PA RL600 Sst Technical Manual

RL600 Sst
–600 bar – 60 MPa gun
Gun suitable for use with pumps up to 600 bar – 60 MPa rated pressure.

TECHNICAL SPECIFICATIONS MAGNETIC MICROSWITCH WITH REED BULB

Rated voltage: 220 V
Cable length : 2000 mm
Room temperature: 100°C
Current max:
P/N RATED
PRESSURE
bar - MPa
30.5800.00 600 - 60
*30.5820.00 600 - 60
(1) Attention ! ! !
The work limit of the magnetic microswitch with REED bulb attached to the gun must be
maximum: 48 volt ac-cc
(2) The gun has been designed for continuous use, at a water temperature of 60°C (140°F). It can resist at the max
temperature of 100°C (210°F) for short periods only, as, when the gun shuts off, the heater continues to transmit the heat
to the water, thus increasing both temperature and pressure up to high, dangerous values.
Using the gun at a water temperature higher than 60°C involves for the operator the use of adequate safety devices,
such as gloves, etc.
Attention ! ! !
In order to prevent the risk of INSTABILITY of the gun due to pressure spikes, CHECK (fig. 3) the use of safety
devices (SHOULDER SUPPORT) in the CHART enclosed, in function of the parameters of Pressure / Flow Rate..
. Instruction manual, maintenance, installation, spare parts.
For a correct utilization, follow the directions of this manual.
Re-print them on the Use and Maintenance booklet of the machine.
Commutable voltage max :
Wire:
Type of action:
0.5 A
PERMISSIBLE
PRESSURE
bar - MPa
660 - 66
660 - 66

30.5800.00 RL600 Sst

30.5820.00 RL600 Sst with microswitch
- Assembly on tubes equipped with G3/8" couplings
- Entirely made of stainless steel
- Ergonomic construction
- The trigger opens up with minimum effort
- Microswitch version with REED bulb (*)
- Highly resistant Reed switch
- Protection degree IPX3
- Protection class III
- Magnetically controlled by the movement of the trigger
- In compliance with
10 VA
2 x 0,25mm
1C
MAX FLOW (1) MAX
RATE TEMPERATURE
I/min °C
60 100
60 100
E 102
Technical manual :
norms
2
INLET
OUTLET
G3/8F-F
G3/8F-F
n. 12.9102.00
Ed. 04/2002
Last Update: 30/01/2017
WEIGHT
gr
1005
1020
