AMPLIFIED INDOOR HDTV ANTENNA WIFI EXTENDER WITH SETUP GUIDE Check out setup videos at www.TERK.com/Setup Instrucciones en español ....21...
Page 2
Setup is easy! Getting up and running with the Trinity Xtend has two parts. WIFI EXTENDER SETUP HDTV ANTENNA SETUP (for better Wi-Fi coverage around the Xtend) (for free local HDTV) Download the TERK Find the best place XTEND App on your for the Xtend.
Page 3
HD ANTENNA SETUP Find the best location for your antenna. TV antennas perform best when facing the direction of the broadcaster’s tower. tend) For help finding your local broadcast towers, go to www.TERK.com Antenna Placement Tips pp to Avoid metal surfaces (like a metal stand). Move the antenna close to or in a window.
Page 4
HD ANTENNA SETUP (continued) Raise the antenna’s five elements. Raise the five elements to their upright position for best performance. Side view For wall-mounting, raise the five antenna elements to their full 180-degree position. Connect the antenna’s coaxial cable to your TV. Amplifier IMPORTANT: Make sure your TV is turned off.
Page 5
TV. IMPORTANT: For some channels you might get better performance with the Trinity Xtend antenna in a different position or facing a different direction. Sometimes just a little bit of adjustment can make a...
Page 6
WIFI EXTENDER SETUP with the APP Download the TERK XTEND App on your phone or tablet. In the Google Play or Apple App Stores, search for “TERK XTEND” and look for the icon shown here. Then download and install the App. Note: If you have a QR code reader on your phone or tablet, you can also go directly to the App using the QR codes on the bottom of the Xtend.
Page 7
WIFI EXTENDER SETUP with the APP (continued) Connect your phone or tablet to the Terk Xtend. Go to the WiFi connections menu on Bottom of the your phone or tablet (in the Settings Terk Xtend menu). ectly Wi-Fi Name (SSID): XTN-000000 Look at the Wi-Fi Name (SSID) listed Wi-Fi Password: 12345678 Web browser link: http://192.168.168.1/...
Page 8
WIFI EXTENDER SETUP with the APP (continued) Launch the TERK XTEND App on your phone or tablet. Press on the TERK XTEND App icon to launch the App. Connect the Terk Xtend to your network. iPhone screen Android screen In the first screen of the TERK XTEND App, press the SCAN button to start scanning for available networks.
Page 9
WIFI EXTENDER SETUP with the APP (continued) iPhone screen Find your WiFi network in the list and Android screen select it. WHAT IF I DON’T SEE MY WIFI NETWORK? • If your network does not broadcast its SSID, it will show up in the list as [Hidden]. You can enter the SSID manually by choosing the [Hidden] option in the list and typing in the name on the following screen.
Page 10
WIFI EXTENDER SETUP with the APP (continued) Enter the password for your WiFi iPhone screen Android screen network when prompted. Then press the Next button. IMPORTANT: If you chose [Hidden] from the list of available networks, enter the name of your WiFi network in the SSID field on this screen before you enter your password.
Page 11
WIFI EXTENDER SETUP with the APP (continued) iPhone screen Android screen The next screen lets you change the name and password of the Xtend from what’s s the listed on the bottom of the Xtend to a name and password of your choice (like “upstairs-xtend,”...
Page 12
WAIT FOR THE XTEND TO REBOOT! Allow a minute or so for the Trinity Xtend to restart before you start connecting devices to it. The LINK light on the front of the Xtend will turn solid blue when it’s ready to accept connections from your...
Page 13
WIFI EXTENDER SETUP with the APP (continued) Connect your devices to the Terk Xtend. Once you’ve finished setup, wait for the Xtend to reboot with its new settings. nt to When the LINK light on the Xtend’s front panel turns solid blue, go into the WiFi connection menus of the devices you want to use with the Xtend’s extended WiFi range and choose the Xtend from the list of available devices to connect to.
Page 14
WIFI EXTENDER SETUP with COMPUTER Using browser-based setup The Terk Xtend WiFi Extender can also be set up via web browser on your computer. 1. In your computer’s WiFi connection menu, choose the Wi-Fi Name (SSID) from the bottom sticker of the Terk Xtend. The password is also on the bottom sticker. Give your computer a full minute to connect to this new network.
