DSC PC15OO Installation Manual

Dsc pc15oo security system installation manual
Hide thumbs Also See for PC15OO:
Table of Contents

Advertisement

Quick Links

See also: Instruction Manual
INSTALLATION
MANUAL
PC15OO
This device complies with Parts 15 and 68 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
FCC Registration Number: F53CAN-61031-AL-E REN = 0.0B
Plug Type : RJ31X
MADE IN CANADA
Technical Manuals Online! - http://www.tech-man.com

Advertisement

Table of Contents
loading

Related Manuals for DSC PC15OO

Summary of Contents for DSC PC15OO

  • Page 1 INSTALLATION MANUAL PC15OO This device complies with Parts 15 and 68 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 2 NOTES FOR UL INSTALLATIONS This equipment is UL listed in accordance with standard UL1023 (Household Burglar - Alarm System Units), standard UL985 (Household Fire Warning Units) and UL1635 (Digital Alarm Communicator System Units). This equipment has the capability of being programmed for operational features that are not allowed for UL recognized installations.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS FEATURES PECIFICATIONS INSTALLATION Mounting the Panel ................................ 2 Mounting the Keypad ..............................2 Auxiliary Power Connection ............................2 PGM Terminal Connections ............................2 Keypad Wiring ................................2 Bell/Siren Connection ..............................2 Fire Zone Wiring ................................3 Burglary Zone Wiring ..............................3 AC Power Wiring ................................
  • Page 4 PROGRAMMING SECTIONS [00] Binary Programming ............................11 [01] 1st Phone Number ............................... 11 [02] 1st Account Code ..............................11 [03] 2nd Phone Number .............................. 11 [04] 2nd Account Code ............................... 11 Reporting Codes [05] to [10] ............................11 [05] Zone Alarm Reporting Codes ..........................11 [06] Zone Restoral Reporting Codes ..........................

  • Page 5: Features

    FEATURES SPECIFICATIONS Keypad Programmable PC1500 Control Panel The PC1500 is complete with a default program so that it is • Six fully programmable zones operational with a minimum of programming. The control - EOL resistor supervised option panel is completely programmable from the keypad. - all zones programmable as fire zones.

  • Page 6: Installation

    INSTALLATION Mounting the Panel Wiring Chart PC1500RK Select a dry location close to an unswitched AC source and Wire Gauge Max. Run Length close to the telephone line connection. Remove the printed (AWG) Keypad to Panel circuit board, the mounting hardware and the keypad from the cardboard retainer inside the cabinet.

  • Page 7: Fire Zone Wiring

    Fire Zone Wiring Burglary Zone Wiring Any one of the 6 zones may be programmed as a Fire Zone. Burglary zone definitions (Delay, Instant, 24-Hour, etc.) are See Programming Guide Section [11]. programmed in Programming Section [11]. Smoke detectors should be the latching type and have N.O. alarm initiating contacts.

  • Page 8: Guidelines For Locating Smoke Detectors

    GUIDELINES FOR LOCATING SMOKE DETECTORS Experience has shown that all hostile fires in family living units generate smoke to a greater or lesser extent. Experiments using typical fires in family living units indicate that detectable quantities of smoke precede detectable levels of heat in most cases.

  • Page 9: Keypad Functions

    KEYPAD FUNCTIONS Introduction Auto-bypass/Home-away Arming The PC1500RK remote keypad provides complete information If a correct access code is entered, and you do not exit the premises, the system will, at the end of the Exit Delay time, and control of the PC1500 control panel. The panel can be arm with interior zones automatically bypassed if those fully programmed from the keypad.

  • Page 10: Trouble Conditions

    6. Loss of Time on System Clock ... When the PC1500 is To Bypass Zones: ∗ powered up or reset, the internal time of day clock needs to Enter [ ][1] - the “Bypass” light will start flashing. be reset to the correct time. The trouble is cleared after Enter [zone number to be bypassed];...

  • Page 11: Eeprom Reset

    Programming Access Codes Items [4], [5], [6] and [0] turn ON and OFF various features. ∗ When the item key is pressed and the feature is being turned Enter [ ][5][Master Code] to enter the access code ON, the keypad sounder will beep 3 times. If the feature is programming mode.

