DEVICENET MODULE
Issued on 15/06/12
R. 01
This manual is integrant and essential to the product. Carefully read the instructions contained herein as they provide
important hints for use and maintenance safety.
This device is to be used only for the purposes it has been designed to. Other uses should be considered improper and
dangerous. The manufacturer is not responsible for possible damages caused by improper, erroneous and irrational uses.
Elettronica Santerno is responsible for the device in its original setting.
Any changes to the structure or operating cycle of the device must be performed or authorized by the Engineering
Department of Elettronica Santerno.
Elettronica Santerno assumes no responsibility for the consequences resulting by the use of non-original spareparts.
Elettronica Santerno reserves the right to make any technical changes to this manual and to the device without prior
notice. If printing errors or similar are detected, the corrections will be included in the new releases of the manual.
The information contained herein is the property of Elettronica Santerno and cannot be reproduced. Elettronica Santerno
enforces its rights on the drawings and catalogues according to the law.
Contents
1.
Important User Information ...................................................................................................................................... 2
2.
Installation .................................................................................................................................................................. 2
3.
Configuration ............................................................................................................................................................. 3
4.
Adjustment ................................................................................................................................................................. 3
5.
Connections ............................................................................................................................................................... 4
6.
LEDs ............................................................................................................................................................................ 4
7.
DeviceNet Polled I/O Structure ................................................................................................................................. 5
8.
Trip Codes .................................................................................................................................................................. 6
9.
Parameter Object ....................................................................................................................................................... 7
10.
Specifications ............................................................................................................................................................ 7
- 15G0078B120 -
INSTRUCTIONS
FOR ASAC-0/ASAC-1/ASAB
Elettronica Santerno S.p.A.
S.S. Selice, 47 - 40026 Imola (BO) Italy
Tel. +39 0542 489711
www.santerno.com, sales@santerno.com
-
Fax +39 0542 489722
Advertisement
Table of Contents
Related Manuals for Santerno ASAC-0
Summary of Contents for Santerno ASAC-0
-
Page 1: Table Of Contents
Elettronica Santerno reserves the right to make any technical changes to this manual and to the device without prior notice. If printing errors or similar are detected, the corrections will be included in the new releases of the manual. -
Page 2: Important User Information
Important User Information Observe all necessary safety precautions when controlling the soft starter remotely. Alert personnel that machinery may start without warning. It is the installer's responsibility to follow all instructions in this manual and to follow correct electrical practice. Installation CAUTION Remove mains and control voltage from the soft starter before attaching or removing accessories. -
Page 3: Configuration
The soft starter must be added to the DeviceNet manager project using the EDS file and configuration/management software tool. This file is available from santerno.com. In order to operate successfully, the correct EDS file must be used. An on-screen graphics bitmap file (device.bmp) is also available. -
Page 4: Connections
Connections ASAC ASAB Rd Wh Bu Bk ASAC ASAB (Remote mode) A1, 02: Stop 56, 57: Stop 58, 57: Reset DeviceNet Module DeviceNet Module Standard connection onto DeviceNet network Standard connection onto DeviceNet network ASAC: For the DeviceNet Module to accept serial commands, a link must be fitted across terminals A1-02 on the soft starter. ASAB: Input links are required across the stop and reset inputs if the soft starter is being operated in Remote mode. -
Page 5: Devicenet Polled I/O Structure
DeviceNet Polled I/O Structure Once the EDS file has been loaded, the DeviceNet Module must be added to the scanner list with parameters shown in the following table: Parameter Value I/O connection type Polled Poll receive size 14 bytes Poll transmit size 2 bytes Once the soft starter, module and Master have been set up, configured and powered up, the Master will transmit 2 bytes of data to the module and receive 14 bytes of data from the module. -
Page 6: Trip Codes
4 to 7 Reserved For models ASAB-0053B and smaller this value will be 10 times greater than the value displayed on the keypad. Trip Codes Code Trip Type ASAC-0 ASAC-1 ASAB No trip Input A trip/Auxiliary Trip A Motor overload (thermal model) -
Page 7: Parameter Object
Internal Fault x The table below details the internal fault code associated with trip code 104. Internal fault Message displayed on the keypad 70 ~ 72 Current Read Err Lx Internal fault X Contact your local supplier with the fault code (X). 74 ~ 76 Motor Connection Tx 77 ~ 79... - Page 8 DeviceNet Module...
