Electric Screwdrivers
and Power Supply
Operation Manuals
Clutch Type Torque Auto Control
CL-Series
SS-Series
α
-Series
Q-CR-ESD Type • Q Type
111-6, Akiyama, Matsudo City, Chiba, Pref. Japan
TEL. 81-47-392-2001 FAX. 81-47-392-7773
15
A
(September, 2015)
CL-2000, CL-3000, CL-4000,
CL-6000, CL-6500 and CL-7000
(NL-Series and Push-to-Start Type)
SS-2000, SS-3000, SS-4000,
SS-6500 and SS-7000
(Push-to-Start Type)
α
α
-4500,
-5000 and
(Push-to-Start Type)
ESD Type •
HIOS Inc.
α
-6500
Operation Manual No.ET-A002
Utilizing 100％ post-consumer
recycled paper pulp
Advertisement
Table of Contents
Related Manuals for HIOS CL-2000
Summary of Contents for HIOS CL-2000
- Page 1 Electric Screwdrivers and Power Supply Operation Manuals (September, 2015) Clutch Type Torque Auto Control CL-Series CL-2000, CL-3000, CL-4000, CL-6000, CL-6500 and CL-7000 (NL-Series and Push-to-Start Type) SS-Series SS-2000, SS-3000, SS-4000, SS-6500 and SS-7000 (Push-to-Start Type) α α α α -Series...
-
Page 2: Name Of Parts
Thank you for your purchasing a Hios screwdriver. 1. Name of Parts cord cord Detachable cord (5P both ends common) Joint ring Forward/ Connector Reverse switch Carbon brush cap Carbon brush Switch lever Carbon brush Forward/Reverse switch Switch lever Carbon brush cap... -
Page 3: Specifications
3. Specifications CL-Series (NL-Series, ESD, Q-CR-ESD, Q, PS-Type) Model CL-2000 CL-3000 CL-4000 CL-6000 CL-6500 CL-7000 0.02 - 0.2 0.03 - 0.2 0.1 - 0.55 0.2 - 1 0.3 - 1.6 0.3 - 2.5 Output Torque 0.17 - 1.7 0.3 - 1.7 0.9 - 4.8... - Page 4 (1) Do not drop it or otherwise subject it to excessive shock. (2) Be careful not to splash water or oil. (3) Use HIOS power supplies units. We are not respon- sible for any malfunctions or troubles caused by using power units other than specified.
-
Page 5: How To Operate
M3 x 3 set screw there and tighten it. Return band to original position. ● The torque adjusting nuts of the CL-2000, CL-3000, CL-4000 can be locked by aligning the red mark on the outer casing with any one of two vertical grooves (or three grooves for the standard-type screwdriver) of the bolt located nearest the torque adjusting scale. -
Page 6: Power Supplies
● The CL-2000 (SS-2000) Electric Screwdriver have ‘Double nut system’ (Nut fixing ring and Torque adjust- ing nut) to avoid loosening from shock or vibration to the driver. To adjust those two nuts, follows ① to ③ steps below. ①... - Page 7 CLT-45 Connects to one CL, SS or α -series driver. (except the CL- α 7000, SS-7000, -6500, CL-9000 model). CLT-45 CLT-60 Connects to one CL, SS or α -series driver. (except CL-9000 CLT-60 model). CLT-100 Connects to two CL, SS or α...
- Page 8 MC-70L (requires separate control box) ■ Max. number of connected drivers: Type max. number of drivers Note CL-2000, 3000, 4000 20 pcs. SS-2000, 3000, 4000 CL-6000, 6500, 7000 Each driver must be connected SS-6500, 7000 10 pcs. to CB-105 (Control Box ).
- Page 9 7. How to connect a control Box ● There are two pairs of output terminals, two (+) and two (-), on the back of the body case. They are pro- vided to divide main wires to two directions from the main unit.
-
Page 10: How To Replace Carbon Brushes
Trunk line wires Branch Black wires Black Power pack MC-70L CB-105 (SUB) Control box CB-105 (SUB) • U-Element Parts No.: MCLK-560B • Branch wire Parts No.: RED: MCCBS-RD BLACK: MCCBS-BK • Trunk-line wire Parts No.: RED: MCCBM-RD BLACK: MCCBM-BK 8. How to replace carbon brushes 1. - Page 11 ■ Proper guidance on output torque (at HI input) CL-series (NL-Series, ESD, Q-CR-ESD, Q, PS-Type ) SS-series (ESD, Q-CR-ESD, Q, PS-Type) α -series (ESD, Q, PS-Type) α * Since -series screwdrivers feature high-speed rotation, their tightening torque may differ from the setting values depending on the various conditions of screws and parts materials.
