Chapter 2. Product overview

USB 2.0 connector
HDMI connector
Security-lock slot*
Touch pad
ThinkPad logo LED
Home
Projector icon LED
Speaker
Tripod screw hole
Reset hole
*Security-lock slot: It is recommended that you use the Kensington Minisaver Cable Lock from Lenovo
(part number: 4X90H35558) to secure the projector. To purchase the lock, go to the Lenovo Web site.
*Pogo pad: The Pogo pad
other ThinkPad Stack devices.
CAUTION:
When you use the projector, ensure that the ambient temperature is between 0°C (32°F) and 35°C (95°F).
Do not block the vents
supports both data and power transfer when you stack the projector to
when the projector is on.
2
Audio connector
ac power connector
Air-out vents
Focus wheel
Overview
Back
Air-in vents
Power button with power LED
Foldout foot
Pogo pad*
