- Page 1 VT-6000 6000H/TL750A Two-Stage Video Tripod with Fluid Head Owner’s Manual...
- Page 2 Thank you for choosing Magnus. The Magnus REX VT-6000 tripod is designed with features that professional videographers and cinematographers require of their camera-support systems. It’s constructed with sturdy, high-grade aluminum legs with flip locks that provide stable support in the most demanding environments.
-
Page 3: Specifications
Specifications General Load Capacity: 17 lb. (7.7 kg) Maximum Working Height: 65 in. (165.1 cm) Minimum Working Height: 29.3 in. (74.4 cm) Folded Length: 33.5 in. (85.1 cm) Weight: 12.2 lb. (5.5 kg) Materials: Anodized aluminum alloy Bubble Level: Yes Head Counterbalance System: Stepped, spring loaded Quick-Release Plate: 4.7 ×... - Page 4 Overview Head (6000H) QR plate release button Quick-release plate Tilt lock Stepped counterbalance control Bubble level Stepped tilt drag control Mounting screw Mounting screw holes Guide pin QR plate locking lever Reversible handle Pan lock Handle locking knob 1/4-20 Mounting hole Stepped pan Handle length adjustment knob drag control...
- Page 5 Tripod (TL750A) 75 mm bowl Also Includes • Shoulder strap • Padded carry case...
-
Page 6: Tilt Control
Operating the VT-6000 Handle Loosen the handle locking knob to adjust the vertical angle of the handle and to turn the handle to adjust the curve angle. Use the length adjustment knob to lengthen or shorten the handle. Tilt Control Turn the tilt lock clockwise to lock the tilting action. -
Page 7: Pan Control
Select 0 to turn the counterbalance tension off. Select higher numbers to increase the tension, depending on the camera’s weight. Heavier cameras should have greater tension. Pan Control Turn the pan lock clockwise to lock the panning motion. Stepped pan drag control: Select 0 to turn the pan drag off. Select higher numbers to increase the pan drag tension, depending on the desired panning speed. - Page 8 Customer Service Department to obtain a return merchandise authorization (“RMA”) number, and return the defective product to Magnus along with the RMA number and proof of purchase. Shipment of the defective product is at the purchaser’s own risk and expense.
