- Page 1 TR-13 Owner’s Manual Travel Tripod...
- Page 2 Thank you for choosing Magnus. The Magnus TR-13 Travel tripod is the perfect lightweight travel companion when you’re on the go. This tripod features a dual-action ballhead with pan control for precise aim. An Arca-type quick release plate allows you to quickly and effortlessly mount or swap your cameras.
- Page 3 Opening the Tripod Fold the legs down until the angle locks click into place. Make sure all the legs are set to the same angle. Open the flip locks, and extend each leg to the desired height. Relock each leg. Always extend the legs from the top flip-locks first.
- Page 4 Operating the Ballhead Important! Always support the camera with one hand when loosening the tilt locking knob. To adjust the tilt, loosen the ball locking knob, and change the position of the camera. For 90° portrait orientation, loosen the ball locking knob, and place the ballhead into the 90°...
- Page 5 Reversing the Center Column Unscrew the counterweight hook from the bottom of the center column. Loosen the center column locking collar, and remove the center column from the tripod. Align the channel on the side of the center column with the notch in the center column hole, and insert the bottom of the center column up through the...
-
Page 6: User Cautions
To obtain warranty coverage, contact the Magnus Customer Service Department to obtain a return merchandise authorization (“RMA”) number, and return the defective product to Magnus along with the RMA number and proof of purchase. Shipment of the defective product is at the purchaser’s own risk and expense.
