PRIMERGY TX200 S3 User Manual

Hide thumbs Also See for TX200 S3:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual Supplement
Areas Covered
Before Reading This Manual
This section explains the notes for your safety and conventions used in this manual.
Chapter 1
Overview
This chapter explains component names and basic operations of this server, as well as an
overview of the software provided with this server. In addition, the workflow, from placing the
server to starting the operation, is also described.
Chapter 2
Checking before OS Installation
This chapter explains the preparation on the server and cautions necessary before OS installation.
Please read this chapter before starting installation.
Chapter 3
OS Installation Using ServerStart
This chapter explains how to install the OS in the server using ServerStart.
Chapter 4
Manual OS Installation
This chapter explains how to install the OS without using ServerStart.
Chapter 5
Operations after OS Installation
This chapter explains the operations to be performed after OS installation. Be sure to perform
those operations before operating the server.
Chapter 6
High Reliability Tools
For stable PRIMERGY server operations, we recommend that high reliability tools be installed.
This chapter explains the installation and necessary settings of high reliability tools.
Chapter 7
Installing Internal Options
This chapter explains how to install internal options.
Chapter 8
Configuring Hardware and Utilities
This chapter explains how to make the environment settings necessary to operate the server and
how to use each utility.
Chapter 9
Operation and Maintenance
This chapter explains the operations that become necessary after starting to use this server as well
as daily care and maintenance.
Appendix
This appendix explains the specifications for the server and for its internal options.
PRIMERGY TX200 S3 User's Guide
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TX200 S3 and is the answer not in the manual?

Questions and answers

Related Manuals for PRIMERGY TX200 S3

Summary of Contents for PRIMERGY TX200 S3

  • Page 1 Chapter 6 High Reliability Tools For stable PRIMERGY server operations, we recommend that high reliability tools be installed. This chapter explains the installation and necessary settings of high reliability tools. Chapter 7 Installing Internal Options This chapter explains how to install internal options.

  • Page 2: For Your Safety

    Before Reading This Manual For Your Safety... This manual contains important information, required to operate the server safely. Thoroughly review the information in this manual before using the server. Especially note the points under "Safety Precautions", and only operate the server with a complete understanding of the material provided. This manual and "Safety Precautions"...
  • Page 3 PRIMERGY TX200 S3 User’s Guide Remarks Warning Descriptions Various symbols are used throughout this manual. These are used to emphasize important points for your safety and that of others. The following are the symbols and their meanings. Fully understand these symbols when reading this manual.
  • Page 4 Entering Commands (Keys) Command entries are displayed in the following way. • At each blank in a command line (as pointed out above), press the [Space] key once. • When using Windows or DOS OS, commands are not case sensitive. •...
  • Page 5 PRIMERGY TX200 S3 User’s Guide Abbreviations The following expressions and abbreviations are used throughout this manual. table: Abbreviations of Product Names Product name Expressions and abbreviations PRIMERGY TX200 S3 This server or the server ® Windows Server 2003 R2 Windows Windows ™...

  • Page 6: Reference Information

    Latest Information about Software Provided with This Server For the latest information regarding ServerStart and other software provided with this server, refer to the Fujitsu PRIMERGY website (http://primergy.fujitsu.com). Warning and Caution Labels Warning and caution labels are found on the server.

  • Page 7: Table Of Contents

    1.1 TX200 S3 ........
  • Page 8 3.1.3 RAID and Disk Wizard ........61 3.1.4 OS Installation Wizard .
  • Page 9 PRIMERGY TX200 S3 User’s Guide Chapter 5 Operations after OS Installation 5.1 Memory Dump/Paging File Setting ..... . 136 5.1.1 How to Obtain Memory Dump for Windows Server 2003 ... .136 5.1.2 How to Obtain Memory Dump for Windows 2000 Server .
  • Page 10 7.3 Installing the CPU ........177 7.3.1 Installation Location of CPUs and Installable CPUs .
  • Page 11 PRIMERGY TX200 S3 User’s Guide 8.2.12 The Server Menu ......... .231 8.2.13 The CPU Status Submenu .
  • Page 12 C Using the Server Management Port ....285 C.1 Preparation for Using Remote Control Function ....285 C.2 Remote Power Supply Control .

