- Page 1 S4E V2 Hi-Carb Superchiller 220V / 60Hz Installation, Operation & Service Manual lancerbeverage.com...
- Page 2 S4E V2 Hi-Carb Superchiller 220V / 60Hz This page is intentionally left blank www.lancerbeverage.com Page 2 of 27 Hoshizaki Lancer reserve the right to change specifications without notice Part No: 68000006 012/4 – 23 April 2015 Images are for illustration purposes only as product may vary.
-
Page 3: Table Of Contents
Certificate of Warranty ....................... 26 Manufacturer’s Checklist ....................27 www.lancerbeverage.com Page 3 of 27 Hoshizaki Lancer reserve the right to change specifications without notice Part No: 68000006 012/4 – 23 April 2015 Images are for illustration purposes only as product may vary. -
Page 4: Introduction
2. The Company Hoshizaki Lancer is a wholly owned subsidiary of Lancer Corporation, a world leader in the supply of Beverage Dispensing Equipment based in San Antonio, Texas. Lancer has manufacturing bases and distribution networks in 97 countries. -
Page 5: Specifications
Casters (79602411). Height with casters 765mm www.lancerbeverage.com Page 5 of 27 Hoshizaki Lancer reserve the right to change specifications without notice Part No: 68000006 012/4 – 23 April 2015 Images are for illustration purposes only as product may vary. -
Page 6: Superchiller Safety Information
Page 6 of 27 Hoshizaki Lancer reserve the right to change specifications without notice Part No: 68000006 012/4 – 23 April 2015 Images are for illustration purposes only as product may vary. -
Page 7: Service & Maintenance
If damage exists, have carrier note damage on bill of landing and file a claim with the carrier. www.lancerbeverage.com Page 7 of 27 Hoshizaki Lancer reserve the right to change specifications without notice Part No: 68000006 012/4 – 23 April 2015 Images are for illustration purposes only as product may vary. -
Page 8: Unpacking
The Superchiller must always be handled in a vertical position. Carefully unpack the Lancer S4E Superchiller from the shipping carton, remove the wooden base. If appropriate, assemble legs to unit by carefully tilting (tilt should not be more than 45°). - Page 9 (i.e. double pass of soda circuit out and back from dispense point to soda return). www.lancerbeverage.com Page 9 of 27 Hoshizaki Lancer reserve the right to change specifications without notice Part No: 68000006 012/4 – 23 April 2015...
-
Page 10: Connecting To Water Supply
Page 10 of 27 Hoshizaki Lancer reserve the right to change specifications without notice Part No: 68000006 012/4 – 23 April 2015 Images are for illustration purposes only as product may vary. -
Page 11: Plumbing The Drain And Co2 Exhaust
Page 11 of 27 Hoshizaki Lancer reserve the right to change specifications without notice Part No: 68000006 012/4 – 23 April 2015 Images are for illustration purposes only as product may vary. - Page 12 Commission and purge system as per clause 6.11 and 6.12. www.lancerbeverage.com Page 12 of 27 Hoshizaki Lancer reserve the right to change specifications without notice Part No: 68000006 012/4 – 23 April 2015 Images are for illustration purposes only as product may vary.
- Page 13 Operate dispensing valves until syrup flows freely. www.lancerbeverage.com Page 13 of 27 Hoshizaki Lancer reserve the right to change specifications without notice Part No: 68000006 012/4 – 23 April 2015 Images are for illustration purposes only as product may vary.
