DSC PC1575 Programming Manual

Supported
DSC Modules
Enter Program
Exit Program
Move to location
Default Panel
Enable Download
Hex Program
[00] Keypad Assignment (must be done at each keypad)
[0] Slot (Valid entries are 11-18 for the Slot)
[1] Function Key 1 Assignment (Default = 03)
[2] Function Key 2 Assignment
[3] Function Key 3 Assignment
[4] Function Key 4 Assignment
[5] Function Key 5 Assignment
00 Null Key (Not Used)
01 Not used
02 Not used
03 Stay Arm
04 Away Arm
05 * 9 No-Entry Arm
06 * 4 Chime On/Off
If multiple LCD keypads make 1 slot 8 to enable Zone description programming by downloader
[01] Zone 1-6 Definitions
Default
01
l_____l_____l
06
l_____l_____l
03
l_____l_____l
03
l_____l_____l
03
l_____l_____l
03
l_____l_____l
[02] System Times
Default
030 I _ _I _ _I _ _I Entry Delay 1
045 I _ _I _ _I _ _I Entry Delay 2
120 I _ _I _ _I _ _I Exit Delay
004 I _ _I _ _I _ _I Bell Cut-off
[03] Installer's Code
Default
1575 I _1 _I _5 _I _7 _I _5 _I
[04] Master Code
Default
1234 I _ _I _ _I _ _I _ _I
[05] Second Master Code
Default
AAAA I _ _I _ _I _ _I _ _I
Created by Mark Leuck 02/02/2002
DSC PC1575 Program Sheet
PC5580 Escort
PC5400 Printer Module
DLM-1/DLM-4 Downlook Module
Cannot use PC5132 Wireless Receiver or Sensors
* 8 1575 (READY, ARMED and TROUBLE Lights should flash)
#
Enter 2-digit location, some areas may require # to exit
1. Connect wire from Zone 1 to PGM1
2. Power up panel, wait 10 seconds
3. If Zone 1 turns ON panel is defaulted, if not panel is locked
* + 6 + Master Code + 5 (Enables for 1 hour)
(System also enables downloading for 1 hour if powered down then up)
A = * 1 *, B = * 2 *, C = * 3 *, D = * 4 *, E = * 5 *, F = * 6 *
(Default = 04)
(Default = 06)
(Default = 14)
(Default = 16)
07 * 6 4 System Test
08 * 1 Bypass Mode
09 * 2 Trouble Display
10 * 3 Alarm Memory
11 * 5 User Programming
12 * 6 User Functions
00 Null (Not Used) 11 24 Hour Burglary
01 Delay 1
Zone 1 02 Delay 2
Zone 2 03 Instant
Zone 3 04 Interior
Zone 4 05 Interior, Stay/Away
Zone 5 06 Delay, Stay/Away
Zone 6 07 Delay 24 Hour Fire
08 Standard 24 Hour Fire
09 24 Hour Supervisory (Links)
10 24 Hour Supervisory Buzzer
(000 to 255 seconds)
(000 to 255 seconds)
13 * 7 1 Utility Output
14 * 7 2 Sensor Reset
15 Not Used
16 * 0 Quick Exit
17 * 1 Reactivate Stay/Away's
18 Not Used
12 24 Hour Heat
13 Not Used
14 24 Hour Hold-Up
15 24 Hour Auxiliary
16 24 Hour Panic
17 24 Hour Emergency
18 24 Hour Sprinkler
19 24 Hour Water
20 24 Hour Freeze
21 24 Hour Latching Tamper
(000 to 255 seconds)
(000 to 255 minutes)
