Medivators SCOPE BUDDY Series Service Manual

Endoscope flushing aid for serial numbers from 201345
Hide thumbs

Advertisement

Table of Contents

SERVICE MANUAL
SCOPE BUDDY
®
ENDOSCOPE FLUSHING AID
(For Serial Numbers ≥ 201345)
MEDIVATORS
Endoscope reprocessing the way it should be

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SCOPE BUDDY Series and is the answer not in the manual?

Questions and answers

Related Manuals for Medivators SCOPE BUDDY Series

Summary of Contents for Medivators SCOPE BUDDY Series

  • Page 1 SERVICE MANUAL SCOPE BUDDY ® ENDOSCOPE FLUSHING AID (For Serial Numbers ≥ 201345) MEDIVATORS Endoscope reprocessing the way it should be...
  • Page 2 Minntech Corporation. Minntech reserves the right to make changes in the specifications shown herein without or obligation. Contact your Medivators representative or Medivators customer service for more information. MEDIVATORS...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS PAGE INTRODUCTION Using this Manual Product Description Product Specifications QUALITY ASSURANCE TEST Flow Validation Setup and Tubing Prime Performing a Flow Validation Test PUMP REPLACEMENT Replacement Instructions PARTS LIST Illustration Parts List WARRANTY MEDIVATORS...
  • Page 4 MEDIVATORS...

  • Page 5: Introduction

    INTRODUCTION Using this Manual This Service Manual is to be used for servicing the Medivators SCOPE BUDDY Endoscope Flushing Aid having a serial number ≥201345. A SCOPE BUDDY unit having a serial number ≤ 201344 is not serviceable, and should be discarded and replaced with a new unit.

  • Page 6: Product Specifications

    Installation / Over Voltage Category Classification 1, Ordinary protection Pollution Degree Operating Temperature Range 15ºC to 35ºC Operating Humidity Range 10 - 75% non-condensing Storage Temperature Range -29ºC to 57ºC Storage Humidity Range 5 - 90% non-condensing Warranty Period One (1) year MEDIVATORS...

  • Page 7: Quality Assurance Test

    WARNING: Failure to perform the quality test can result in the device not delivering the proper amount of fluid through the channels of an endoscope. Note: A 200cc graduated cylinder is required to perform this test. MEDIVATORS...

  • Page 8: Flow Validation Setup And Tubing Prime

    2. Locate the Fluid Intake Line and attach it to the front panel tubing connection port labeled “IN.” Place the screened end into the sink or container of clean water. Verify the screened end is fully submerged into the water. See Figure 2. Figure 2 MEDIVATORS...
  • Page 9 Universal Cleaning Adapter Extension Line. Place the open end of the Flow Verification Tube into the sink. See Figure 4. SCOPE BUDDY UNIT Fluid Intake Line Universal Cleaning Adapter with Flow Verification Tube Figure 4 Universal Cleaning Adapter with Flow Verification Tube MEDIVATORS...

  • Page 10: Performing A Flow Validation Test

    6. If the dispensed volume is above or equal to 100 ml’s, then SCOPE BUDDY is ready for use. If the dispensed volume is below 100 ml’s, then contact your local distributor or Medivators Technical Support. Do not use SCOPE BUDDY if the dispensed volume is below 100 ml’s.

  • Page 11: Pump Replacement

    SCOPE BUDDY is delivering the correct volume of fluid over time. If SCOPE BUDDY does not operate correctly or deliver the correct volume of fluid during the Quality Assurance Test, then contact your local Medivators representative or distributor for further assistance. Note: Do not use SCOPE BUDDY if it fails the Quality Assurance Test.
  • Page 12 3. Lay the SCOPE BUDDY on the back plate and then lift/tip the blue housing forward. See Figure 6. Figure 6 4. Follow the red and black wires from the back of the pump motor to the connector labeled “PMP” and then disconnect the plug. See Figure 7. Figure 7 MEDIVATORS...
  • Page 13 Figure 8 6. Using a 3/8” wrench, remove the four (4) nuts that hold the pump to the back plate. See Figure 9. Figure 9 Remove pump from back plate. MEDIVATORS...
  • Page 14 12. Reattach the five (5) screws that hold the back plate to the blue SCOPE BUDDY housing. 13. Reattach the power cords and turn system power back on. 14. Run SCOPE BUDDY for several minutes using water to verify there are no fluid leaks. 15. Perform the Quality Assurance Test as detailed in Section 2. MEDIVATORS...

  • Page 15: Illustration

    PARTS LIST MEDIVATORS...
  • Page 16 Scope Buddy Service Parts List Part Number Description Unit 72233-213 Chassis, Scope Buddy 78399-658 Cover, Scope Buddy Medivators 78400-538 Pump Assembly, Service Part 39500-046 Controller, Scope Buddy 37590-241 Harness, Power Jack 37590-242 Harness, Rocker Switch 47509-454 “OUT” Connector 47509-456 “IN” Connector...

  • Page 17: Warranty

    This will be customer’s exclusive remedy for a covered defect. In order to recover under the warranty, the customer must notify Medivators if in the U.S.A., or country of installation of the defect (describing the problem in reasonable detail) prior to the expiration of the warranty period and within thirty (30) days of discovery of the defect.
  • Page 20 Medivators Website “Resource Center” Go to: www.minntech.com/medivators, Select “Resource Center” and “User Library” for detailed user guides and hook up matrices, report forms and logs, and product bulletins Medivators Customer and Technical Support Toll Free: Phone: 1-800-444-4729 · FAX: 1-866-421-7696...
