and button are forwarded to the PC in all modes.
In "Computer" mode, the " " key toggles between lower and upper case charac-
ters and the "Alt" (green) and "Alt" (blue) keys activate and deactivate the num-
bers and special characters printed in the corresponding colors.
11.5.

11.5. aquaremote: Special functions in "VISION" mode

aquaremote: Special functions in "VISION" mode
11.5. 11.5. aquaremote: Special functions in "VISION" mode aquaremote: Special functions in "VISION" mode
During display mode, the keys „QWERTYUIOP" correspond to the configured in-
formation pages („Q" first page, „W" second page, ...).
The keys "ASDFGHJKL " can be assigned to commands.
11.6. 11.6.

11.6. aquaremote: Special functions in "Computer" mode

11.6. aquaremote: Special functions in "Computer" mode aquaremote: Special functions in "Computer" mode aquaremote: Special functions in "Computer" mode

11.7. aquaremote: Special functions in "Media" mode

11.7. aquaremote: Special functions in "Media" mode
11.7. 11.7. aquaremote: Special functions in "Media" mode aquaremote: Special functions in "Media" mode
© 2016
Three keys of the aquaremote select the mode of op-
eration: "VISION" mode is selected by pressing the
" " key, the " " key selects "Computer" mode and
"Media" mode can be selected by pressing the „TV"
key. The currently selected mode is displayed on the
VISION module display for approximately two seconds
after switching modes. The circular mouse control pad
Exit menu
One menu level up
↖
Previous
Next
Enter menu/confirm
OK
No function
≣
No function
↖
Context menu
≣
Cursor keys
Enter
OK
Page up/down
Menu navigation back
↖
Menu
≣
Next/previous track
Menu navigation up/down
OK Play/Pause
Menu +/-
+– Volume up/down/mute
