ASA 4.0 Advanced
Issued on 01/08/18
R. 01
This manual is integrant and essential to the product. Carefully read the instructions contained herein as
•
they provide important hints for use and maintenance safety.
This device is to be used only for the purposes it has been designed to. Other uses should be
•
considered improper and dangerous. The manufacturer is not responsible for possible damages caused
by improper, erroneous and irrational uses.
Enertronica Santerno is responsible for the device in its original setting.
•
Any changes to the structure or operating cycle of the device must be performed or authorized by the
•
Engineering Department of Enertronica Santerno.
Enertronica Santerno assumes no responsibility for the consequences resulting by the use of
•
non-original spare parts.
Enertronica Santerno reserves the right to make any technical changes to this manual and to the device
•
without prior notice. If printing errors or similar are detected, the corrections will be included in the new
releases of the manual.
The information contained herein is the property of Enertronica Santerno and cannot be reproduced.
•
Enertronica Santerno enforces its rights on the drawings and catalogues according to the law.
Tel. +39 0542 489711
- 15V0093B100 -
S OFT STARTER
2 8 B
QUICK SETUP
Enertronica Santerno S.p.A.
Via della Concia, 7 - 40023 Castel Guelfo (BO) Italy
www.santerno.com -
–
Fax +39 0542 489722
info@santerno.com
Advertisement
Table of Contents
Related Manuals for Santerno ASA 4.0 Advanced
Summary of Contents for Santerno ASA 4.0 Advanced
- Page 1 • non-original spare parts. Enertronica Santerno reserves the right to make any technical changes to this manual and to the device • without prior notice. If printing errors or similar are detected, the corrections will be included in the new releases of the manual.
-
Page 2: Table Of Contents
Keypad and Feedback ............................ 12 The Keypad ..............................12 Starter status LEDs ............................. 13 Operation ................................. 13 Start, Stop and Reset Commands ......................13 Programmable Parameters ..........................14 Parameter List.............................. 14 Specifications ..............................19 Disposal Instructions ........................... 20 ASA 4.0 Advanced... -
Page 3: About This Manual
A bout This Manual CAUTION This manual provides brief information to assist in installing and operating the ASA 4.0 Advanced in simple applications. For comprehensive information on installing and operating the ASA 4.0 Advanced, refer to the ASA 4.0 Advanced User Manual (available from santerno.com). -
Page 4: Caution Statements
Many internal parts of the starter SHORT CIRCUIT The ASA 4.0 Advanced is not short circuit proof. After severe overload or short circuit, the operation of the ASA 4.0 Advanced should be fully tested by an authorised service agent. GROUNDING AND BRANCH CIRCUIT PROTECTION It is the responsibility of the user or person installing the ASA 4.0 Advanced to provide proper... -
Page 5: Avertissements À L'attention Des Clients Canadiens
(par exemple, un arrêt d'urgence, un détecteur de défaut). AVERTISSEMENT – LE DÉMARREUR PEUT DÉMARRER OU S'ARRÊTER À TOUT MOMENT L’ASA 4.0 Advanced répond aux commandes de contrôle de différentes origines et peut par conséquent démarrer ou s'arrêter à tout moment. Toujours déconnecter le démarreur de la tension secteur avant d'accéder au démarreur ou à... - Page 6 Toujours appliquer la tension de commande avant (ou en même temps que) la tension secteur. AVERTISSEMENT Lors du raccordement de l’ASA 4.0 Advanced en connexion 6 fils, toujours installer un contacteur principal ou un disjoncteur magnéto-thermique à bobine de déclenchement.
