- Page 1 PV Series Owner’s Manual Photo Tripod...
- Page 2 Thank you for choosing Magnus. Congratulations on the purchase of your new Magnus tripod. This tripod features an adjustable center column for smooth and precise camera height adjustment, and telescoping legs with flip-locks for fast and easy leg adjustments. The three-way pan &...
-
Page 3: The Camera
Opening the Tripod Always extend the legs from the top flip-locks first. Pull out on each flip-lock and extend the legs to the desired height. Relock each leg (Fig. A-B) Figure A Figure B Rotate the locking knob counterclockwise to release the center brace, and gently pull the legs out. - Page 4 Make sure the screwhead handle is flat against the bottom of the quick-release plate. Mount the camera/quick-release plate assembly to the tripod head by pulling and holding back on the plate locking lever. Insert the camera/ quick-release plate assembly and push the plate locking lever to lock it in place (Fig.
- Page 5 To change the camera orientation from horizontal to vertical position, loosen the platform locking knob by rotating it counterclockwise. Rotate the platform 90°, and then rotate the platform locking knob clockwise to lock the new position (Fig. I) Figure I adjusting the Center Column Height To raise or lower the center column, loosen the center column collar by rotating it counterclockwise...
- Page 6 To obtain warranty coverage, contact the Magnus Customer Service Department to obtain a return merchandise authorization (“RMA”) number, and return the defective product to Magnus along with the RMA number and proof of purchase. Shipment of the defective product is at the purchaser’s own risk and expense.
