4.32 Clock/Timer - if fitted
ELECTRO/MECHANICAL and DIGITAL clock/timer - Release the
mounting bracket securing screws, see diagram 4.27.
Note: Care should be taken here, as these screws also retain the
fan driver control housing in position, see diagram 4.1.
Disconnect electrical cables, release securing clip to remove the
clock/timer spacer plate, see diagram 4.28.
CLOCK/TIMER
SECURING
SCREWS (2)
ELECTRICAL
CONNECTIONS
y y
br b
MAINS
COMMON
LIVE (L)
HEATING ON
DIGITAL CLOCK/TIMER
Supplied By www.heating spares.co Tel. 0161 620 6677
4 Replacement of Parts
KEY
br BROWN
b BLUE
y YELLOW
MAINS
NEUTRAL (N)
Diagram 4.27
SECURING CLIP (2)
ELECTRO/MECHANICAL and
DIGITAL CLOCK/ TIMER
47
MOUNTING
BRACKET
SPACER
PLATE
TIMER/CLOCK
Diagram 4.28
