Santerno Sinus M Installation Instructions Manual

Sensorless vector control or v/f inverter for ac three-phase induction motors from 0.37 kw to 22.0 kw. 200-480 vac power supply
Hide thumbs Also See for Sinus M:
Table of Contents

Advertisement

Available languages

Available languages

Quick Links

See also: User Manual
This Manual covers basic information for the commissioning of the Sinus M VFDs.
Detailed information about installing and programming the Sinus M is given in the full User Manual
available for download from santerno.com.
 Always follow safety instructions to prevent accidents and potential hazards from occurring.
 In this manual, safety messages are classified as follows:
WARNING
CAUTION
 Keep operating instructions handy for quick reference.
 Read this manual carefully to maximize the performance of Sinus M series inverters and ensure safe usage.
 Do not remove the inverter cover while power is applied or the unit is operating.
Otherwise, electric shock could occur.
 Do not run the inverter with the front cover removed.
Otherwise, you may get an electric shock due to high voltage terminals or charged capacitor exposure.
 Do not remove the cover except for periodic inspections or wiring, even if the input power is not
applied.
Otherwise, you may access the charged circuits and get an electric shock.
 Wiring and periodic inspections should be performed at least 10 minutes after disconnecting the input
power and after checking the DC link voltage is discharged with a meter (below DC 30V).
Otherwise, you may get an electric shock.
 Operate the switches with dry hands.
Otherwise, you may get an electric shock.
 Do not use the cable when its insulating tube is damaged.
Otherwise, you may get an electric shock.
 Do not subject the cables to scratches, excessive stress, heavy loads or pinching.
Otherwise, you may get an electric shock.
Rev. 01 17/11/2016
15W0073BA100
Variable Frequency Drive
SAFETY INSTRUCTIONS
Improper operation may result in serious personal injury or death.
Improper operation may result in slight to medium personal injury or property damage.
SINUS M
NOTE
WARNING
INSTALLATION
INSTRUCTIONS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sinus M and is the answer not in the manual?

Questions and answers

Related Manuals for Santerno Sinus M

Summary of Contents for Santerno Sinus M

  • Page 1 CAUTION  Keep operating instructions handy for quick reference.  Read this manual carefully to maximize the performance of Sinus M series inverters and ensure safe usage. WARNING  Do not remove the inverter cover while power is applied or the unit is operating.

  • Page 2: Operating Precautions

    Follow your national electrical code for grounding. Recommended Ground impedance for 2S/T class (200-230V) is below 100Ω and for 4T class (380-480V) below 10Ω.  SINUS M series contains ESD (Electrostatic Discharge) sensitive parts. Take protective measures against ESD before touching the PCB for inspection or installation. ...
  • Page 3 (2) Wiring  Do not connect a power factor correction capacitor, surge suppressor, or RFI filter to the output of the inverter.  The connection orientation of the output cables U, V, W to the motor will affect the direction of rotation of the motor.

  • Page 4: Basic Information & Precautions

    Also make sure that the inverter is intact SINUS M series Inverter Type Part Number Input Power Ratings...
  • Page 5  Install in a location where temperature is within the permissible range (–10~50°C). <Surrounding Air Temp Checking Location>  The inverter will be very hot during operation. Install it on a non-combustible surface.  Mount the inverter on a flat, vertical and level surface. Inverter orientation must be vertical (top up) for proper heat dissipation.
  • Page 6 WIRING Terminal Wiring (Control I/Os) Description Specification Multi-function open collector < 26VDC,100mA MO Common 24V output Max current:100mA FX: Forward run MF input terminal (factory setting) RX: Reverse run Input signal common BX: Emergency stop MF input terminal (factory RST: Trip reset setting) JOG: Jog operation Input signal common...
  • Page 7 SINUS M 0025 4T 30.6/26.5 30.6/26.5 SINUS M 0030 4T 7.0mm *For Sinus M 0025 and Sinus M 0030, UL-approved Ring or Fork Terminals must be used. Grounding procedure • Remove the front cover. • Connect the Grounding wire to the ground terminal through the opening for ground terminal as shown above.
  • Page 8 CAUTION  Apply the rated torque to terminal screws. Loosen screws can cause short circuit and malfunction. Tightening the screws too much can damage the terminals and cause short circuit and malfunction.  Use copper wires only with 600V, 75°C ratings for wiring. ...

  • Page 9: Guida All'installazione

     Tenere sempre le istruzioni operative a portata di mano per la rapida consultazione.  Leggere questo manuale con attenzione per sfruttare appieno le prestazioni degli inverter della serie Sinus M in sicurezza ATTENZIONE ...

  • Page 10: Precauzioni Operative

    2S/T (200-230V) è inferiore a 100Ω e per la classe 4T (380-480V) è inferiore a 10Ω.  La serie SINUS M include delle parti sensibili alle scariche elettrostatiche (ESD). In caso di controllo o installazione, applicare delle misure contro le scariche elettrostatiche prima di toccare il PCB.
  • Page 11 Collegamenti  Non collegare condensatori di rifasamento, filtri di sovracorrente o filtri RFI ai circuiti d’uscita dell’inverter.  L’orientamento della connessione dei cavi di output (U, V, W) al motore influirà sulla direzione di rotazione del motore.  Un collegamento errato dei morsetti può danneggiare l’attrezzatura. ...

  • Page 12: Installazione

    SINUS M series Tipo di inverter Codice Alimentazione Uscita Contattare Elettronica Santerno qualora vengano riscontrati danni o differenze con l’apparecchiatura richiesta in fase d’ordine. Preparazione degli Gli strumenti e le parti che devono essere preparati dipendono dal funzionamento dell’inverter. strumenti e delle Preparare l’attrezzatura e le parti nel modo necessario.
  • Page 13  Installarlo in un luogo in cui la temperatura sia compresa entro i limiti consentiti (–10~50°C). <Posizioni per il controllo della temperatura ambiente>  L’inverter raggiunge temperature elevate durante il funzionamento. Installarlo su una superficie non infiammabile.  Montare l’inverter su una superficie livellata, verticale e piana. Per consentire una corretta dissipazione del calore, l’inverter deve essere orientato in senso verticale (la parte superiore verso l’alto).
  • Page 14 COLLEGAMENTI Collegamento dei morsetti di comando (I/O) Descrizione Specifica Uscita multifunzione (open collector) < 26VDC,100mA Comune MO Uscita 24V Corrente max:100mA Mors. ingr. MF FX: Marcia avanti (impost. RX: Marcia indietro fabbrica) Comune segnale d’ingresso BX: Arresto emergenza Mors. ingr. MF (impost.
  • Page 15 SINUS M 0025 4T SINUS M 0030 4T 30.6/26.5 7.0mm * Per Sinus M 0025 e Sinus M 0030 occorre utilizzare puntali ad anello o a forchetta omologati UL. Procedura di messa a terra • Rimuovere il coperchio anteriore. •...
  • Page 16 AVVERTENZA  Applicare la coppia nominale alle viti dei morsetti. Viti troppo lente possono danneggiare i morsetti e causare cortocircuiti e malfunzionamenti.  Per il collegamento, usare fili in rame da 600V, 75°C.  Prima di eseguire il collegamento, assicurarsi che l’inverter non sia alimentato. ...