  • Page 13: Chapter1 Overview

    1.1 TX200 S3 ........

  • Page 14: Tx200 S3

    Chapter1 Overview 1.1 TX200 S3 This server has the following features. High Reliability Advanced Memory Protection Function The server supports the SDDC (Single Device Data Correction） function using PC2-4200F (DDRII 533) compliant memory (Fully Buffered DIMM). Also, memory mirroring function is supported to enable data recovery in the event of a memory error.
  • Page 15 PRIMERGY TX200 S3 User’s Guide High-speed Processing   Dual Core Intel Xeon Processors The server can have up to two dual core Intel® Xeon® processors for high-speed data processing (one processor in standard servers). The server supports the 64-bit processing and the Hyper-Threading function providing high-efficiency and high-speed processing.

  • Page 16: Supplied Software

    ServerStart for supporting setup and high reliability tools for avoiding problems during server operation are supplied with this server. 1.2.1 Setup Support Tool - ServerStart ServerStart is a setup support tool that helps to install PRIMERGY. It offers easy server installation and proper installation of recommended drivers. Installing ServerStart...
  • Page 17 PRIMERGY TX200 S3 User’s Guide Supported OS The following OSs can be installed using ServerStart V6.606. ® ™ • Microsoft Windows Server 2003, Standard Edition ® ™ • Microsoft Windows Server 2003, Enterprise Edition ® ™ • Microsoft Windows Server 2003, Standard x64 Edition ®...

  • Page 18: Main Window

    Chapter1 Overview Intuitive User Interface The intuitive user interface allows you to easily set the necessary information. Main Window When ServerStart is started, the following window appears. The window and tool bar differ depending on the mode. Toolbar In Guided Mode/Expert Mode Brings you to Brings you to Changes the size...

  • Page 19: Network Configuration

    PRIMERGY TX200 S3 User’s Guide Wizard Window Clicking a wizard displays a wizard window. Set items in the wizard window. To move to a step in the next wizard window, click the operation button at the bottom of the window. Clicking [help] displays a tip for setting the item.

  • Page 20: High Reliability Tools

    Chapter1 Overview 1.2.2 High Reliability Tools High reliability tools are a comprehensively useful set of software for stable system operations of the server. The following tools have respective roles to manage normal operations or recovery from errors. • Server Monitoring Tools •...

  • Page 21: Installing High Reliability Tools

    PRIMERGY TX200 S3 User’s Guide Installing High Reliability Tools You can install all high reliability tools provided with PRIMERGY by specifying them in "Application Wizard" when the OS is installed is initiated with ServerStart. The following high reliability tools are installed.

  • Page 22: Component Names And Functions

    Chapter1 Overview 1.3 Component Names and Functions This section explains the component names and functions of the server. 1.3.1 Server (Front View) a b c d e f g h Drive cover Pull the drive cover down to the lower end of the server.

  • Page 23: Power Switch

    PRIMERGY TX200 S3 User’s Guide e Maintenance switch This switch is used only by maintenance personnel. Do not touch this. f System status LED ( This LED lights or blinks in amber when an error is detected in the server components. If this LED lights or blinks, contact an office listed in the "Contact Information"...
  • Page 24 Chapter1 Overview Inside the Hard Disk Cover Hard disk cover Remove the hard disk cover. a 3.5-inch storage bay Contains an internal hard disk. b Hard disk access display LED ( This LED is lit green when data is being written to or read from the hard disk. table: Meaning of the Hard Disk Access Display LED LED status Hard disk access status...

  • Page 25: Server (Rear View)

    PRIMERGY TX200 S3 User’s Guide 1.3.2 Server (Rear View) Power supply unit (Non redundant) Power supply unit (Redundant) a Power supply unit When using the Power Supply Conversion kit, two units are installed, which enables the redundant power supply function.
  • Page 26 Chapter1 Overview e System status LED / System identification LED When an error is detected in a server component, this LED lights or blinks amber. If this LED lights or blinks, contact an office listed in the "Contact Information" of the "Start Guide".
  • Page 27 PRIMERGY TX200 S3 User’s Guide m LAN (10/100/1000BASE-T) port ( An Unshielded Twisted Pair (UTP) cable is plugged in. For 1000Mbps connection, a category 5 enhanced or a category 6 cable is required. For 10Mbps/100Mbps connection, a category 5 or higher cable is required.

