Colour Television
Contents
2. Technical Specs, Diversity, and Connections
Cable dressing (39" 4109 series)
Cable dressing (47" 4109 series)
Cable dressing (50" 4109 series)
11. Styling Sheets
4109 series 24"
4109 series 28"
4109 series 32"
4109 series 39"
4109 series 47"
4109 series 50"
Published by CQZ/SC 1410 Quality
©
2014
TP Vision Netherlands B.V.
All rights reserved. Specifications are subject to change without notice. Trademarks are the
property of Koninklijke Philips Electronics N.V. or their respective owners.
TP Vision Netherlands B.V. reserves the right to change products at any time without being obliged to adjust
earlier supplies accordingly.
PHILIPS and the PHILIPS' Shield Emblem are used under license from Koninklijke Philips Electronics N.V.
Page
Contents
2
2
7
11
11
12
12
13
13
14
30
32
39
45
Drawing PWB
46
48-49
50
52-53
54
58-59
60
65-66
67
69-70
71
84-85
86
98-99
100
101
102
103
104
105
106
107
108
109
Printed in the Netherlands
Chassis
TPM14.1L
Page
Subject to modification
EN 3122 785 19621
LA