-
Page 14: Postmix Circuit Diagram
S4E V2 Hi-Carb Superchiller 220V / 60Hz 8. Postmix Circuit Diagram www.lancerbeverage.com Page 14 of 27 Hoshizaki Lancer reserve the right to change specifications without notice Part No: 68000006 012/4 – 23 April 2015 Images are for illustration purposes only as product may vary. -
Page 15: Electrical Circuit Diagram
S4E V2 Hi-Carb Superchiller 220V / 60Hz 9. Electrical Circuit Diagram www.lancerbeverage.com Page 15 of 27 Hoshizaki Lancer reserve the right to change specifications without notice Part No: 68000006 012/4 – 23 April 2015 Images are for illustration purposes only as product may vary. -
Page 16: Airflow Diagram
S4E V2 Hi-Carb Superchiller 220V / 60Hz 10. Airflow Diagram www.lancerbeverage.com Page 16 of 27 Hoshizaki Lancer reserve the right to change specifications without notice Part No: 68000006 012/4 – 23 April 2015 Images are for illustration purposes only as product may vary. -
Page 17: Trouble Shooting
Fan not operating. Remove obstruction or replace motor. www.lancerbeverage.com Page 17 of 27 Hoshizaki Lancer reserve the right to change specifications without notice Part No: 68000006 012/4 – 23 April 2015 Images are for illustration purposes only as product may vary. -
Page 18: Troubleshooting - Postmix
135 kpa lower than CO (install water pressure regulator if necessary) www.lancerbeverage.com Page 18 of 27 Hoshizaki Lancer reserve the right to change specifications without notice Part No: 68000006 012/4 – 23 April 2015 Images are for illustration purposes only as product may vary. - Page 19 20. Replace control or probe if defective. www.lancerbeverage.com Page 19 of 27 Hoshizaki Lancer reserve the right to change specifications without notice Part No: 68000006 012/4 – 23 April 2015 Images are for illustration purposes only as product may vary.
-
Page 20: Hydra Icebank Control Go/No Go Test
(Simulates ice growth over black probe only) www.lancerbeverage.com Page 20 of 27 Hoshizaki Lancer reserve the right to change specifications without notice Part No: 68000006 012/4 – 23 April 2015 Images are for illustration purposes only as product may vary. -
Page 21: Hydra Carbonator Level Control Test
(i.e. Water level drops below low level) www.lancerbeverage.com Page 21 of 27 Hoshizaki Lancer reserve the right to change specifications without notice Part No: 68000006 012/4 – 23 April 2015 Images are for illustration purposes only as product may vary. -
Page 22: Assembly Diagrams & Parts List
FRONT PANEL S4E 61000483 REAR UPPER PANEL S4E www.lancerbeverage.com Page 22 of 27 Hoshizaki Lancer reserve the right to change specifications without notice Part No: 68000006 012/4 – 23 April 2015 Images are for illustration purposes only as product may vary. -
Page 23: Postmix Assembly Diagram
S4E V2 Hi-Carb Superchiller 220V / 60Hz 14.2. Postmix Assembly Diagram www.lancerbeverage.com Page 23 of 27 Hoshizaki Lancer reserve the right to change specifications without notice Part No: 68000006 012/4 – 23 April 2015 Images are for illustration purposes only as product may vary. -
Page 24: Refrigeration Parts List
CLAMP TUBES SYRUP 16522334 ICE BANK PROBE www.lancerbeverage.com Page 24 of 27 Hoshizaki Lancer reserve the right to change specifications without notice Part No: 68000006 012/4 – 23 April 2015 Images are for illustration purposes only as product may vary. -
Page 25: Refrigeration Assembly Diagram
S4E V2 Hi-Carb Superchiller 220V / 60Hz 14.4. Refrigeration Assembly Diagram www.lancerbeverage.com Page 25 of 27 Hoshizaki Lancer reserve the right to change specifications without notice Part No: 68000006 012/4 – 23 April 2015 Images are for illustration purposes only as product may vary. -
Page 26: Certificate Of Warranty
Lancer will not normally cover any labour costs associated with a warranty claim. Subject to the approval of the Divisional Sales Manager, Lancer may choose to reimburse the customer for some or all labour costs associated with a warranty claim. Any claim for labour costs must be authorized by Lancer prior to the work being undertaken. -
Page 27: Manufacturer's Checklist
Copy checklist & file, put manual/checklist and pump insulator kit in plastic bag & place in the tank area. Customer asset No. W/O ............... www.lancerbeverage.com Page 27 of 27 Hoshizaki Lancer reserve the right to change specifications without notice Part No: 68000006 012/4 – 23 April 2015 Images are for illustration purposes only as product may vary.
