4. Once the inner chassis has been removed from the
outer enclosure, note the SATA connector, highlighted
in yellow. There are also four screw holes highlighted
in red — two through the metal on the right and two
through the green circuit board on the left.
5. Place the drive in the inner chassis as shown below.
Slide the drive into the SATA connector on the circuit
board, making sure the drive is fully seated before
proceeding.
6. Use one hand to hold the drive in place, then turn over
the inner chassis. There are four screw holes on the
bottom of the inner chassis (circled in red below).
7. Insert the four included screws into the screw holes,
then use a Phillips driver to fasten the drive to the inner
chassis (shown below). When this is done, turn the
inner chassis over.
