AGP RS130B Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

INSTRUCTION MANUAL

For your personal safety, READ and UNDERSTAND before using.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
Warning:
Tools equipped with over load protection, when motor has
been cut off due to over load, always switch on machine with
no load for at least 20 seconds to reduce temperature before
switch on again to avoid burn out to the motor.
Version:20130628

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RS130B and is the answer not in the manual?

Questions and answers

Related Manuals for AGP RS130B

Summary of Contents for AGP RS130B

  • Page 1: Instruction Manual

    INSTRUCTION MANUAL For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. Warning: Tools equipped with over load protection, when motor has been cut off due to over load, always switch on machine with no load for at least 20 seconds to reduce temperature before switch on again to avoid burn out to the motor.
  • Page 2 Technical data Voltage See machine nameplate No load speed min 1000-2800 Power input 110-120V = 1300W, 220-240V = 1600W Stroke 26mm (1") Insulation Double insulation Class II Weight 3.70 Kgs ( 8.14 Lbs) Lock Button Speed Control Thumbwheel Trigger switch Pivoting shoe plate...
  • Page 3 GENERAL SAFETY INSTRUCTIONS When operating a power tool outdoors, use an extension cord suitable for outdoor use. WARNING! Read all safety warnings and Use of a cord suitable for outdoor use reduces all instructions. Failure to follow the the risk of electric shock. I f o p e rat i n g a p owe r to o l i n a d a m p warnings and instructions may result in location is unavoidable, use an ear th...
  • Page 4 5) SERVICE ensure these are connected and properly used. Use of dust collection can reduce dust-related Have your power tool serviced by a qualified hazards. repair person using only identical replacement parts. This will ensure that the safety of the power 4) POWER TOOL USE AND CARE tool is maintained.

  • Page 5: Specific Safety Rules

    SPECIFIC SAFETY RULES Wear eye and hearing protection. Always use safety glasses. Everyday eyeglasses are Some dust created by power sanding, sawing, NOT safety glasses. USE CERTIFIED SAFETY grinding, drilling, and other construction activities EQUIPMENT. Eye protection equipment contains chemicals known to cause cancer, birth should comply with ANSI Z87.1 standards.

  • Page 6: Selecting The Blade

    FOREWORD machine for best performance or convenience, etc. This Reciprocating Saw is designed for cutting metal up to 20mm (3/4”) thick, wood up to 300mm (12") thick (depending on the blade), and various MOTOR other materials, such as plastics, fiberglass, hard rubber, etc.

  • Page 7: Removing The Blade

    Sometimes you need to turn the quick- prevent from rusting. release collar as shown to ensure the blade is WARNING: NEVER TOUCH BLADE IMMEDIATELY mounted appropriately when there is dust or AFTER USE, AS IT MAY BE HOT ENOUGH TO dirt accumulated on the quick-release collar.

  • Page 8: Soft Start Function

    release the lock, press the switch and release b a c k w a r d , t h e m a c h i n e o n l y c u t s o n t h e backstroke.

  • Page 9: Operation

    BEFORE YOU START TO WORK Hold the front housing with one hand and the rear handle with the other. Select the blade best suited for the material to be To start the cut, rest the saw on the cutting shoe, cut.

  • Page 10: Maintenance

    SAWING METAL THE CARBON BRUSHES When cutting angle metals such as channel The carbon brushes are a normal wearing part and section, I-beam, etc., start the cut in a position must be replaced when they reach their wear limit. where the greatest number of teeth will contact Caution: Always replace the brushes as a pair the work.
  • Page 11 WIRING...

  • Page 12: Exploded View

    EXPLODED VIEW...

  • Page 13: Parts List

    PARTS LIST Parts Name Q'TY Parts Name Q'TY POWER SUPPLY CORD OUTPUT GEAR M1.25 x 47T CORD ARMOR CRANK HEX KEY HOLDER WOODRUFF KEY 5 x 5 x 10 L-HEX WRENCH M6 EXTERNAL CIRCLIP R-35 SCREW M4 x 16 BEARING 6003 zz FLAT WASHER ø4 x ø8 x 1 CONNECTING ROD CORD CLIP...
