- Page 1 BW31PTZ Optional Camera for BW345xR Series Baby Monitoring Series For more exciting new products please visit our website: Australia: www.uniden.com.au...
-
Page 2: What's In The Box
WHAT’S IN THE BOX? AC Adaptors Bracket Camera Owner’s Manual Screws & Anchors • If any item is missing or damaged, contact your place of purchase immediately. Never use damaged products! • Need help? Get answers at our website: www.uniden.com.au for Australian model INSTALLATION CAMERA INSTALLATION The BW31PTZ camera comes with a mounting bracket. With it installed, you can mount the camera on the wall. Placement Considerations • The camera included with your monitor is NOT weatherproof; it is an indoor camera. • The clearest line-of-sight between the camera and monitor is best. Walls, especially brick and concrete, can affect reception quality. • Avoid having a direct light source in view of the camera (ceiling or floor lamps). • Carefully plan where and how the camera will be positioned, and where you will route the cable that connects the camera to the power adaptor. • When you are positioning the camera, bring the monitor along; it’s much easier to get the camera into the right position when you have the display handy. Check the image on the monitor before you install the camera. -
Page 3: Basic Operation
BASIC OPERATION WIRELESS CAMERA Item What it does Light sensor: Measures light intensity on the camera side. Lens: Camera lens. Microphone: Receives sounds for the area near the camera, and transmits sound from the camera to the monitor. Temperature sensor: Detects temperature at camera side and displays it on the monitor LCD. Power Switch: Turns the camera ON or OFF. Volume Switch: Turn to increase or decrease volume. Camera Antenna: Sends and receives signals to or from the monitor. DC 5V Power: Connects the DC 5V power adaptor to the camera. PAIR: Pairs the camera to the monitor. Ceiling/Wall flip switch: Slide the switch to rotate the camera view depending on where the camera is mounted (wall or ceiling). -
Page 4: Pairing The Camera
PAIRINg THE CAMERA Pairing allows you to introduce additional cameras to the monitor (not included). The monitor can then recognize and display video from them. Before pairing additional cameras, be sure they are powered and turned on. 1. On the monitor select Pair from the Camera options screen. The camera selection screen displays. 2. Press ▲Vol or ▼Vol or toggle the Joy Stick to select the camera you want to pair, then press the JOY STICK (OK). The monitor prompts you to press the PAIR button on the bottom of the camera within 30 seconds. 3. Press PAIR button on the bottom of the camera within 30 seconds. 4. That camera’s video displays on the monitor when pairing is successful. -
Page 5: Specification
SPECIfICATION GENERAL Operating Frequency Range 2.400 ~ 2.4835GHz TX Power 15dBm RX Sensitivity Type of Spread Spectrum Used FHSS Type of Modulation Used GFSK Communication Range 150ms Line of Sight Effective Pixel 640 x 480 Image Processing MJPEG Lens 3.0mm / F2.8 Exposure Auto White Balance Auto Power Requirement 5.0VDC +/-5% Power Consumption 300mA Max (IR OFF) 450mA Max (IR ON) Operating Temperature Range –10°C ~ 40°C (14°F ~ 104°F) Operating Humidity Rance Withing 80% Relative Humidity Housing Material Plastic... -
Page 6: One-Year Limited Warranty
BW31PTZ IMPORTANT Satisfactory evidence of the original purchase is required for warranty service. Please refer to our Uniden website for any details or warranty durations offered in addition to those contained below. Warrantor The warrantor is Uniden Australia Pty Limited ABN 58 001 865 498 (“Uniden Aust”). Terms of Warranty Uniden Aust warrants to the original retail purchaser only that the BW31PTZ (“the Product”), will be free from defects in materials and craftsmanship for the duration of the warranty period, subject to the limitations and exclusions set out below. Warranty Period This warranty to the original retail purchaser is only valid in the original country of purchase for a Product first purchased either in Australia or New Zealand and will expire, as indicated below, from the date of original retail sale. Product... - Page 7 COMPETITION AND CONSUMER ACT 2010 (Australia) or the CONSUMER GUARANTEES ACT (New Zealand) as the case may be, none of which can be excluded. Procedure for Obtaining Warranty Service Depending on the country in which the Product was first purchased, if you believe that your Product does not conform with this warranty, you should deliver the Product, together with satisfactory evidence of your original purchase (such as a legible copy of the sales docket) to Uniden. Please refer to the Uniden website for address details. You should contact Uniden regarding any compensation that may be payable for your expenses incurred in making a warranty claim. Prior to delivery, we recommend that you make a backup copy of any phone numbers, images or other data stored on your Product, in case it is lost or damaged during warranty service. UNIDEN AUSTRALIA PTY LTD Phone number: 1300 366 895 Email address: custservice@uniden.com.au...
- Page 8 ©2016 Uniden Australia Pty Ltd Printed in PRC...
