1.

GENERAL INFORMATION

MANUFACTURER:
VICTORIA ARDUINO - Via M. D'Antegiano, 6 - Belforte del Chienti, Macerata (MC) - Italy
MODELS:
MYTHOS - Elettronic-instantaneous coffee grinder system
2.

TECHNICAL DATA

DESCRIPTION
Volts (V)
Frequency (Hz)
Power (W)
Revolution per min. (rpm)
Production rate (Kg/h)
Empty weight (Kg)
Height (mm)
Width (mm)
Depth (mm)
Noise factor (dBA)
3.

APPLIANCE DESCRIPTION

1 Body machines
2 Coffee bean holder
3 Holder lid
4 Switch

5 Control panel

6 Start-up micro-switch
7 Fork portafilter
4. CONTROL PANEL
1 Liquid crystal display
2 In operating mode, this decreases a selected dose
3 In operating mode, this increases a selected dose
4 In operating mode, this selects one of the three doses
3+4 Together: access to programming
8
MYTHOS 220
220 220/240
60 50
570 450
900 900
15 15
22 22
510 510
185 185
400 400
65 65
8 Pouring lip
9 Open/closer holder tab
10 Grinding adjustment knob
11 Extractor fan
12 Intake fan
13 Heating element
14 Filter holder retaining device
(Fig. 2)
MODEL
MYTHOS
110
60
960
1090
15
22
510
185
400
65
(Fig. 1)
EN
110
MYTHOS
