USB-1208LS User's Guide
Pin Signal Name
1 CH0 IN
2 CH1 IN
3 GND
4 CH2 IN
5 CH3 IN
6 GND
7 CH4 IN
8 CH5 IN
9 GND
10 CH6 IN
11 CH7 IN
12 GND
13 D/A OUT 0
14 D/A OUT 1
15 GND
16 CAL
17 GND
18 TRIG_IN
19 GND
20 CTR
8-channel single-ended mode
Pin Signal Name
21 Port A0
22 Port A1
23 Port A2
24 Port A3
25 Port A4
26 Port A5
27 Port A6
28 Port A7
29 GND
30 PC+5V
31 GND
32 Port B0
33 Port B1
34 Port B2
35 Port B3
36 Port B4
37 Port B5
38 Port B6
39 Port B7
40 GND
23
Specifications