Page 15
TOUR OF THE TRINITY XTEND POWER indicator illuminates when the Trinity Xtend is Reception element plugged in. LINK indicator illuminates when the Xtend is linked to your home network. ACTIVITY indicator flashes to show that there is WiFi activity. RESET button returns the Xtend to its factory default settings, clearing all of your network information.
Page 16
TOUR OF THE TRINITY XTEND (continued) Amplifier I’m ha AMP / BYPASS switch lets you turn the amplifier for TV signals on (AMP) or off (BYPASS). Most • The TV channels will perform better with this switch left in the AMP position. However, if a channel is...
TROUBLESHOOTING Antenna Reception Problems I’m having trouble receiving certain channels. • There are lots of factors that can affect your reception. Tall buildings, mature trees, even hills between you and the broadcast towers can interfere and change the direction of the signals you receive. You might still need to make adjustments after you position the antenna to account for these factors.
Page 18
• Make sure your phone, tablet, or computer has WiFi turned on. • The Trinity Xtend will appear by its SSID in the list of available networks. Your Xtend’s SSID is listed on the label on the bottom of the Xtend.
Page 19
My WiFi coverage and/or performance isn’t as good as I expected. • Make sure you’ve connected each device you want to use to the Trinity Xtend, not directly to your WiFi router. For example, if you want to use your streaming box, go to the WiFi connection settings on your Setup streaming box and find your Xtend’s SSID in the list of available connections (if you customized the...
Page 20
I’m having intermittent connection problems. • Make sure you’re connected to the Trinity Xtend, not directly to your WiFi router. Go to the WiFi connection settings for each of your devices and find your Xtend’s name (either the customized one you created or the default on the bottom of the unit) in the list of available connections.
ANTENA INTERIOR HDTV AMPLIFICADA EXTENSOR WIFI GUÍA DE CONFIGURACIÓN Consulte los videos de instalación en www.TERK.com/Setup...
Page 22
¡Es fácil de configurar! La instalación y puesta en marcha con la Trinity Xtend tiene dos partes. CONFIGURACIÓN DEL EXTENSOR WIFI CONFIGURACIÓN DE LA ANTENA HDTV (para una mejor cobertura Wi-Fi alrededor del Xtend) (para HDTV local gratis) Descargue la aplicación...
Page 23
CONFIGURACIÓN DE LA ANTENA HD Encuentre la mejor ubicación para su antena. Las antenas de TV funcionan mejor cuando están orientadas WIFI hacia la torre de radiodifusión. l Xtend) Si necesita ayuda para encontrar la ubicación de las torres ón www.TERK.com de radiodifusión locales, visite Consejos para la ubicación de la antena...
Page 24
INSTALACIÓN DE LA ANTENA HD (continuación) Levante los cinco elementos de la antena. Para lograr un mejor desempeño levante los cinco elementos a su posición vertical. Vista lateral Para el montaje en pared, levante los cinco elementos de la antena a su posición de 180 grados.
Page 25
TV. IMPORTANTE: Para algunos canales es posible que pueda obtener un mejor desempeño con la antena Trinity Xtend en una posición diferente u orientada en una dirección diferente. ¡A veces un ajuste pequeño es todo lo que se necesita!
Page 26
CONFIGURACIÓN DEL EXTENSOR WIFI con la aplicación Descargue la aplicación TERK XTEND en su teléfono o tablet. En las tiendas Google Play o Apple App, busque “TERK XTEND” y el icono mostrado aquí. Luego, descargue e instale la aplicación. Aviso: Si usted tiene un lector de código de Respuesta Rápida (QR) en su teléfono o tablet, también puede ir directamente a la aplicación usando los códigos QR indicados en la parte inferior del Xtend.
Page 27
CONFIGURACIÓN DEL EXTENSOR WIFI con la aplicación (continuación) Conecte su teléfono o tablet al Terk Xtend. Acceda al menú de conexiones WiFi en Parte inferior del su teléfono o tablet, en el menú Settings Terk Xtend (Ajustes). Wi-Fi Name (SSID): XTN-000000 Fíjese en el Nombre WiFi (SSID, código Wi-Fi Password: 12345678 Web browser link: http://192.168.168.1/...
Page 28
CONFIGURACIÓN DEL EXTENSOR WIFI con la aplicación (continuación) Inicie la aplicación TERK XTEND en su teléfono o tablet. Oprima el icono de la aplicación TERK XTEND para iniciar la aplicación. Conecte el Terk Xtend a su red. Menú iPhone Menú Android En la primera pantalla de la aplicación TERK XTEND, oprima el botón SCAN (Buscar) para comenzar a buscar...
