Analog output

Parameter
Resolution
Output range
Number of channels
Throughput (Note 4)
Power on and reset voltage
Output drive
Slew rate
Maximum throughput when scanning is machine dependent.
Note 4:
Table 9. Analog output accuracy, all values are (±); accuracy tested at no load
Range
0 V to 5.0 V
Range % of FSR
0 V to 5.0 V 0.1 typ, 0.9 max
Zero-scale offsets may result in a fixed zero-scale error producing a "dead-band" digital input code
Note 5:
region. In this case, changes in digital input code at values less than 0x040 may not produce a
corresponding change in the output voltage. The offset error is tested and specified at code 0x040.

Digital input/output

Parameter
Digital type
Number of I/O
Configuration
Pull up/pull-down configuration
Input high voltage threshold
Input high voltage limit
Input low voltage threshold
Input low voltage limit
Output high voltage, Port A
Output low voltage, Port A
Output high voltage, Port B
Output low voltage, Port B
Power on and reset state
Table 8. Analog output specifications
Condition
Software paced
Hardware paced
Each D/A OUT
Accuracy (LSB)
4.0 typ, 45.0 max
Table 10. Analog output accuracy components, all values are (±)
Gain Error at FS (mV)
4.0 typ, 36.0 max
Table 11. Digital I/O specifications
Specification
CMOS
16 (Port A0 through A7, Port B0 through B7)
2 banks of 8. Port B is high current drive.
All pins pulled up to 5V via 47 kΩ resistors (default). Change to pull-down using
internal user-configurable jumpers.
2.0 V min
5.5 V absolute max
0.8 V max
–0.5 V absolute min
0 V recommended min
4.4 V min (IOH = –20 µA)
3.84 V min (IOH = –6.0 mA)
0.1 V max (IOL = 20 µA)
0.33 V max (IOL = 6.0 mA)
4.4 V min (IOH = –50 µA)
3.76 V min (IOH = –24.0 mA)
0.1 V max (IOH = 50 µA)
0.44 V max (IOH = 24.0 mA)
Input
Specification
12-bits, 1 in 4,096
0 V to 5.0 V
2
250 S/s single channel typ, PC dependent
50 kS/s max per channel
Initializes to 000h code
5 mA, sourcing
0.8 V/ µs typ
Offset (mV)
(Note 5)
1.0 typ, 9.0 max
23
Specifications
Accuracy at FS (mV)
4.0 typ, 45.0 max