  • Page 12: Master Code]+[8]

    Bell Test Quick-Exit ∗ ∗ ∗ ∗ ∗ ∗ ∗ ∗ ∗ ∗ ]+[6]+[Master Code]+[8] ]+[0] when Armed ∗ Pressing [8] while in the User Function Command mode will Entering [ ][0] when the system is armed will allow the user sound the bell/siren, the keypad sounder and turn on all the to exit the premises through any delay zone without altering keypad lights for 2 seconds.

  • Page 13: Programming Guide

    PROGRAMMING GUIDE Introduction It is not necessary to program all 2-digit pairs in any given section. A section can be entered and selectively programmed The PC1500 is fully programmable from the keypad and uses by going only to the digit(s) you wish to change and then an EEPROM memory which can be reprogrammed thousands pressing [#] to return to the programming mode where you of times.

  • Page 14: Binary Data Display

    Binary Data Display Zone lights 1 through 4 are used to display the value, in binary format, of the data as shown in the table below. Hex Data Entry* Value Zone 1 Zone 2 Zone 3 Zone 4 Light On Light Off See Hex Data Entry instructions HEX Data Programming...

  • Page 15: Programming Sections

    PROGRAMMING SECTIONS [00] Binary Programming entered. The keypad beeps twice and the “Armed” light flashes after each 2-digit entry. After the last 2-digit number This section is normally used upon instruction from factory is entered, programming of the current section is complete. technical personnel for specialized programming not covered The keypad gives a series of beeps, the “Ready”...

  • Page 16: Closing (Arming) Reporting Codes Partial Closing Reporting Code

    [07] Closing (Arming) Reporting Codes [10] Maintenance Alarms and Restorals Partial Closing Reporting Code These reporting codes are used by the communicator to transmit the following list of alarms and restorals. See Section Reporting codes 1 to 6 are used to identify closings for [05] as a guide to programming.

  • Page 17: 1St System Option Code

    [2] Interior Zone is normally used with interior motion detectors products of combustion from the detectors and perform ∗ and has the standard Exit Delay time. The zone also has the a reset by pressing the [ ] then [7] keys. See Section standard Entry Delay time provided that a delay zone has [24] for programming the PGM terminal for smoke detector ∗...

  • Page 18: 2Nd System Option Code

    [13] 2nd System Option Code [15] Communication Variables Once this section is entered, two 2-digit numbers are Use the same method of programming as Section [12]. expected. Do not press the [#] key while entering data. The ZONE first 2-digit number defines the number of attempts (alarm LIGHT and restoral pairs) per zone that the communicator will [1] •...

  • Page 19: Auxiliary Delay Zone Entry / Exit Times

    [18] Auxiliary Delay Zone the only one being used. Entry / Exit Times [0] SILENT KNIGHT / ADEMCO SLOW 10 BPS This section requires two 3-digit entries to establish the (1400 Hz handshake) Auxiliary Entry and Exit Delay times. Do not press the [#] key 3/1, 4/1 and 4/2 non-extended formats during data entry.

  • Page 20: Programmable Output Options (Pgm Terminal)

    2. The zone alarm reporting codes must all be single digit [07] System Status (Armed / Disarmed) numerical codes with no extended 2nd round being sent The PGM output switches to and remains at ground as (i.e. Zone 1 = 10, Zone 2 = 20... Zone 6 = 60). The zero long as the panel is armed.

  • Page 21: Downloading Telephone Number

    [26] Downloading Telephone Number [32] 5th System Option Code This telephone number is used by the panel to call the Use the same programming method as in Section [12]. downloading computer when a request to call is make by ZONE ∗...

  • Page 22: For Future Use

    [91] Installer’s Lockout Disable Entering [91] when in the installer’s programming mode will disable the installer’s lockout feature. NOTE: Panels returned to DSC with the installer’s lockout feature enabled and no other apparent problems will be subject to an additional service charge.

  • Page 23: For The Record

    PC1500 Version 4.0 FOR THE RECORD Customer ___________________________________________________________________________________________________ Address ___________________________________________________________________________________________________ ___________________________________________________________________________________________________ Phone ___________________________________________ Installation Date _____________________________________ CONTACTS: #1 Name ___________________________________________ Phone ______________________________________________ #2 Name ___________________________________________ Phone ______________________________________________ #3 Name ___________________________________________ Phone ______________________________________________ Installer’s Code ______________________________________ ZONES Zone Type Protected Area _____________________________ __________________________________________________________________ _____________________________...

