7.5. Settings of individual values

7.5. Settings of individual values
7.5. 7.5. Settings of individual values Settings of individual values
If the currently selected overview page is unlocked for editing, right-click an ele-
ment and select "Settings". You may also double click the element.
Font face, size and color as well as position, decimal places and unit can be con-
figured for individual values.
7.6.

7.6. Settings of control elements

7.6. 7.6. Settings of control elements Settings of control elements Settings of control elements
If the currently selected overview page is unlocked for editing, right-click an ele-
ment and select "Settings". You may also double click the element. Apart from po-
sition, size and color, the style of the element can be selected and configured. The
following styles are available:
Headline only: Compact display as a headline.
●
Text: Displays the numerical value in a box with a headline.
●
Bar graph: Displays numerical value as well as bar graph.
●
Chart: Displays the value in chronological sequence as a chart.
●
Gauge: Displays the value as a analog gauge.
●
All display styles offer extensive configuration options, additionally statistical data
such as minimum, maximum and average can be displayed.
7.7. 7.7. 7.7.

7.7. Custom controls: Images, text, drawing elements

Custom controls: Images, text, drawing elements Custom controls: Images, text, drawing elements Custom controls: Images, text, drawing elements
By using custom controls, simple drawing elements such as circles, rectangles and
texts as well as images and more sophisticated elements can be added to an over-
view page. To do so, add a "Custom control" to an overview page. Switch to the
"Display" tab in following dialog box, select the type of element to be created from
the drop down menu and confirm your selection by clicking the "Load preset" but-
ton. Depending on the type of element, an additional dialog may appear before
the code (XAML, Extensible Application Markup Language) of the new element is
displayed in the lower part of the dialog window. You may want to customize the
code. By clocking the "Ok" Button, the new control is saved to the overview page.
Example process to add an image: Select "Image" from the drop down menu and
click the "Load preset" button. Select an image file using the following file selec-
tion dialog. The code is then displayed in the lower part of the dialog window an
can be modified. Save the new control by clicking the "Ok" button. The picture
will be displayed on the overview page.
More complex controls such as data bindings and animations are also available
but will require some programming experience for configuration.
7.8. 7.8. 7.8.

7.8. Log data chart

Log data chart Log data chart Log data chart
This element can be used to display charts on overview pages. The charts have to
be created using the data log functionality of the aquasuite before they become
available for overview pages. Please refer to the next chapter for details. Once a
