Summary of Contents for Axial SCX10 II 2000 JEEP CHEROKEE
- Page 4 Make sure charger is correct for battery type selected for use. Examples: Do NOT charge Lipo batteries with Nickel Metal Hydride charger. Do NOT charge Nickel Cadmium batteries Lipo charger. Stellen Sie sicher, Ladegerät ist korrekt für Batterietyp zur Verwendung ausgewählt. Beispiele: Laden Sie keine Lipo-Akkus mit Nickel-Metall-Hydrid-Ladegerät.
- Page 5 Top View Parts Front Bumper Tactic TSX45 Servo Steering Rack Front Body Mount Steering Knuckle C-Hub Battery Strap Receiver Box Battery Tray ESC Plug Motor 35T Transmission AE-5 Electronic Speed Control(ESC) Rock Rail Spur/Pinion/Slipper (Under Cover) Lower 4-link Bar Upper 4-link Bar Driveshaft Rear Body Mount Shock Absorber...
- Page 6 Getting-Started Checklist The following checklist is a guide for getting you vehicle running for the first time. Read ‘Cautions’ in Manual. (Page 2) Familiarize yourself with vehicle and Even though the vehicle is new check its components. driveshaft setscrews and other screws to make sure they are tight from the factory.
- Page 7 Range-Checking Your Radio System The radio system should be checked before operating the vehicle to ensure it’s operating properly and has adequate range. 1. Turn on the transmitter and then connect the battery in the vehicle. 2. Have a friend hold the vehicle while keeping hands and loose clothing away from moving parts. 3.
- Page 8 Battery Tray Adjust to the appropriate range. AX31388 AX31388 AX31388 Suitable battery size. AX31373 AX31373 5.75” x 1.2” (147mm x 32mm) AX31373 5.44” x .94” (138mm x 24mm) AX31373 M2.6x8mm AE-5 Forward/Reverse ESC w/ Drag Brake Mount the ESC in an area that is well ventilated and isolated from vibration and shock. Connect the ESC motor wires to the motor red-red &...
- Page 9 2016 SCX10 Spur/Pinion Gear Ratio Chart - AX Transmission Spur 45.50 42.00 39.00 36.40 34.13 32.12 30.33 48.75 45.00 41.79 39.00 36.56 30.559 30.956 NOTES...
- Page 10 Details Install AXA1179 AX31389 2.5x1.5mm AX31374 AX31389 3mm Body Clip AX31194 AX31194 AX31389 AX31373 AX31389 M2.6x8mm AX31194 M2.6x4mm AX31389 AX31373 AX31389 AXA1179 AX31374 AX31389 AX31390 Front AX31390 AXA0286 M4x2.5x13mm AX31390 AX31393 AXA0286 Rear AX31390...
- Page 11 AXIAL LIMITED WARRANTY Your Axial product is warranted to be free of defects in materials and workmanship when new in the factory sealed box. This warranty does not cover damages due to normal wear and tear, users' failure to perform routine maintenance, error of assembly or installation, modifications or addition of aftermarket parts or option parts. This warranty lasts as long as the original purchaser owns the product and is not transferable (verified by dated itemized sales receipt accompanied with product).
- Page 12 AX80029 Shock Cap Parts Tree AX80006 Servo Set AX80018 Hardware Parts Tree AX31114 AX80032 WB8-HD Driveshaft 10mm Shock Parts Tree AX80009 Transmission Set AX80078 Transmission Spur Gear Cover AX31186 M4 Rod End Set AX31401 AR44 Axle Housing AX31379 SCX10 II Skid Plates AX8079 AX80030 Wheel Cap...
- Page 13 AX31387 SCX10 II Servo Mounts AX31386 SCX10 II Frame Braces AX31388 SCX10 II Battery Tray AX31389 2000 Jeep® Cherokee Exterior Details AX31390 Headlight and Turn Signal Lenses AX31391 AX31393 SCX10 II Body Posts JCROffroad Vanguard Rear Bumper AX31392 JJCROffroad Vanguard Front Bumper...
- Page 14 AX31083 Radio Box Seals AX31404 AR44 Differential Locker AX30413 AX31148 Slipper spring 8.5x12 WB8-HD Driveshaft Coupler Set AX30427 Narrow 12mm Aluminum Hub AX31405 AX80010 Heavy Duty Bevel Gear Set AX30435 Gear Set 52T/28T 30T/8T Steel Outdrive Shaft AX31145 Spring 12.5x60mm 2.63 lbs/in - (Yellow) AX31180 AX30724 Pinion Gear 32P 13T...
- Page 15 AXA1179 O-Ring 2.5x1.5mm A XA0286 AX31398 M2.6x12mm Hex Socket Cap Head Screw Shaft M4x12mm AXA1163 O-Ring 7x1mm AXA180 AX31399 M3x3mm Set Screw M2.6x18mm Hex Socket Cap Head AXA1070 Washer 3x6x0.5mm AXA291 M4x4mm Set Screw AX30162 AXA083 Pin 1.5x8mm M3x6mm Hex Socket Cap Head AX30163 Pin 2x10mm AX31403...
- Page 22 M2x6 mm Cap Head (Black) (10pcs) AX30413 Slipper spring 8.5x12 165 lbs/in - Black (2pcs) AXA0286 Screw Shaft M4x2.5x12mm (6pcs) AX30427 Axial Narrow 12mm Aluminum Hub - Black (4pcs) AXA0414 M2.6x10mm Hex Socket Tapping Flat Head (Black) (10pcs) AX30435 Steel Outdrive Shaft Set (2pcs) AXA0437...
- Page 23 Axial Dingo Truck Body - .040" uncut (Clear) - Body Only AX04034 2012 Jeep Wrangler Unlimited Rubicon™ Roof - .040” (Clear) AX4025 Axial Trail Honcho Truck Body - .040" uncut (Clear) w/Molded Rear Cage AX04035 2012 Jeep Wrangler Unlimited Rubicon™ Body - .040” (Clear) - Complete AX4025R Axial Trail Honcho Truck Body - .040"...
