Summary of Contents for Axial YETI JR. ROCK RACER
- Page 4 DTXP4175 USB NiMH Charger and DTXC2031 Battery Instructions Before using your factory assembled RTR, review the entire instruction manual to become familiar with the vehicle. This is a quick start guide for care and usage of the charger and battery that comes with the vehicle. DTXP4175 - Duratrax Onyx USB Charger •...
- Page 5 Top View Parts Front Control Arm Front Bumper C-Hub Front Shock Absorber Steering Knuckle Steering Rack Front Body Mount Spur/Pinion (Under Cover) Steering Servo Motor 40T Receiver Box and Electronic Speed Control (ESC) Battery Tray Rear Shock Absorber Rear Swing Arm Driveshaft Battery Door Rear Differential...
- Page 6 Getting-Started Checllist The following checklist is a guide for getting you vehicle running for the first time. Read ‘Cautions’ in Manual. (Page 2) Familiarize yourself with vehicle and Before vehicle operation its components. check all nuts and screws on moving parts are securely tightened.
- Page 7 Range-Checking Your Radio System The radio system should be checked before operating the vehicle to ensure it’s operating properly and has adequate range. 1. Turn on the transmitter first and then the vehicle. 2. Have a friend hold the vehicle while keeping hands and loose clothing away from moving parts. 3.
- Page 8 AXIAL LIMITED WARRANTY Your Axial product is warranted to be free of defects in materials and workmanship when new in the factory sealed box. This warranty does not cover damages due to normal wear and tear, users' failure to perform routine maintenance, error of assembly or installation, modifications or addition of aftermarket parts or option parts. This warranty lasts as long as the original purchaser owns the product and is not transferable (verified by dated itemized sales receipt accompanied with product).
- Page 17 AX31516 Yeti Jr.™ Steering Knuckle Set AX31508 Yeti Jr.™ Rear Cage Battery Tray AX31512 Yeti Jr.™ Chassis Components AX31514 Yeti Jr.™ Front Lower Control Arm Set AX31515 Yeti Jr.™ Front Carrier Set AX80029 Shock Cap Parts Tree AX31518 AX31506 AX80032 Yeti Jr.™...
- Page 18 AX31520 Yeti Jr.™ Battery Door AX31510 AR18 Axle Housing AX31513 AX31522 1.55 Method Beadlock Style Wheels Spur Gear 48P 60T AX31511 (Black) Dogbone and Center Driveline Set AX31519 Yeti Jr.™ Body Cage AX31517 Yeti Jr.™ Front Shock Tower and Bumper Set AX80030 AX31505 AX31009...
- Page 19 AXA013 AX31280 AXA0413 AXA1060 M2x6mm Cap Head M2.6x6mm Hex Socket Button Head M2.6x8mm Hex Socket 3mm Body clip (Black) Tapping Flat Head AXA0023 AXA0065 AXA1392 M2.6x8mm Cap Head AXA0414 M2.6x10mm Hex Socket Button Head E2 e-clip M2.6x10mm Hex Socket Tapping Flat Head AX31398 AX31195 M2.6x12mm Cap Head...
- Page 25 AX30146 Shock Shaft 3x50 (2pcs) AX30162 Pin 1.5x8mm (6pcs.) AX30168 Pin 2x8mm (6pcs.) AX31009 2-Speed Hi/Lo Servo Saver Set AX31195 M2.6x12mm Hex Socket Button Head (Black) (10pcs) AX31280 M2.6x6mm Hex Socket Button Head (Black) (10pcs) AX31289 Shim 10x8x0.3mm (6pcs) AX31374 3mm Body Clip (Black) (10pcs) AX31398 M2.6x12mm Cap Head (Black) (10pcs)
- Page 26 NOTES...
- Page 27 NOTES...
- Page 28 2803877...
