Current Measurement Option
be removed and replaced with an ammeter across the pins to measure the current drawn
from the +5 V or the +3.3 V supplies, respectively.
—A motor/encoder header is provided at header J6 for future use.
Motor Encoder
LCD/Keypad Module
101-0465) may be plugged in directly to headers J7, J8, and J10.
10
—Jumpers across pins 1–2 and 5–6 on header JP1 can
—Z-World's LCD/keypad module (Z-World part number
RabbitCore RCM3000
