RX-V675/HTR-6066/RX-A730/TSR-6750

■ SPECIFICATIONS

■ Audio Section
Rated Output Power (Power Amp. Section)
(1 kHz, 0.9 % THD)
– 1 channel driven –
U, C, R, T, A, B, G, F, L, S, H models (8 ohms)
FRONT L/R ................................................................ 125 W/ch
CENTER .......................................................................... 125 W
SURROUND L/R ........................................................ 125 W/ch
SURROUND BACK L/R ............................................. 125 W/ch
B, G, F models (4 ohms)
FRONT L/R ................................................................ 150 W/ch
– 2 channels driven simultaneously –
U, C, R, T, A, B, G, F, L, S, H models (8 ohms)
FRONT L/R .......................................................105 W + 105 W
CENTER .......................................................................... 105 W
SURROUND L/R ...............................................105 W + 105 W
SURROUND BACK L/R ....................................105 W + 105 W
(20 Hz to 20 kHz, 0.09 % THD)
– 2 channels driven simultaneously –
U, C, R, T, A, B, G, F, L, S, H models (8 ohms)
FRONT L/R ...........................................................90 W + 90 W
Maximum Effective Output Power (JEITA) [R, T, L, H models]
(1 channel driven, 1 kHz, 10 % THD, 8 ohms)
FRONT L/R ......................................................................... 150 W/ch
CENTER .................................................................................. 150 W
SURROUND L/R ................................................................ 150 W/ch
SURROUND BACK L/R ..................................................... 150 W/ch
Dynamic Power Per Channel (IHF)
FRONT L/R (1 channel driven)
(8 / 6 / 4 / 2 ohms) ..................................... 130 / 170 / 200 / 240 W
Damping Factor (20 Hz to 20 kHz, 8 ohms)
FRONT L/R to SPEAKER-A ............................................ 100 or more
Input Sensitivity/Input Impedance (1 kHz, 100 W/8 ohms)
AV5 etc. ............................................................ 200 mV / 47 k-ohms
Maximum Input Signal (1 kHz, 0.5 % THD)
AV5 etc. (EFFECT ON) .............................................................. 2.3 V
Output Level/Output Impedance
AV OUT ............................................................ 200 mV / 1.2 k-ohms
SUBWOOFER (2 ch stereo and FRONT SP: small)
.............................................................................. 1 V / 1.2 k-ohms
ZONE2 OUT ..................................................... 200 mV / 1.2 k-ohms
Headphone Jack Rated Output/Output Impedance
(1 kHz, 50 mV, 8 ohms)
AV5 etc. input ..................................................... 100 mV / 560 ohms
Frequency Response (10 Hz to 100 kHz)
AV5 etc., FRONT ..................................................................0 / -3 dB
Total Harmonic Distortion (20 Hz to 20 kHz, 50 W/8 ohms)
AV5 etc. (PURE DIRECT) to FRONT SP OUT .............0.06 % or less
Signal to Noise Ratio (IHF-A Network) (Input shorted 250 mV)
AV5 etc. (PURE DIRECT) to SP OUT ....................... 100 dB or more
Residual Noise (IHF-A Network)
FRONT L/R to SP OUT ................................................150 μV or less
Channel Separation (1 kHz / 10 kHz)
AV5 etc. (Input 5.1 k-ohms shorted)
...................................................... 60 dB or more / 45 dB or more
Volume Control/Step
......................................... MUTE / -80 dB to +16.5 dB / 0.5 dB step
10
Tone Control Characteristics
Bass
Boost/Cut ........................................ ±6 dB / 0.5 dB step, at 50 Hz
Turnover frequency ............................................................. 350 Hz
Treble
Boost/Cut .......................................±6 dB / 0.5 dB step, at 20 kHz
Turnover frequency ............................................................ 3.5 kHz
Filter Characteristics
FRONT, CENTER, SURROUND, SURROUND BACK small (H.P.F.)
.................... fc=40/60/80/90/100/110/120/160/200 Hz, 12 dB/oct.
SUBWOOFER small (L.P.F.)
.................... fc=40/60/80/90/100/110/120/160/200 Hz, 24 dB/oct.
Optical Jack, Coaxial Jack Support Frequencies
............................................................................... 32 kHz to 96 kHz
■ Video Section
Video Signal Type
Monitor out (Wall paper)
U, C, R models ...................................................................... NTSC
T, A, B, G, F, L, S, H models ..................................................... PAL
Video conversion
.......................................................................................NTSC/PAL
Composite Video Signal Level
...............................................................................1 Vp-p / 75 ohms
Component Video Signal Level
Y .............................................................................1 Vp-p / 75 ohms
Pb/Pr ...................................................................0.7 Vp-p / 75 ohms
Video Maximum Input Level (VIDEO Conversion Off)
................................................................................ 1.5 Vp-p or more
Video Signal to Noise Ratio
................................................................................... 50 dB or more
Monitor Out Frequency Response (VIDEO Conversion Off)
Component video signal level .......................5 Hz to 60 MHz, -3 dB
■ FM Section
Tuning Range
U, C models ......................................................... 87.5 to 107.9 MHz
R, L, S, H models ..................... 87.5 to 108.0 / 87.50 to 108.00 MHz
T, A, B, G, F models ......................................... 87.50 to 108.00 MHz
50 dB Quieting Sensitivity (IHF) (1 kHz, 100 % MOD.)
Mono ......................................................................... 3 μV (20.8 dBf)
Signal to Noise Ratio (IHF)
Mono ........................................................................................71 dB
Stereo ......................................................................................69 dB
Harmonic Distortion (1 kHz)
Mono ........................................................................................ 0.3 %
Stereo ...................................................................................... 0.5 %
Antenna Input
......................................................................... 75 ohms unbalanced
