Installation - Fisher FIELDVUE DLC3010 Quick Start Manual

DLC3010 Digital Level Controller
February 2016

Installation

WARNING
To avoid personal injury, always wear protective gloves, clothing, and eyewear when performing any installation
operations.
Personal injury or property damage due to sudden release of pressure, contact with hazardous fluid, fire, or explosion can
be caused by puncturing, heating, or repairing a displacer that is retaining process pressure or fluid. This danger may not
be readily apparent when disassembling the sensor or removing the displacer. Before disassembling the sensor or
removing the displacer, observe the appropriate warnings provided in the sensor instruction manual.
Check with your process or safety engineer for any additional measures that must be taken to protect against process
media.
This section contains digital level controller installation information, including an installation flowchart (figure 1),
mounting and electrical installation information, and a discussion of failure mode jumpers.
Do not install, operate, or maintain a DLC3010 digital level controller without being fully trained and qualified in valve,
actuator, and accessory installation, operation, and maintenance. To avoid personal injury or property damage, it is
important to carefully read, understand, and follow all of the contents of this manual, including all safety cautions and
warnings. If you have any questions regarding these instructions contact your
office before proceeding.
