- Page 1 i3TOUCH PREMIUM User’s Manual i3TOUCH P5512 i3TOUCH P6512...
-
Page 2: Table Of Contents
Contents Safety Warnings ..........................1 Prepare to Install..........................2 Connection and Settings ........................ 6 Menu Operations ........................... 9 Simple Troubleshooting ....................... 12 Maintenance ..........................13... -
Page 3: Safety Warnings
Safety Warnings Safety Warnings Before operating the unit, please read this manual thoroughly and keep it for future references. Images shown in this manual are indicative only. There may be differences between the pictures and the actual product. Placement Do not place the unit on an unstable cart, stand, tripod, bracket, table, or shelf. Do not expose the unit to direct sunlight or other sources of heat. -
Page 4: Prepare To Install
Prepare to Install Prepare to Install 1. Control Panel The Interactive Intelligent Panel will enter the standby mode without any presence detection in front of the display. Motion Sensor 2. The standby mode lasts for 15 minutes, then the i3TOUCH will enter the energy saving mode. - Page 5 Prepare to Install VGA IN External computer image input Touch signal output to the external computer TOUCH High-definition multimedia interface signal input, connect to devices with HDMI output HDMI IN interface (personal computer with HDMI output, set-top box, or another video device) AV IN Composite video and audio input COAX OUT...
- Page 6 Prepare to Install Detailed Function Description ：Power on/off ：Mute switch Start：Built-in computer Windows key Space：Built-in computer Space key Alt+Tab：Built-in computer Alt + Tab function Alt+F4：Built-in computer program close function Numeric keys：Numeric input keys Display：Display channel information ：Function button Input：Input signal source selection key, choose different sourced according to need Home：Built-in system main screen button Menu：Setting menu button, press this button to pop up Red：Lock and unlock Buttons function...
- Page 7 Prepare to Install 2) Remote Control Instruction Install Batteries (1) Open back cover of battery component on the back of remote control (2) Install AAA type battery according to the corresponding electrode, make sure battery positive and negative pole are correct ("+"to"+", "-" to "-"), please do not mix using old and new batteries (3) After battery is installed, close the back cover of battery components, and make the following clip buckled to the bottom...
-
Page 8: Connection And Settings
Connection and Setting Connection and Setting For the safety of you and the machine, please do not connect any power plug before connection. (1) Use VGA cable to connect to VGA output port of external computer, and meanwhile use headphone audio cable to connect to external computer audio output interface (2) Use USB cable to connect to external computer USB port... - Page 9 Connection and Setting 2. Audio and Video Equipment (1) Use HDMI cable to connect audio and video equipment with HDMI output (2) After cable connection, plug in power cord, and switch power on (3) Press to turn equipment on 3. Coaxial Connection (1) Use coaxial cable to connect audio device with coaxial input (2) After cable connection, plug in power cord, and switch power on (3) Press...
- Page 10 Connection and Setting 5. LAN Connection Network Cable Internet 6. RS232 Connection After using serial port cable to connect central control equipment and machine, certain function of the machine can be controlled via central control equipment, such as: machine ON/OFF, and adjustment of sound volume, etc.
-
Page 11: Menu Operations
Menu Operation Menu Operation Touch Menu Operation Call up Method Take middle point position on the bottom of display screen as starting point, use finger or touch pen to drag towards screen center position to call up touch menu, as shown below. Note: "Touch A Method"... - Page 12 Menu Operation Detail Setting Menu Press Menu on remote control or click the icon on General Setting menu with touch pen to call up detail setting menu. Detail setting menu includes Audio, Screen, Display and Adjust. Audio Press button on remote control to select Audio setting menu.
- Page 13 Menu Operation Display Press button on remote control to select Display setting menu. Press button on remote control or directly click with touch pen to select the option. Press Enter on remote control to enter adjustment mode, and press button or directly click with ...
-
Page 14: Simple Troubleshooting
Simple Troubleshooting Simple Troubleshooting Machine fails to work normally Check whether there is a direct line-of-sight between remote control and receiver. Check whether the batteries are correctly inserted in the remote control. Remote control failure Check whether the remote control needs new batteries. 1. -
Page 15: Maintenance
Maintenance Maintenance Proper maintenance can avoid many early faults and regular careful cleaning can keep machine brand new. Please unplug power plug before cleaning and maintenance, to prevent electric shock. Clean Screen Please moisten a little fabric softener or tableware detergent with warm water. Please use a soft cloth to be completely soaked in the mixture.