-
Page 7: System Design
M odel Code 1 3 B ASA4.0-A – Control voltage 12 = 110~120 VAC or 220~240 VAC 14 = 24 VAC/VDC Mains voltage 5 = 200~525 VAC 7 = 380~690 VAC Bypass B = internally bypassed Nominal current rating ASA 4.0 Advanced... -
Page 8: Installation
Connect the motor cables to starter output terminals 2/T1, 4/T2, 6/T3. 10. Connect mains supply cables to starter input terminals 1/L1, 3/L2, 5/L3 (refer to Power Terminations on page 9). The soft starter is now ready to control the motor. ASA 4.0 Advanced... -
Page 9: Physical Installation
For models ASA4.0-A 0184B to ASA4.0-A 0580B to be UL compliant, supplementary or branch overcurrent protection must be used on the control circuit supply (A1, A2, A3), in accordance with the electrical code applicable at the installation location. ASA 4.0 Advanced... -
Page 10: Power Terminations
P ower Terminations 1 7 B The power input and output terminals for ASA 4.0 Advanced are at the bottom of the unit. Models ASA4.0-A 0024B~ASA4.0-A 0135B use cage clamps. Use only copper stranded or solid • conductors, rated for 75 ºC or higher. -
Page 11: Typical Installation
T ypical Installation 1 8 B The ASA 4.0 Advanced is installed with a main contactor (AC3 rated). Control voltage must be supplied from the input side of the contactor. The main contactor is controlled by the main contactor output (33, 34). -
Page 12: Quick Setup
Q uick Setup 1 9 B The Quick Setup Menu makes it easy to configure the ASA 4.0 Advanced for common applications. The ASA 4.0 Advanced guides you through the most common installation parameters, and suggests a typical setting for the application. -
Page 13: Keypad And Feedback
Soft starter local control buttons Shortcut buttons for quick access to common tasks. LOGS: Open the Logs Menu. GRAPHS: Select which graph to view, or pause/restart the graph (hold longer than 0.5 seconds) TOOLS: Open the Setup Tools. ASA 4.0 Advanced... -
Page 14: Starter Status Leds
S tart, Stop and Reset Commands 2 2 B The ASA 4.0 Advanced can be started and stopped via the digital inputs, remote keypad, communication network, smart card or scheduled auto-start/stop. The command source can be set via the Setup Tools, or using parameter 1A Command Source. -
Page 15: Programmable Parameters
00:00 (mm:ss) Stop Time-2 Adaptive Stop Profile-2 Constant Deceleration Adaptive Control Gain-2 Single Pump Multi Pump-2 00:00 (mm:ss) Start Delay-2 DC Brake Torque-2 00:01 (mm:ss) DC Brake Time-2 250% Brake Current Limit-2 Soft Brake Delay-2 400 ms ASA 4.0 Advanced... - Page 16 Any Sequence Phase Sequence Protection Actions Auto-Reset Count 00:05 (mm:ss) Auto-Reset Delay Soft Trip and Log Current Imbalance Soft Trip and Log Undercurrent Soft Trip and Log Overcurrent Undervoltage Soft Trip and Log Overvoltage Soft Trip and Log ASA 4.0 Advanced...
- Page 17 Analog A Minimum Adjustment Display English Language Temperature Scale Celsius 30 seconds Graph Timebase 400% Graph Maximum Adjustment Graph Minimum Adjustment 100% Current Calibration Read & Write Adjustment Lock Current User Parameter 1 User Parameter 2 Motor Voltage ASA 4.0 Advanced...
- Page 18 Pressure Units Pressure at 4 mA Pressure at 20 mA None Flow Sensor Type litres/second Flow Units Flow at 4 mA Flow at 20 mA Units per Minute at Max Flow Pulses per Minute at Max Flow ASA 4.0 Advanced...
- Page 19 High Pressure Soft Trip and Log Low Pressure Soft Trip and Log High Flow Soft Trip and Log Low Flow Soft Trip and Log Flow Switch Soft Trip and Log Well Depth Soft Trip and Log RTD/PT100 B ASA 4.0 Advanced...
-
Page 20: Specifications
ASA4.0-A 0352B~ASA4.0-A 0580B ................≤ 140 watts approx M otor Overload Protection 3 6 B Default: The default settings of parameters 1D, 1E and 1F provide Motor Overload Protection: Class 10, Trip Current 105% of FLA (full load amperage) or equivalent. ASA 4.0 Advanced... -
Page 21: Disposal Instructions
Marine ........................Lloyds Marine No 1 Specification D isposal Instructions 2 4 B Equipment containing electrical components may not be disposed of together with domestic waste. It must be collected separately as electrical and electronic waste according to local and currently valid legislation. ASA 4.0 Advanced...
