AUDIO SECTION
Minimum RMS Output Power per Channel (Power Amp. Section)
(When both channels are driven)
Main L, R
8 ohms, 20 Hz to 20 kHz, 0.04% THD ......................... 60 W + 60 W
Center
8 ohms, 20 Hz to 20 kHz, 0.04% THD ...................................... 60 W
Rear L, R
8 ohms, 20 Hz to 20 kHz, 0.04% THD ......................... 60 W + 60 W
Minimum RMS Output Power per Channel (Power Amp. Section)
(When both channels are driven)
Main L, R
8 ohms, 1 kHz, 0.07% THD ......................................... 70 W + 70 W
Center
8 ohms, 1 kHz, 0.07% THD ...................................................... 70 W
Rear L, R
8 ohms, 1 kHz, 0.07% THD ......................................... 70 W + 70 W
Maximum Power (EIAJ) [China and General models only]
(When both channels are driven)
Main L, R
8 ohms, 1 kHz, 10% THD ............................................ 95 W + 95 W
Center
8 ohms, 1 kHz, 10% THD ......................................................... 95 W
Rear L, R
8 ohms, 1 kHz, 10% THD ............................................ 95 W + 95 W
Dynamic Power per Channel
(by IHF Dynamic Headroom measuring method)
Main L, R
8 ohms ......................................................................... 80 W + 80 W
6 ohms ..................................................................... 100 W + 100 W
4 ohms ..................................................................... 120 W + 120 W
2 ohms .................................................................... 145 W + 145 W
DIN Standard Output Power per Channel [Europe model only]
Main L, R
4 ohms, 1 kHz, 0.7% THD ....................................... 100 W + 100 W
Center
4 ohms, 1 kHz, 0.7% THD ...................................................... 100 W
Rear L, R
4 ohms, 1 kHz, 0.7% THD ....................................... 100 W + 100 W
Dynamic Headroom [U.S.A. and Canada models only]
8 ohms .................................................................................. 1.55 dB
IEC Power [Europe model only]
Main L, R
8 ohms, 1 kHz, 0.04% THD ......................................... 65 W + 65 W
Power Band Width
Main L, R
8 ohms, 30 W, 0.1% THD ....................................... 10 Hz to 50 kHz
Damping Factor (SPEAKERS A)
Main L, R
8 ohms, 20 Hz to 20 kHz .................................................. 60 or more
SPECIFICATIONS
Input Sensitivity/Impedance
PHONO (MM) ...................................................... 2.5 mV/47 k-ohms
CD/TAPE·MD/DVD·LD/TV·DBS/VCR ................. 150 mV/47 k-ohms
6CH DISCRETE INPUT (EXTERNAL DECODER)
Maximum Input Signal
PHONO (MM)
CD/TAPE·MD/DVD·LD/TV·DBS/VCR (EFFECT ON)
Output Level/Impedance
REC OUT ........................................................... 150 mV/2.7 k-ohms
SUBWOOFER (EFFECT OFF) ................................. 5 V/1.2 k-ohms
Headphone Jack Rated Output Level/Impedance
(1 kHz, 8 ohms, 150 mV) ...................................... 0.43 V/ 330 ohms
Frequency Response (20 Hz to 20 kHz)
CD/TAPE·MD/DVD·LD/TV·DBS/VCR ............................... 0 ± 0.5 dB
RIAA Equalization Deviation
PHONO (MM) ................................................................... 0 ± 0.5 dB
Total Harmonic Distortion (20 Hz to 20 kHz)
PHONO (MM) to REC OUT
CD/TAPE·MD/DVD·LD/TV·DBS/VCR (EFFECT OFF) to SP OUT
Signal-to-Noise Ratio (IHF-A Network)
PHONO (MM) to REC OUT (5 mV Input Shorted)
CD/TAPE·MD/DVD·LD/TV·DBS/VCR to MAIN SP OUT
Residual Noise (IHF-A Network)
MAIN L/R to SP OUT ................................................. 150 µV or less
Channel Separation (Vol. –30 dB, EFFECT OFF)
PHONO
CD/TAPE·MD/DVD·LD/TV·DBS/VCR
Tone Control Characteristics
BASS:
TREBLE: Boost/cut ............................................... ±10 dB, 20 kHz
Filter Characteristics
Subwoofer (L.P.F.) ......................................... fc = 150 kHz, 6 dB/oct.
MAIN L/R ......................................................... 150 mV/47 k-ohms
CENTER ......................................................... 150 mV/40 k-ohms
REAR L/R ........................................................ 150 mV/40 k-ohms
SUBWOOFER ................................................. 150 mV/40 k-ohms
1 kHz, 0.1% THD ................................................ 100 mV or more
1 kHz, 0.5% THD .................................................... 2.2 V or more
1 V ........................................................................... 0.02% or less
30 W/8 ohms ......................................................... 0.025% or less
[U.S.A., Canada, China, and General models] ...... 86 dB or more
[Australia, U.K., and Europe models] ..................... 81 dB or more
(150 mV Input Shorted, EFFECT OFF) .................. 96 dB or more
(Input Shorted, 1 kHz/10 kHz) ........ 60 dB or more/55 dB or more
(Input 5.1 k-ohms shorted, 1 kHz/10 kHz)
....................................................... 60 dB or more/45 dB or more
Boost/cut ................................................. ±10 dB, 50 Hz
Turnover Frequency ............................................ 350 Hz
Turnover Frequency ........................................... 3.5 kHz
43