  • Page 28: Server (Internal)

    Chapter1 Overview 1.3.3 Server (Internal) Rear a Power supply unit b 5-inch storage bay Contains a 5-inch internal optional device. . c 3.5-inch storage bay Contains a 3.5-inch internal optional device. d System fan When Power Supply Conversion kit is used, four fans are installed to enable the redundant function.

  • Page 29: Baseboard

    PRIMERGY TX200 S3 User’s Guide 1.3.4 Baseboard a Parallel connector A parallel port cable is plugged in when using optional parallel port. b Memory slots Contains memory. One memory bank consists of Slots A and B in this server. Be sure to install a pair of memory modules.

  • Page 30: Standard Operations

    Chapter1 Overview 1.4 Standard Operations This section explains such standard operations as turning the server on/off and inserting/ejecting CD-ROMs. 1.4.1 Sliding the Drive Cover Turn the drive cover key counterclockwise to unlock the cover. Drive cover key Slide the drive cover. Slide the drive cover down to use the floppy disk drive, CD-ROM drive, or a 5-inch internal option device.

  • Page 31: Opening The Rack Door

    PRIMERGY TX200 S3 User’s Guide 1.4.2 Opening the Rack Door This section explains how to open the front and rear doors of the 40U standard rack. Refer to the manual included with the rack for procedures on opening other rack doors.
  • Page 32 Chapter1 Overview Opening the Rear Door Turn the rack key and pull the rack handle up. Turn the handle in the direction of the arrow and pull it forward. Turn and then pull Unless you are inserting/ejecting media or turning the power on/off, keep the rack door closed. Doing so blocks electric waves from cell phones, etc.

  • Page 33: Turning On The Server

    PRIMERGY TX200 S3 User’s Guide 1.4.3 Turning On the Server • Do not move, strike, or shake the server when it is turned on. This can damage the hard disk in the server and cause data loss. • Turn the server on when the temperature is in its operating environment range (10-35°C).

  • Page 34: Turning Off The Server

    Chapter1 Overview 1.4.4 Turning Off the Server • In the event of smoke or sparks, immediately unplug the electric cord. Failure to do so could lead to a fire or electrocution. • Follow the procedures below to turn off the server. Data can be lost if these procedures are not followed correctly.

  • Page 35: Inserting And Ejecting A Floppy Disk

    PRIMERGY TX200 S3 User’s Guide Cautions when Turning the Power Off (When the OS is Windows Server 2003 or Windows 2000 Server) • For Windows Server 2003 "Do Nothing", "Prompt Input", "Standby", "Hibernation", or "Shutdown" can be specified as the operating mode of the power switch in the OS settings (normally, "Shutdown"...
  • Page 36 Chapter1 Overview Inserting the Floppy Disk Insert the floppy facing the label up into the floppy disk drive at the side with a shutter. It makes a clicking sound and the floppy disk eject button pops out. Floppy Disk Ejecting the Floppy Disk Make sure that the floppy disk access LED is off, and then press the floppy disk eject button.

  • Page 37: Inserting And Ejecting A Cd-Rom (Dvd-Ram)

    PRIMERGY TX200 S3 User’s Guide 1.4.6 Inserting and Ejecting a CD-ROM (DVD-RAM) This section explains how to insert and eject a CD-ROM. Unless otherwise noted, a CD-ROM can also mean a DVD-RAM. When using a CD-ROM, note the followings to avoid a failure: Cautions for Handling CD-ROM Drive •...
  • Page 38 Chapter1 Overview Inserting the CD-ROM Make sure the server is turned on and press the CD-ROM eject button. The CD-ROM tray comes out a little. CD-ROM eject button Place the CD-ROM (label side up) onto the tray. CD-ROM Press the CD-ROM eject button. The tray is inserted into the server and CD-ROM is set.

  • Page 39: Workflow

    PRIMERGY TX200 S3 User’s Guide 1.5 Workflow Use the following workflow from server installation to start of operation. Installing the server Refer to "Safety Precautions" and "Start Guide" to install the server to a suitable place. Preparing the server - Install hardware options - Set hardware Refer to "2.1 Preparation on the server", "Chapter 7 Installing Internal Options"...
