1 Quick Guide
1
Set reference range
Min. reference, Ref
Max. reference, Ref
Set ramp time
Ramp-up time [s]
Ramp-down time [s] Parameter 208
In parameter 002,
operation
Set the control location to
Local/remote operation =
Set the motor speed by adjusting the
Local reference
Local reference, Par. 003
1.6 Motor Start
Press [START] to start the motor. Set the motor speed by adjusting par. 003,
Check whether the direction of rotation of the motor shaft is clockwise. If not, exchange any two
phases on the motor cable.
Press [STOP/RESET] to stop the motor.
Press [QUICK MENU] to return to display mode.
[QUICK MENU] + [+] keys must be pressed simultaneously to give access to all parameters.
Phone: 800.894.0412 - Fax: 888.723.4773 - Web: www.clrwtr.com - Email: info@clrwtr.com
NB!
VLT 2880-2882 do not have the AMT function.
Parameter 204
MIN
Parameter 205
MAX
Parameter 207
Local/remote control
[0], i.e. via the control terminals, or
Local
[1]
Local
[1], Par. 002
, the frequency converter mode can be selected as
Local
[1], i.e. via the control unit.
VLT 2800 Quick Guide
Remote
Local reference
.