  • Page 24: Programming Work Sheets

    PC1500 Version 4.0 PROGRAMMING WORK SHEETS NOTE: In sections [01] to [10], do not enter data into sections that are not used. [01] 1st Phone Number Page 11 ∗ ∗ Enter [0] for the digit 0 in the phone number. Enter [ ] (HEX D) for additional dial tone detection between number digits, as in local PBX systems.
  • Page 25 PC1500 Version 4.0 [07] Closing (Arming) Reporting Codes / Partial Closing Reporting Code Page 12 Access Code 1 Access Code 2 Access Code 3 Access Code 4 Access Code 5 Access Code 6 Partial Closing Code [08] Opening (Disarming) Reporting Codes / After Alarm Reporting Code Page 12 The “after alarm”...
  • Page 26 PC1500 Version 4.0 [10] Maintenance Alarms and Restorals Page 12 For automatic test code reporting, time between reports (in days) must be specified in Section [17], and time of day for the report must be entered in Section [19]. NOTE: For UL installations, either AC failure or battery trouble reporting must be enabled. Low Battery Alarm AC Fail Alarm Fuse Failure Alarm...
  • Page 27 PC1500 Version 4.0 [13] 2nd System Option Code Page 14 Default Zone Light ON Zone Light OFF Zone Light 1 Call 1st phone only Backup to 2nd phone 1 1 1 1 1 Zone Light 2 Master Code not changeable Master Code changeable Zone Light 3 Bell Squawk enabled...
  • Page 28 PC1500 Version 4.0 [16] Zone Bypass Mask Page 14 ∗ If the zone light is ON, the zone can be bypassed using the [ ][1] command. If a zone is defined as a fire zone, it cannot be bypassed. Default Zone Light 1 Zone Light 2 Zone Light 3...
  • Page 29 PC1500 Version 4.0 [21] New Master Code Page 15 Default 1 2 3 4 [22] 2nd Master Code Page 15 ∗ The 2nd Master Code can be erased by entering [ 1111]. AAAA = not programmed Default A A A A [23] Communication Formats Page 15...
  • Page 30 PC1500 Version 4.0 [24] Programmable Output Options (PGM Terminal) Page 16 Enter 2 digits from “01” to “0C” only. Default Programmable Output [01] Ground Start Pulse ∗ [02] Utility Output, No Access Code - 5 seconds [ ] [7] ∗ [03] Utility Output, Any Access Code - 5 seconds [ ] [7] ∗...
  • Page 31 PC1500 Version 4.0 [28] Panel Identification Code Page 17 Default 1 5 0 1 This code confirms the panel’s identity to the downloading computer. [29] For Future Use Page 17 [30] Reset To Factory Default Page 17 [31] 4th System Option Code Page 17 Default Zone Light ON...
  • Page 32 [90] Installer’s Lockout Enable Page 18 [91] Installer’s Lockout Disable Page 18 WARNING! Panels returned to DSC with the Installer’s Lockout enabled and no other apparent problems will be subject to an additional service charge! Technical Manuals Online! - http://www.tech-man.com...

  • Page 33: Hookup Diagram

    Security detection devices that require power from control panel must be UL listed for the intended application and operate over the voltage range of 10.0 to 14.0 VDC. The DSC BRAVO series is a recommended UL listed motion detector. Technical Manuals Online! - http://www.tech-man.com...

  • Page 34: Limited Warranty

    LIMITED WARRANTY Digital Security Controls Ltd. warrants that for a period of liabilities on the part of Digital Security Controls Ltd. This twelve months from the date of purchase, the product shall warranty contains the entire warranty. Digital Security be free of defect in materials and workmanship under Controls Ltd.
  • Page 35 © 1994, 2002 Digital Security Controls Ltd. Toronto Canada • Tech Line: 1-800-387-3630 • www.dsc.com Technical Manuals Online! - http://www.tech-man.com...
  • Page 36 PC1500 V4.0 NOTICE OF SOFTWARE RELEASE The PC1500 Version 4.0 Software incorporates several new features and changes. The most impoartant additions are features designed to prevent false alarms caused by user error. False Alarm Reduction Features The following features have been added to reduce the number of false alarms caused by user error. Section [17] System Times System times now allow more than 4 minutes for the Entry or Exit delay to allow users more time to enter or leave the premises.
