Installation and Servicing
125 electronic
G.C. No. 47 313 19
Fanned Flue Combination Boiler
This is a Cat I
The instructions consist of three parts, User, Installation and Servicing Instructions, which includes the Guarantee Registration Card.
The instructions are an integral part of the appliance and must, to comply with the current issue of the Gas Safety (Installation and Use)
Glow-worm appliances' are manufactured to the very highest standard so we are pleased offer our customers'
In the center pages are to be found your Guarantee Registration Card, which we recommend you complete
If this card is missing you can obtain a copy or record your registration by telephoning the
Our Guarantee gives you peace of mind plus valuable protection against breakdown by covering the cost of:
All replacement parts
All labour charges
All call-out charges
One Contact Local Service
Supplied By www.heating spares.co Tel. 0161 620 6677
Instructions for Use
To b e l e f t w i t h t h e u s e r
Appliance
2H
Regulations, be handed to the user on completion of the installation.
Guarantee Registration
Thank you for installing a new Glow-worm appliance in your home.
a Comprehensive First Year Guarantee.
and return as soon as possible.
Heatcall Customer Service number 01773 828100.
Customer Services:
Tel: (01773) 828100
Fax: (01773) 828070
REGISTER YOUR GLOW-WORM APPLIANCE
FOR 1ST YEAR GUARANTEE PROTECTION
CALL 0181 380 2555
Nottingham Road, Belper, Derbyshire. DE56 1JT
General/Sales enquiries:
Tel: (01773) 824141 Fax: (01773) 820569
221474C.02.00
Hepworth Heating Ltd.,
