Reporting Commands; Clear And Reset Commands; Parameter Setting Commands - Rice Lake 720i Installation Manual

10.1.2

Reporting Commands

Reporting commands send specific information to the
serial port. The commands listed in Table 10-2 can be
used in both setup mode and normal mode.
Command
DUMPALL List all parameter values
DUMPAUDIT List audit trail information
SPDUMP
Print
PCEE
VERSION
Write
720i
HARDWARE Lists installed
Section 11.1.2 on page 99 for more
information about using the HARDWARE
command.
XE Returns a 10-digit code representing any
error conditions currently shown on the
front panel.
page 100 for more information.
Table 10-2. Reporting Commands
10.1.3

Clear and Reset Commands

The following commands can be used to clear and reset
the :
720i
: Reset system. Resets the indicator without
RS
resetting the configuration.
RESETCONFIGURATION
parameters to their default values (setup mode
only). The
RESETCONFIGURATION
also be initiated by pressing the
softkey under the VERSION menu. Use the
to select
Clear entire indicator configuration
to reset the indicator.
Enter
All load cell calibration settings are lost when
the RESETCONFIGURATION command is run.
Command
SC.GRADS#1 Graduations
SC.SPLIT#1 Multi-range or multi-interval scale type
SC.ZTRKBND#1 Zero track band
SC.ZRANGE#1 Zero range
SC.MOTBAND#1 Motion band
SC.SSTIME#1 Standstill time
SC.OVRLOAD#1 Overload
SC.WMTTHRH#1 Weighment threshold
SC.NUMWEIGH#1 Number of weighments
SC.MAX_WEIGHT#1 Maximum weight
SC.DIGFLTR1#1 Digital filtering
SC.DIGFLTR2#1
SC.DIGFLTR3#1
SC.DFSENS#1 Digital filter cutout sensitivity
Function
configuration
software version
option cards. See
See Section 11.1.5 on
: Restores all configuration
function can
Reset Config
up
, then press
Description
Table 10-3. SCALES Serial Commands
10.1.4

Parameter Setting Commands

Parameter setting commands allow you to display or
change the current value for a particular configuration
parameter (Tables 10-3 through 10-10).
Current configuration parameter settings can be
displayed in either setup mode or normal mode using
the following syntax:
Most parameter values can be changed in setup mode
only.
Use the following command syntax when changing
parameter values:
is either a number or a parameter value. Use no spaces
before or after the equal (=) sign. If you type an
incorrect command, the display reads
For example, to set the motion band parameter on Scale
#1 to 5 divisions, type the following:
SC.MOTBAND#1=5<ENTER>
For parameters with selectable values, enter the
command and equal sign followed by a question mark:
command=?<ENTER>
indicator must be in setup mode to use this function.
Some parameters are valid only if other
parameters or parameter values are specified.
See the configuration menus in Section 3.2 on
page 20 for information about parameter
dependencies. Restrictions for front-panel
configuration also apply to serial command
configuration.
key
1–9999999
OFF, 2RNG, 3RNG, 2INTVL, 3INTVL
0, 0–100
1.900000, 0–100
1, 0–100
1–65535
FS+2%, FS+1D, FS+9D, FS
grads
—
—
1, 2, 4, 8, 16, 32, 64, 128, 256
2OUT, 4OUT, 8OUT, 16OUT, 32OUT, 64OUT, 128OUT
command<ENTER>
, where
command=value<ENTER>
.
??
to see a list of those values. The
Values
Serial Commands
value
