CleanFreak TPL-17-220-CE-HEAT-TCP Operator's Manual page 11

TPL-17-220-CE-HEAT-TCP
ITEM DESCRIPTION
1 F11787-1BWG Solution Tank,
2 F11788-1BWG Recovery Tank
3 F11791-1BWG Lid, Sol Tank, Galaxy Pro
4 C11167 Screw, .25 - 20 X .75,SS
5 K02714 Plug, .500
6 A00060 3-8 Barb X 1-4MP, Brass
7 A00052 90 Elbow, .25MP X .25FP
8 C11244 Washer, .56 X 1.5 X .05
10 E11836 Gasket, Galaxy Pro Lid
11 12906A Stand Pipe Assembly, Galaxy Pro
A K11965 Elbow, 180 Deg. Float Ball
B K00672 Pvc Pipe, 1.5 X 14.75 in, Sch 40
Wht
C K00741 Adapter, Male, 1.5 in Sch 40
D 10989-2A Float Ball Screen
12 F11785-1BWG Lid, Recovery
13 B11769 Extension Cord, 12-3 SJTW
14 C11177 Velcro Strap
15 H02548-2 Label, Important, Cord
16 B00185-30 Wires, 73 in
17 B00185-40 Wires, 73 in
18 B010314 Wire Harness
19 F11786-1BWG Handle, 17 Gal
20 B00177 Terminal Lug, Female, QD, .25 X
.032, 16-14 AWG, Fully Insulated
21 B00185-40 Wire,14 GA Black, UL1015, 10
in
22 C00295-1 #10 X .75in Pan, Black SMS,
Phillips
23 C00293 #8 X .5in Pan, Black SMS, Phillips
24 D11168 Cover, Switchplate, Galaxy
25 B02211-1 Switch, Rocker, Green Light
26 D010284 Switchplate
17-150-CE-HEAT-TC
UPPER
UPPER
QTY
1
1
1
6
4
1
1
1
1
1
1
1
1
1
1
2
2
2
2
2
1
1
4
1
2
2
1
3
1
ITEM DESCRIPTION
27 E010453 Gasket, Switchplate
28 B00177-1 Terminal Lug, Female, QD, .25 X
.032
29 B00185-30 Wire,14 GA White, UL1015, 10
in
30 C02315 Lockwasher, #10 Int. Str, SS
31 C00264 Nut, 10-32
32 C00288-1 .25-20 X 2.25 Flat Head
33 C00288 .25-20 X 1.5 Flat Head
34 K00665-1 Hose Adapter, 1.5in, Black
36 C00314-1 Hex Bolt, .25 X 20 X 1, Zinc
37 C00233 Washer, Flat, .25 in
38 C00313 Hex Bolt, .25 X 20 X .75 SS
39 C02312 Lockwasher, .25 in., Internal Star
40 D010283 Plate, Heater Mounting
41 F11804 Heater Mount
42 C00261 Nut, .25-20, Hex
43 K00710 Elbow, Drain Valve, Black
44 K00711 Drain Valve, Black
45 E11128 Gasket, Drain Valve
46 C12110 Hex Bolt, .375-16 X 1.75
47 C11540 Washer, .375 ID X .875 OD
48 K00741 Adapter, Male, 1.5 in Sch 40
49 K00672-1 Pvc Pipe, 1.5 X 2.25 in, Sch 40
Wht
50 A90004 .50 Barb X .25 MP, Brass
51 D00373 Inlet Filter, .25 NPT
52 A00124 Hex Nut, .25 NPT Brass
53 C11144 Screw, .25-20 X 2, SS
54 S11179 Non-Skid Tape, 1 in. Roll
55 C00238 Washer, .275 in, Neosteel
11
QTY
1
2
1
2
1
4
4
1
4
6
2
2
1
1
2
1
1
2
2
2
1
1
1
2
2
2
1
2
