FC 300 Instruction Manual

Adjust Display Contrast

"
Hold down [STATUS] and use the up or down navigation arrow to adjust the display contrast

How to Connect a PC to the FC 300

"
To control the adjustable frequency drive from a
PC, install the MCT 10 Setup Software.
The PC is connected via a standard (host/device)
USB cable, or via the RS-485 interface as
shown in the section Bus Connection in the
chapter How to Program.

The FC 300 Software Dialog

"
Data storage in PC via MCT 10 Set-Up Software:
Connect a PC to the unit via USB com port
1.
MCT 10 Set-up Software
2.
Choose "Read from drive"
3.
4. Choose "Save as"
All parameters are now stored.
30
How to Program
USB connection.
Data transfer from PC to drive via MCT
10 Set-Up Software:
1.
2.
3.
4.
5.
All parameters are now transferred to the drive.
A separate manual for MCT 10 Set-up
Software is available.
MG.33.A2.22 - VLT is a registered Danfoss trademark
Connect a PC to the unit via USB com port
MCT 10 Set-up Software
Choose "Open" - stored files will be shown
Open the appropriate file
Choose "Write to drive"
