Straight guide
The straight guide is effectively used for straight cuts
when chamfering or grooving.
► Fig.10
To install the straight guide, insert the guide bars into
the holes in the tool base. Adjust the distance between
the bit and the straight guide. At the desired distance,
tighten the wing bolts to secure the straight guide in
place. When cutting, move the tool with the straight
guide flush with the side of the workpiece.
► Fig.11: 1. Guide bar 2. Clamp screw 3. Straight
guide
If the distance (A) between the side of the workpiece
and the cutting position is too wide for the straight
guide, or if the side of the workpiece is not straight, the
straight guide cannot be used. In this case, firmly clamp
a straight board to the workpiece and use it as a guide
against the trimmer base. Feed the tool in the direction
of the arrow.
► Fig.12
Dust nozzle set (For European
countries only)
Use the dust nozzle for dust extraction. Install the dust
nozzle on the tool base using the thumb screw so that
protrusion on the dust nozzle fit to the notch in the
tool base. Then connect a vacuum cleaner to the dust
nozzle.
► Fig.13: 1. Dust nozzle 2. Thumb screw
► Fig.14

MAINTENANCE

CAUTION:
Always be sure that the tool is
switched off and unplugged before attempting to
perform inspection or maintenance.
NOTICE:
Never use gasoline, benzine, thinner,
alcohol or the like. Discoloration, deformation or
cracks may result.
To maintain product SAFETY and RELIABILITY,
repairs, any other maintenance or adjustment should
be performed by Makita Authorized or Factory Service
Centers, always using Makita replacement parts.
OPTIONAL
ACCESSORIES
CAUTION:
These accessories or attachments
are recommended for use with your Makita tool
specified in this manual. The use of any other
accessories or attachments might present a risk of
injury to persons. Only use accessory or attachment
for its stated purpose.
If you need any assistance for more details regard-
ing these accessories, ask your local Makita Service
Center.
• Straight & groove forming bits
• Edge forming bits
• Laminate trimming bits
NOTE: Some items in the list may be included in the
tool package as standard accessories. They may
differ from country to country.
Router bits
Straight bit
► Fig.15
D
6
1/4"
8
6
1/4"
6
1/4"
"U"Grooving bit
► Fig.16
D A
6 6
"V"Grooving bit
► Fig.17
D A
1/4" 20
Drill point flush trimming bit
► Fig.18
D A
8 8
6 6
9 ENGLISH
A L1
20 50
8 60
8 50
6 50
L1 L2
50 18
L1 L2
50 15
L1 L2
60 20
60 18
Unit:mm
L2
15
25
18
18
Unit:mm
R
3
Unit:mm
θ
90°
Unit:mm
L3
35
28