Page 29
CONFIGURACIÓN DEL EXTENSOR WIFI con la aplicación ción) (continuación) Menú iPhone Encuentre su red WiFi en la lista Menú Android y selecciónela. ón. ¿QUÉ HAGO SI NO VEO MI RED WIFI? • Si su red no retransmite su SSID, aparecerá en la lista como oculta [Hidden].
Page 30
CONFIGURACIÓN DEL EXTENSOR WIFI con la aplicación (continuación) Introduzca la contraseña para su red WiFi Menú iPhone Menú Android cuando se le pida. Luego oprima el botón Next (Siguiente). IMPORTANTE: Si selecciona [Hidden] en la lista de redes disponibles, introduzca el nombre de su red WiFi en el campo SSID en esta pantalla antes de introducir la contraseña.
Page 31
CONFIGURACIÓN DEL EXTENSOR WIFI con la aplicación ción) (continuación) Menú iPhone Menú Android La siguiente pantalla le permite cambiar el nombre y la contraseña del Xtend con respecto a lo que aparece indicado en la parte inferior del Xtend a un nombre y contraseña elegidos por usted (como por ejemplo: “xtend-primer piso”).
Page 32
CONFIGURACIÓN DEL EXTENSOR WIFI con la aplicación (continuación) Menú iPhone Menú Android La pantalla final de configuración del Xtend le muestra el nombre y la contraseña de su red Wi-Fi existente, y el nombre y la contraseña del Xtend. Si lo desea, usted puede capturar esta pantalla para sus registros.
Page 33
CONFIGURACIÓN DEL EXTENSOR WIFI con la aplicación ción) (continuación) Conecte sus dispositivos al Terk Xtend. u red Una vez que haya finalizado la configuración, espere para que el Xtend se reinicie con sus nuevos ajustes. Cuando la luz LINK (Enlazar) en el panel frontal del Xtend se torne azul continuo, vaya a los menús de conexión WiFi de los dispositivos que usted quiere usar con el alcance WiFi extendido del Xtend y elija el Xtend en la lista de dispositivos disponibles a los que conectar.
Page 34
CONFIGURACIÓN DEL EXTENSOR WIFI con una COMPUTADORA Uso de un navegador para la configuración Parte El extensor WiFi Terk Xtend también puede configurarse vía un navegador en su computadora. 1. En el menú de conexiones WiFi de su computadora, elija el Nombre Wi-Fi (SSID) indicado en la etiqueta en la parte inferior del Terk Xtend.
Page 35
RECORRIDO DEL TRINITY XTEND Parte superior POWER – el indicador de POTENCIA se ilumina cuando el Elemento de recepción Trinity Xtend está enchufado. LINK – el indicador de ENLACE se ilumina cuando el Xtend está enlazado o conectado con la red de su casa.
Page 36
RECORRIDO DEL TRINITY XTEND (continuación) Prob Amplificador Tengo AMP / BYPASS – este interruptor le permite activar • So la función de amplificación de las señales de TV (AMP) o desactivar la misma (BYPASS) en el amplificador. La mayoría de los canales de TV funcionaran mejor cuando se deja este interruptor en la posición AMP.
RESOLUCIÓN DE PROBLEMAS Problemas de recepción de la antena Tengo problemas con la recepción de ciertos canales. • Son muchos los factores que pueden afectar la recepción. Los edificios altos, los árboles maduros e incluso las colinas que hay entre su vivienda y las torres de transmisión pueden interferir y cambiar la dirección de las señales que usted recibe.
Page 38
No puedo conectar mi teléfono, tablet o computadora con el Trinity Xtend. • Cerciórese de que el WiFi esté activado en su teléfono, tablet o computadora. • El Trinity Xtend aparecerá por su SSID en la lista de redes disponibles. El SSID de su Xtend está indicado en No pu la etiqueta en la parte inferior del Xtend.
Page 39
Tengo problemas de conexión intermitente. • Asegúrese que esté conectado con el Trinity Xtend, no directamente al enrutador WiFi. Acceda a los ajustes de conexión WiFi para cada uno de sus dispositivos y busque el nombre de su Xtend (ya sea el nombre personalizado que usted creó...
