8. Slide the inner chassis back into the outer enclosure. Note that the inner chassis

can slide into either end of the outer enclosure, but the rails on one end of the outer

chassis are notched, as shown to the left. This allows the back plate to sit flush

when attached.

9. Attach the back plate as shown below and use a Phillips

driver to re-affix the two screws that you removed in Step

1, in the locations shown at left.

This completes the assembly process.

OWC Mercury Elite Pro mini

DEVICE SETUP
