3) Place to one side.
4) Slide the Appliance door down about 15cm and off the
top hinge pin and lift away from the Appliance.
5) Remove the two screws from top bracket and replace
on the otherside.You will need to first remove the plastic caps
from the other side.
6) Slide the Appliancedoor back on to the Top hinge,
making sure it's the right way up.
Screw the bottom hinge into place on the new side.
Replace theother foot on the other side.Replace the
plastic covering by clicking back into position on the
door hinge.
7) Check that the door is aligned horizontally and
vertically and that the seals are closed on all sides
before finally tightening the bottom hinge.
Re-adjust the levelling feet.
Door
2.3 Space Requirements
The unit's door must be able to open fully as shown.
W D 900mm 800mm
3
