i3-TECHNOLOGIES i3HUDDLE User Manual

Hide thumbs Also See for i3HUDDLE:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
USER MANUAL
i3HUDDLE
SOUND BAR

Advertisement

Table of Contents
loading

Related Manuals for i3-TECHNOLOGIES i3HUDDLE

Summary of Contents for i3-TECHNOLOGIES i3HUDDLE

  • Page 1 USER MANUAL i3HUDDLE SOUND BAR...
  • Page 3 2.1 Channel Sound Bar Please read this manual carefully before operating your set and retain it for future reference. Wireless AUDIO CAUTION ƒ Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. ƒ...

  • Page 4: Table Of Contents

    Getting Started Contents Safety Information -------------------- P 3 Unique features ----------------------P 6 Accessories Introduction Front panel --------------------------P 7 Rear panel --------------------------P 8 Mounting Information Installing the Wireless Subwoofer ---------P 9 Optional equipment connections ----------P 10 Basic operations ----------------------P 11 Use of the Wireless Subwoofer -----------P 12 Trouble Shooting ---------------------P 13 Specifications Maintenance -------------------------P 16...

  • Page 5: Safety Information

    Do not cover the slots and openings with a cloth or other materials. Make sure that the I3HUDDLE that this product is installed on has ample ventilation and is not restricted in any way.
  • Page 6 Getting Started This product uses batteries. In your community there might be regulations that require you to dispose of these batteries properly under environmental legislations. Please contact your local authorities for disposal or recycling information. Do not exceed the standard capacity of a multi-plug or power outlet extension when using it for this product.
  • Page 7 Getting Started When installing this product, check that the I3HUDDLE you are installing it to is in a stable location, and the I3HUDDLE itself has been installed properly and securely. Do not drop or impart any shock to the product. If the product is damaged, disconnect the power cord and contact a service center.

  • Page 8: Unique Features

    Getting Started Unique features 1) Exclusive I3HUDDLE Interface 2) Wireless Audio 3) QBS Sound Field Technology Accessories Please check and identify the supplied accessories. Designs and specifications of the accessories are subject to change without prior notice IFTD Mount Bracket...

  • Page 9: Introduction

    Getting Started Introduction Symbols used in this manual Note Indicates special notes and operating features. Caution Indicates cautions for preventing possible damage from abuse Front panel Key Descriptions MUTE If you want to mute the audio press this key. When the HUDDLE Sound Bar is muted a blue light will flash at one second intervals.

  • Page 10: Rear Panel

    You can mount the main unit on to the IFTD. You can also detach the unit from the IFTD Screws 1. Mount the bracket to the bottom of the i3HUDDLE using the four screws provided. 2. Slide the Soundbar onto the bracket.

  • Page 11: Installing The Wireless Subwoofer

    Getting Started Installation Connect the supplied SB cable form the soundbar SB port to the I3HUDDLE SB port. DC 19V...

  • Page 12: Optional Equipment Connections

    Getting Started Optional Equipment Connections DC 19V External Port Arrangement PTB IN connection - Connect PTB Port by using the audio cable. OPTICAL IN connection - Connect OPT port by using the OPTICAL cable Listening to music from your portable player. - After you connect the adaptor cable, select the OPTICAL or PORTABLE function by using the - Play the device after turning on the Power.

  • Page 13: Basic Operation

    2 seconds and select the mode you want. Mode details below: 1. Main mode : Play the i3HUDDLE Sound. 2. OPTICAL mode : Play the external optical device sound. 3. WIRELESS mode (Bluetooth mode) : Play a wireless device (Bluetooth) 4.

  • Page 14: Use Of The Wireless Subwoofer

    Operation Note Use of the Wireless Subwoofer (optional) Wireless Subwoofer Setup 1. Connect the power cord of the wireless subwoofer to the outlet. 2. Turn on the main unit : The main unit and wireless subwoofer will be automatically connected. Pairing Manually If your connection is not completed, you will still see the red LED on the subwoofer.

  • Page 15: Troubleshooting

    Connect SB I/F cables correctly. 3. The mute function is activated. Press MUTE or adjust the volume level to cancel the mute function. 1. When the sound bar FUNC is i3HUDDLE, change the Audio Volume level on i3HUDDLE (OPS) Low Quality or Low 2.
  • Page 16 Operation 1-2. Input/Output 9Pin D-SUB JACK SB-IF (Interface) 3 V (p-p), Optical jack x 1 OPTICAL IN 0.5 VRMS (3.5 mm stereo jack) PORT. IN For F/W Update Bluetooth Audio Wireless Audio Amplifier (Stereo) Stereo mode 45W+45W (Mid 4 Ω), 25W+25W (Tweeter 6 Ω) Subwoofer (Wireless) Type 1Way 1Speaker...
  • Page 17 Operation Mechanical Stereo Outline dimension(mm) 1200 x 90 x 70 Product weight (Kg) Subwoofer Outline dimension(mm) 315.3 x 260 x 370 Product weight (Kg) Soundbar : 6Kg , Subwoofer : 9.5 Kg 1250*350*515 Packing dimension (mm) Packing weight (Kg) 20kg Reliability Stereo : DC 18~19V From Set Power input range...

  • Page 18: Maintenance

    Operation Maintenance Handling the Unit When shipping the unit Please save the original shipping carton and packing materials. If you need to ship the unit, for maximum protection, re-pack the unit as it was originally packed at the factory. Cleaning the unit Do not use volatile liquids such as insecticide spray near the unit.
  • Page 19 Date of Purchase www.i3huddle.com...
