6.5 Utilities

6.5.1 Embedded
Curve Handler™
Security Settings: provides a means of changing the website security settings by
allowing the user to enter a new username and password for the website, or to
remove password protection from the website. The username and password parame-
ters are available for viewing and editing from the front panel under the Modify IP
Config submenu of the Interface menu.
Password protection only protects access to the embedded web pages and does not pro-
vide any kind of security for TCP Socket access (section 6.4.3).
The website username and password are available from the front panel menu, and there-
fore can easily be obtained by anyone with access to the Model 336 front panel.
Contact Us: provides information regarding how to contact representatives of
Lake Shore Cryotronics, Inc.
The utilities embedded on the Model 336 are written using the Java™ programming
language. This theoretically allows the applications to run properly on many different
platforms (Windows®, Mac®, Linux™, etc.), although the applications are only sup-
ported on Microsoft Windows® XP or Windows 7 and Vista®, and have been designed
to work with the Java™ Runtime Environment (JRE) version 1.6. To download Java ™
JRE please visit www.java.com.
Please note that without the proper JRE installed the utilities will not run properly.
The applications are launched from the Utilities web page using Java™ Web Start
technology. This allows the application to run outside of the web browser in a stand-
alone window. The application can only be launched using the link in the embedded
web page, and cannot be permanently installed. When launching the application,
multiple security warning messages may appear. These messages are meant to pro-
tect youfrom malicious software that can cause harm to, or compromise the security
of, your computer or your data. The applications have been thoroughly tested and are
considered by Lake Shore to be safe.
All software is imperfect and any software may be used by a malicious user for malicious
purposes.
The Embedded Curve Handler™ utility is provided for uploading temperature curve
files to the Model 336. The utility is also capable of reading curves from the
Model 336 and writing them to a file for storage, or manipulation in a third party pro-
gram. The Embedded Curve Handler™ supports standard Lake Shore temperature
curve files in the ".340" file format, and the Microsoft Excel® ".XLS" (Excel® 97 - 2003)
file format. Curve files are provided with calibrated sensors purchased from
Lake Shore in the ".340" file format.
To read a temperature curve from a file:
ted temperature curve (*.340 or *.XLS) file using the Open Browser dialog box. The
curve will be loaded into the program and the curve points and graph will be dis-
played.
To read a temperature curve from the Model 336:
Read Curve from Instrument dialog box appears. Select a curve from the drop-down
box and click OK. The curve will be loaded into the program and the curve points and
graph will be displayed.
Once a curve is loaded into the Embedded Curve Handler™ using either the Read
from File or Read from Instrument buttons, the loaded curve can be stored either to a
user curve location (21 to 59) in the Model 336, or to a file.
click Read from File. Select a properly format-
click Read from Instrument. The
