- Page 1 EASyS Technical Manual EASyS seating system - Ergonomic Adjustment and Safety System • Models • Positioning supports & harnesses • Safety & protection • Accessory for J chassis...
-
Page 2: Table Of Contents
Thomashilfen, the specialist for rehabilitation strollers, spent several years researching and testing solutions for the weak points and risk factors around the subjects sitting, lying and transportation, with a team of clinical professionals and engineers. -
Page 3: Easys 1 + 2 Seating System
MODELS EASyS 1 seating system Item code 6609/5 Seat depth 19 - 30 cm / 7.5 - 11.8" Seat width 19 - 31 cm / 7.5 - 12.2" Back height 40 - 65 cm / 15.7 - 25.6" Lower leg length 17 - 30 cm / 6.7 - 11.8"... -
Page 4: J Chassis With Easys Seat Unit 1 + 2
MODELS J chassis, size 1 size 2 swivel front wheels Item code chassis and seat unit 6603/5 + 6609/5 6703/5 + 6709/5 Item code complete stroller 6601/5 6701/5 Seat tilt-in-space -10° to +45° -10° to +40° Seat height 48 cm / 18.9" 54 cm / 21.3"... -
Page 5: Standard Underframe For Indoor Use With Easys Seat Unit 1 + 2
MODELS Q hi/low base Q extra low Q standard Q special Item code chassis and seat unit 6665/5 + 6609/5 6666/5 + 6609/5 6709/5 6664/5 + 6609/5 6709/5 Seat tilt-in-space -28° to +2° -28° to +2° -28° to +2° Seat height (including seat unit) 25 - 62 cm 30 - 66 cm 44 - 74 cm 9.8 - 24.4"... -
Page 6: Butterfly / Chest Harness
POSITIONING SUPPORTS & HARNESSES Butterfly/chest harness EASyS 1 EASyS 2 Item code 6616/41(small: S); 6617/41(medium: M) 6717/41(large: L); 6617/41(medium:M) Size of pad (w x h) S: 11.5 x 12.5 cm; M: 10.5 x 13.5 cm L: 12 x 17 cm; M: 10.5 x 13.5 cm S: 4.5 x 4.9";... -
Page 7: Lateral Head Supports, Flexible With Chest Belt
POSITIONING SUPPORTS & HARNESSES Lateral trunk supports EASyS 1 EASyS 2 with chest belt Item code 6633/5 6633/5 Support surface (h x d) 9 x 19 cm / 3.5 x 7.5" 9 x 19 cm / 3.5 x 7.5" Adjustment range (to each other) 17 - 27 cm / 6.7 - 10.6"... -
Page 8: Lateral Head Supports
POSITIONING SUPPORTS & HARNESSES Lateral head supports EASyS 1 EASyS 2 Item code 6624/4 6724/4 Size (h x d) 13 x 11 cm / 5.1 x 4.3" 15 x 14 cm / 5.9 x 5.5" Adjustment range (to each other) 17 - 27 cm / 6.7 - 10.6"... -
Page 9: Grip Rail
POSITIONING SUPPORTS & HARNESSES Grip rail EASyS 1 EASyS 2 Item code 6621/4 6721/4 Height to seating surface 11.5 / 14 / 16.5 cm 17.5 / 19 / 22 cm 4.5 / 5.5 / 6.5" 6.9 / 7.5 / 8,66" Width (inner dimension) 34 cm / 13.4"... -
Page 10: Sleeping Bag (Padded And Woven Fur)
SAFETY & PROTECTION Sleeping bag, EASyS 1 EASyS 2 padded Item code 6619/4 6719/4 Bottom part of leg blanket (w x l) 35 x (68 - 80) cm 40 x (90 - 104) cm 13.8 x (26.8 - 31.5)" 15.7 x (35.4 - 40.9)" Leg blanket ( 31 cm / 12.2"... -
Page 11: Rain Cape
SAFETY & PROTECTION Rain cape EASyS 1 EASyS 2 Item code 6340/4 6540/4 Length of blanket (without hood) 125 cm / 49.2" 140 cm / 55.1" Weight 0.36 kg / 0.79 Ib 0.46 kg / 1.01 Ib Material hydrophobic synthethic fibre Fixation elastic Umbrella... -
Page 12: Tray, Transparent
SAFETY & PROTECTION Tray, EASyS 1 EASyS 2 transparent Item code 6628/4 6728/4 Size (w x l) 56 x 33.2 cm / 22.0 x 13,0" 60 x 36.2cm / 23.6 x 14,2" Height to seat surface 15 - 22 cm / 5.9 - 8.7" 15 - 22 cm / 5.9 - 8.7"... -
Page 13: Transit Tie Down System J Chassis 1
ACCESSORY FOR J CHASSIS Transit tie down system J chassis 1 J chassis 2 swivel front wheels swivel front wheels Item code 970066840 970067840 Norm ISO 7176/19 and ANSI/RESNA WC/vol. 1 - Section 19 6/22/99 Draft Material steel Fixation firmly attached to chassis Hint restraint system not included in delivery For further information please call: +49 (0) 47 61 / 8 86-68 or -63... - Page 14 NOTES...
- Page 15 NOTES...
- Page 16 Support Association for the Rehabilitation of Children and Youths e.V. Walkmühlenstraße 1 · D - 27432 Bremervörde Phone: +49 (0) 47 61 / 8 86-68 or -63 · Fax: +49 (0) 47 61 / 8 86-19 E-mail: info@thomashilfen.de · www.thomashilfen.com...
