Makita 2107F Instruction Manual

Portable band saw
Hide thumbs Also See for 2107F:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction Manual
Portable Band Saw
MODEL 2107F
I N S T R U C T I O N
WARNING:
For your personal safety, READ and UNDERSTAND before using.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
DOUBLE
INSULATION
M A N U A L
005893

Advertisement

Table of Contents
loading

Related Manuals for Makita 2107F

Summary of Contents for Makita 2107F

  • Page 1 Portable Band Saw MODEL 2107F 005893 DOUBLE INSULATION I N S T R U C T I O N M A N U A L WARNING: For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.

  • Page 2: Specifications

    SPECIFICATIONS Model 2107F Round workpiece 120 mm (4-3/4”) dia. Max. cutting 120 mm x 120 mm capacity Rectangular workpiece (4-3/4” x 4-3/4”) 1.0 - 1.7 m/s Blade speed (200 - 350 ft./min.) Length 1,140 mm (44-7/8”) Blade size Width 13 mm (1/2”) Thickness 0.5 mm (0.020”)
  • Page 3 7. MAKE WORKSHOP KID PROOF with pad- 17. USE RECOMMENDED ACCESSORIES. locks, master switches, or by removing Consult the owner’s manual for recom- starter keys. mended accessories. The use of improper accessories may cause risk of injury to 8. DON’T FORCE TOOL. It will do the job bet- persons.

  • Page 4: Additional Safety Rules For Tool

    4. Cutting workpieces covered with oil can cause the blade to come off unexpectedly. Wipe off all excess oil from workpieces before cutting. 5. Never use the cutting oil as a cutting lubri- cant. Use only Makita cutting wax. 6. Do not wear gloves during operation.
  • Page 5 SAVE THESE INSTRUCTIONS WARNING: MISUSE or failure to follow the safety rules stated in this instruction manual may cause serious personal injury. SYMBOLS USD201-2 The followings show the symbols used for tool. V ....... volts ....no load speed ˚ A ....... amperes ....Class II Construction Hz .....

  • Page 6: Functional Description

    FUNCTIONAL CAUTION: DESCRIPTION • Always be sure that the tool is switched off and unplugged before adjusting or checking function on the tool. Switch action 005894 CAUTION: • Before plugging in the tool, always check to see that the switch trigger actuates properly and returns to the “OFF” position when released.

  • Page 7: Installing Or Removing The Blade

    NOTE: • Use a dry cloth to wipe the dirt off the lens of lamp. Be careful not to scratch the lens of lamp, or it may lower the illumination. • Do not use thinner or gasoline to clean the lamp. Such solvents may damage it.
  • Page 8 Match the direction of the arrow on the blade to that of the 005900 arrow on the wheels. 1. Saw blade 2. Bearing 3. Upper holder 4. Lower holder Position the blade around the wheels and insert the other 005901 side of the blade within the upper holder and lower holder until the blade back contacts the bottom of the upper holder and lower holder.

  • Page 9: Operation

    • When not using the tool for a long period of time, remove the blade from the tool. When cutting metals, use Makita cutting wax as a cutting 005903 lubricant. To apply the cutting wax to the blade teeth, start the tool and cut in to the cutting wax as shown in the figure after removing a cap of the cutting wax.

  • Page 10: Maintenance

    Remove screws, which secure Lamp Box for the light. Pull out the Lamp Box keeping pushing lightly the upper posi- tion of it as illustrated on the left. Pull out the fluorescent tube and then replace it with Makita original new one.

  • Page 11: Replacing Carbon Brushes

    CAUTION: • These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose.
  • Page 12 Memo...
  • Page 13 Stamp Timbre Makita Canada Inc. 1950 Forbes Street, Whitby, Ontario L1N 7B7 Fold...
  • Page 14 Your answers to the following questions are appreciated. 1. This product was purchased from? 3. How did you first learn of Makita Power Tools? Hardware/lumber Store Industrial Supply Magazine/Newspaper Catalog Tool Distributor Other ( From dealer Other ( Store display 2.
  • Page 15 When you need service... DATE • Explain the problem in a letter PURCHASED: • Enclose the letter with the tool DEALER’S NAME • Package carefully and send prepaid & ADDRESS: to the nearest Makita factory or authorized service centre MODEL NO.: SERIAL NO.:...
  • Page 16 WARRANTY. “The Makita Warranty is the only and the entire written warranty given by Makita for the Makita tools. No dealer or his agent or employee is authorized to extend or enlarge upon this warranty by any verbal or written statement or advertisement.”...
