- Page 1 MITRE SAW STOCK No.57491 PART No.MS560/3 •INSTRUCTIONS• IMPORTANT: PLEASE READ THESE INSTRUCTIONS THOROUGHLY BEFORE USE. UNDERSTANDING HOW THIS MACHINE WORKS AND SETTING IT CORRECTLY IS FUNDAMENTAL TO OBTAINING A SATISFACTORY RESULT. 06/99...
- Page 2 MITRE SAW TECHNICAL DATA Specification: Max. cutting width clamped at 45º.....100mm Max. cutting width clamped at 90º.....160mm ✗✌ Max. cutting width unclamped at 90º..110mm Max. cutting height........110mm Blade lengths ..........560mm Blade widths 18, 24 TPI.......40mm Bow saw .......20mm Table size ........76x348mm (WxL) Max.
- Page 3 The adjustable length stop ✕✗✌ can be mounted at either end of the saw table and set for the required length of cut. Replacement blades are available from your local Draper stockist; 18TPI - Stock No.57810, 24TPI - Stock No.57811, Bow Saw Blade - Stock No.57812.
- Page 4 ©Published by Draper Tools Ltd. No part of this publication may be reproduced, stored in a retrieval system or transmitted in any form or by any means, electronic, mechanical photocopying, recording or otherwise without prior permission in writing from Draper Tools Ltd.
