Summary of Contents for Axial SCX10 II
- Page 2 Hobby Services, Axial will repair or replace any incorrectly made part. Your receipt or invoice at the time of purchase is your proof of purchase and is required for Axial to honor any warranty. Axial reserves the right to change or modify this warranty without notice. This warranty...
- Page 6 Make sure charger is correct for battery type selected for use. Examples: Do NOT charge Lipo batteries with Nickel Metal Hydride charger. Do NOT charge Nickel Cadmium batteries Lipo charger. Stellen Sie sicher, Ladegerät ist korrekt für Batterietyp zur Verwendung ausgewählt. Beispiele: Laden Sie keine Lipo-Akkus mit Nickel-Metall-Hydrid-Ladegerät.
- Page 7 Top View Parts Tactic TSX45 Servo Steering Rack Steering Knuckle Front Body Mount C-Hub Battery Strap Receiver Box ESC Plug Battery Tray Motor 35T Transmission AE-5 Electronic Speed Control(ESC) Spur/Pinion/Slipper Driveshaft (Under Cover) Lower 4-link Bar Upper 4-link Bar Shock Absorber Rear Body Mount Differential (inside axle housing)
- Page 8 Getting-Started Checklist The following checklist is a guide for getting you vehicle running for the first time. Read ‘Cautions’ in Manual. (Page 2) Familiarize yourself with vehicle and Even though the vehicle is new check its components. driveshaft setscrews and other screws to make sure they are tight from the factory.
- Page 9 Range-Checking Your Radio System The radio system should be checked before operating the vehicle to ensure it’s operating properly and has adequate range. 1. Turn on the transmitter and then connect the battery in the vehicle. 2. Have a friend hold the vehicle while keeping hands and loose clothing away from moving parts. 3.
- Page 10 M2.6x8mm AX31388 AX31388 AX31388 Suitable battery size. AX31373 AX31373 5.75” x 1.2” (147mm x 32mm) AX31373 5.44” x .94” (138mm x 24mm) SCX10 II Spur/Pinion Gear Ratio Chart - LCX Transmission Spur 45.50 42.00 39.00 36.40 34.13 32.12 30.33 48.75 45.00...
- Page 11 AE-5L Forward/Reverse EAS w/ Drag Brake Mount the ESC in an area that is well ventilated and isolated from vibration and shock. Connect the ESC motor wires to the motor red-red & black-black. Plug the receiver with into the throttle channel on the receiver. The black negative wire should be towards the outside of the receiver.
- Page 12 AX31577 Shock Cap Parts Tree AX31576 AX80018 10mm Shock Parts Tree Hardware Parts Tree AX31380 SCX10 II Shock Hoops AX31592 AR44 Solid Axle Housing (Front and Rear) AX31186 M4 Rod End Set AX31589 AX31381 AR44 Differential Covers (Red) AR44 Steering Knuckles...
- Page 13 AX80046 1/10th Scale Truggy Bed Set AX80046 1/10th Scale Truggy Bed Set AX31536 SCX10 II Steering Link AX80046 AX31588 1/10th Scale Truggy Bed Set Body Mount Set AX80044 Axial SCX10 AX80046 Tube Bumper Parts Tree 1/10th Scale Truggy Bed Set...
- Page 14 Hub Cover Set - Black AX31541 1.9 Method MR307 Hole Wheels - Black AX31379 SCX10 II Skid Plates AX80045 AX80045 Light Bucket Set Light Bucket Set (Black) AX31533 SCX10 II™ Upper Links Set AX31418 SCX10 II Chassis Rails AX31552 SCX10 II™ Lower Links Set...
- Page 15 AX30724 Pinion Gear 32P 13T AX30413 AX30427 Slipper spring 8.5x12 Narrow 12mm Aluminum Hub AX31148 AX80010 AX30435 WB8-HD Driveshaft Coupler Set Gear Set 52T/28T Steel Outdrive Shaft AX31145 Spring 12.5x60mm 2.63 lbs/in - (Yellow) AX31530 AR44 Locker Bevel Gear Set 30T/8T AX31441 Spring 12.5x60mm1.13lbs/in - (White) AX31026...
- Page 16 AXA1070 AXA1059 AXA1179 Washer 3x6x0.5mm O-Ring 2.5x1.5mm 6mm Body Clip AXA1201 AXA013 O-Ring 3x2mm M2x6mm Hex Socket Cap Head A XA0286 Screw Shaft M4x12mm AXA1163 AXA0023 O-Ring 7x1mm M2.6x8mm Cap Head AXA176 Screw Shaft M3x2.5x13mm AX30162 Pin 1.5x8mm AX31399 M2.6x18mm Hex Socket Cap Head AXA180 AX30163 M3x3mm Set Screw...
- Page 24 AX31406 Bearing 7x14x3.5mm (2pcs) AX31407 Bearing 5x14x5mm (2pcs) AX31408 AR44 Straight Axle Shaft 5x106mm (2pcs) AX31418 SCX10 II Chassis Rails (2pcs) AX31441 Spring 12.5x60mm 1.13 lbs/in - (White) (2pcs) AX31471 Axle 12x36mm (2pcs) AX31472 Solid Axle Dogbone 6x73.5mm (2pcs) AX31480...
- Page 25 Axial Dingo Truck Body - .040" uncut (Clear) - Body Only AX24258 4 LED Light String (White LED) AX4025 Axial Trail Honcho Truck Body - .040" uncut (Clear) w/Molded Rear Cage AX24259 Axial AE-2 Forward/Reverse ESC w/Drag Brake AX4025R Axial Trail Honcho Truck Body - .040" uncut (Clear) - Body Only...
- Page 26 NOTES...
- Page 27 NOTES...
