  • Page 2 Hobby Services, Axial will repair or replace any incorrectly made part. Your receipt or invoice at the time of purchase is your proof of purchase and is required for Axial to honor any warranty. Axial reserves the right to change or modify this warranty without notice. This warranty...
  • Page 6 Make sure charger is correct for battery type selected for use. Examples: Do NOT charge Lipo batteries with Nickel Metal Hydride charger. Do NOT charge Nickel Cadmium batteries Lipo charger. Stellen Sie sicher, Ladegerät ist korrekt für Batterietyp zur Verwendung ausgewählt. Beispiele: Laden Sie keine Lipo-Akkus mit Nickel-Metall-Hydrid-Ladegerät.
  • Page 7 Top View Parts Tactic TSX45 Servo Steering Rack Steering Knuckle Front Body Mount C-Hub Battery Strap Receiver Box Battery Tray ESC Plug Motor 35T Transmission AE-5 Electronic Speed Control(ESC) Spur/Pinion/Slipper Driveshaft (Under Cover) Lower 4-link Bar Upper 4-link Bar Shock Absorber Rear Body Mount Differential (inside axle housing)

  • Page 8: Getting-Started Checklist

    Getting-Started Checklist The following checklist is a guide for getting you vehicle running for the first time. Read ‘Cautions’ in Manual. (Page 2) Familiarize yourself with vehicle and Even though the vehicle is new check its components. driveshaft setscrews and other screws to make sure they are tight from the factory.

  • Page 9: Maintaining Your Vehicle

    Range-Checking Your Radio System The radio system should be checked before operating the vehicle to ensure it’s operating properly and has adequate range. 1. Turn on the transmitter and then connect the battery in the vehicle. 2. Have a friend hold the vehicle while keeping hands and loose clothing away from moving parts. 3.

  • Page 10: Battery Tray

    Battery Tray AX31373 Adjust to the appropriate range. M2.6x8mm AX31388 AX31388 AX31388 Suitable battery size. AX31373 AX31373 5.75” x 1.2” (147mm x 32mm) AX31373 5.44” x .94” (138mm x 24mm) SCX10 II Spur/Pinion Gear Ratio Chart - LCX Transmission Spur 45.50 42.00 39.00...
  • Page 11 AE-5L Forward/Reverse EAS w/ Drag Brake Mount the ESC in an area that is well ventilated and isolated from vibration and shock. Connect the ESC motor wires to the motor red-red & black-black. Plug the receiver with into the throttle channel on the receiver. The black negative wire should be towards the outside of the receiver.
  • Page 12 AX31186 M4 Rod End Set AX80018 AX80006 Hardware Parts Tree Servo Set AX31577 Shock Cap Parts Tree AX80030 61-90mm Shock Body AX31576 Shock Parts Tree AX31586 WB8-HD Standard Driveshaft AX31382 AR44 Knuckle Carrier AX31380 SCX10 II Shock Hoops AX31383 AR44 Straight Axle adapters AX31401 AR44 Axle Housing...
  • Page 13 AX31386 SCX10 II Frame Braces AX31388 SCX10 II Battery Tray AX31573 AX31569 CRC JK Rock Sliders Tail Light Lens (Red) AX31391 SCX10 II Body Posts AX31572 AX31387 AX31575 CRC Front JK Fender Flares SCX10 II Servo Mounts CRC JK Rear Fender Flares...
  • Page 14 AX31571 CRC JK Front Bumper AX31570 CRC JK Rear Bumper AX31385 AX31574 SCX10 II Side Plates CRC JK Body Details AX31027 Spur Gear 32P 56T AX31531 AX31418 LCX Transmission Case (Silver) SCX10 II Chassis Rails...
  • Page 15 AX30413 Slipper spring 8.5x12 AX31148 AX31405 AX31585 AX30435 WB8-HD Driveshaft Coupler Set Heavy Duty Bevel Gear Set Gear Set Steel Outdrive Shaft 30T/8T (48P 28T, 48P 52T) AX30427 Narrow 12mm Aluminum Hub AX31083 Radio Box Seals AX31404 AR44 Differential Locker X31068 AX31026 Slipper...
  • Page 16 AXA1392 E2 e-clip AXA180 AXA013 M2x6mm Hex Socket Cap Head M3x3mm Set Screw AXA1070 Washer 3x6x0.5mm AXA291 AX31066 AXA1179 M2x8mm Hex Socket Cap Head M4x4mm Set Screw O-Ring 2.5x1.5mm AXA1163 AXA016 O-Ring 7x1mm AX31403 M2x12mmHex Socket Cap Head M3x4x10mm Hex Socket Button Head Shoulder Screw AX30162 Pin 1.5x8mm...
  • Page 24 Details Install AX31374 4mm Body Clip AXA1179 O-Ring 2.5x1.5mm AX31194 M2.6x4mm AX31574 AX31574 AXA1179 AX31574 AX31374 AX31374 AXA1179 AX31374 AX3157412 AXA1179 AX31574 AX3157412 AX31574 AX31194 AX31574 AX31374 AX31574 AXA1179 AX31374 AXA1179 AX31574...
  • Page 25 NOTES...
  • Page 26 M3x6mm Hex Socket Button Head (Black) (10pcs) AX30413 Slipper spring 8.5x12 165 lbs/in - Black (2pcs) AXA013 M2x6 mm Cap Head (Black) (10pcs) AX30427 Axial Narrow 12mm Aluminum Hub - Black (4pcs) AXA016 M2x12mm Cap Head (Black) (10pcs) AX30435 Steel Outdrive Shaft Set (2pcs) AXA0286 Screw Shaft M4x2.5x12mm (6pcs)

  • Page 27: Option Parts

    Axial Dingo Truck Body - .040" uncut (Clear) - Body Only AX04038 1.9 Walker Evans Street Wheel - Black (2pcs) AX4025 Axial Trail Honcho Truck Body - .040" uncut (Clear) w/Molded Rear Cage AX04039 1.9 Walker Evans Street Wheel - Chrome/Black (2pcs) AX4025R Axial Trail Honcho Truck Body - .040"...
  • Page 28 8810023...
