Air Live MD-3025-IVS Manual

Imotion detection
Hide thumbs Also See for MD-3025-IVS:

Advertisement

Quick Links

Download this manual See also: User Manual, Manual
MD-3025-IVS
iMotion Detection
Guide
Version 1.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the MD-3025-IVS and is the answer not in the manual?

Questions and answers

Related Manuals for Air Live MD-3025-IVS

Summary of Contents for Air Live MD-3025-IVS

  • Page 1 MD-3025-IVS iMotion Detection Guide Version 1.0...
  • Page 2 Detection Guide 1. Overview The MD-3025-IVS has built-in video analytic function for intelligent motion detection. It is a standalone function built into the camera’s firmware without the need for external software or device. The iMotion detection function can be used to detect specific or any moving objects.

  • Page 3: Hardware Installation Guidelines

    MD-3025-IVS iMotion Detection Setup Guide 2. Hardware Installation Guidelines  It is recommended to have at least 2.6 meter of vertical clearance (from floor to ceiling) for best performance. However, if your environment cannot meet the recommended conditions, it can still work with reasonable accuracy.

  • Page 4: Camera Configuration

    MD-3025-IVS iMotion Detection Setup Guide 3. Camera Configuration 3.1 Finding camera using AirLive IP Wizard The IPCAM’s default IP address is 192.168.1.100，but this address can change when there is DHCP server(router) in your network. Therefore, please install AirLive IP wizard to find your camera.
  • Page 5 MD-3025-IVS iMotion Detection Setup Guide 2. Click on “Video” on the left menu bar and select “enable” Intelligent Video Analytics. 3.3 Setting Resolution and Frame Rate On the video page, it is important to set the resolution and frame rate correctly.
  • Page 6 MD-3025-IVS iMotion Detection Setup Guide 3.4 Configure iMotion Detection Function Please go to “Video Analytics” menu and select “iMotion Detection” Below is the main page of iMotion Detection.
  • Page 7 MD-3025-IVS iMotion Detection Setup Guide Zone Area Zone Settings Please remember to press “Apply” after change settings, otherwise the settings won’t take effect. The first step is to set the zones according to your environment. The controls are separated in Zone Area and Zone Settings as indicated above.
  • Page 8 MD-3025-IVS iMotion Detection Setup Guide Click left mouse button to set each position Click right mouse button to complete a zone when you finish a last position setting. After you set the zone area correctly, the next step is to calibrate the object size according to your installation.
  • Page 9 MD-3025-IVS iMotion Detection Setup Guide Other Important Settings  Detect: Please keep on “Anything” for an accurate detection.  Sensitivity: “Moderate” is the recommended settings  Statistic Chart Display: When enabled, it will show the result in a statistic graph. It is not recommended to turn on this function as it might use a lot of CPU resource which can influence the performance.
  • Page 10 MD-3025-IVS iMotion Detection Setup Guide 3. Go to “Video Analytics” and “iMotion Detection”. You can change the “Interval” to have the time interval between events. 4. Now, please click on “Set Event Action”. Click on “Add”. Then the following screen will appear.
  • Page 11 MD-3025-IVS iMotion Detection Setup Guide...
