Specifications

General Specifications

Display
Measurements
UVA, UVC selection
UV Sensor spectrum
UV sensor
UV light zero adjust
Data storage/recall
Datalogger
Memory SD card
Temperature compensation
Display sampling rate
Data output
Operating Temperature
Operating Humidity
Power Supply
Power Consumption
Weight
Dimensions
Accessories included
Optional Accessories
Backlit LCD size: 52 mm x 38 mm (2.0 x 1.5")
UV light, UVA and UVC
Type K or J thermocouple temperature
Front push-button
UVA (390 – 280nm), UVC (280 – 240nm)
Exclusive photo sensor with cosine correction filter
Push-button
Records Max and Min readings with recall
Auto 1 second to 3600 second sample rate
Manual Button press (sample rate set to '0')
1G to 16GB SD Card (for best results use a 4GB or smaller card)
Auto compensation for the Type K/J thermocouple thermometer
1 second approx.
RS-232/USB PC interface
0 o C to 50 o C (32 o F to 122
Less than 85% RH
Alkaline 1.5V AA batteries x 6
or 9V AC adaptor (UA100-240)
Normal operation (without SD storing and with display backlight
OFF): 6.5mA DC approx.
With SD card storing but display backlight OFF: 30mA DC approx.
With the LCD backlight ON the power consumption increases by
16mA DC approx.
Meter: 351g (11.3 oz.); UVA Probe: 100g (3.2 oz.); UVC Probe:
103g (3.3 oz.)
Meter: 177 x 68 x 45mm (7.0 x 2.7 x 1.8")
UVA Probe head: 45 mm diameter x 32 mm (1.8 dia. x 1.3")
UVA Probe handle: 125 x 24 mm diameter (5.0 x 0.9" dia.)
UVC probe: 38mm diameter x 25 mm (1.5 dia. x 1.0")
Instruction manual, UVA light sensor, UVC light sensor, hard-shell
carrying case, batteries, 9V AC adapter, and user guide
Type K thermocouple probe, USB cable (407001-USB) and data
acquisition software (407001)
13
o F)
SDL470-en-GB_v1.4 3/17
