LSQT1158-T.CH.book 1 ページ 2006年12月26日 火曜日 午前10時18分 使用說明書 Operating Instructions DVD 攝錄放影機 DVD Video Camera VDR-D310GC Model no. VDR-D220GC 使用前,請完整閱讀本說明書。 Before use, please read these instructions completely. LSQT1158 A...
Page 22
LSQT1158-T.CH.book 22 ページ 2006年12月26日 火曜日 午前10時18分 設定 充電時間和可拍攝時間 下表中所示的時間是指溫度為 25 oC,濕度為 60% 時的時間。 如果溫度高於或低於 25 oC,則充電時間 將會變長。 ∫ 充電時間 ≥ 表中所示的充電時間為估計值。 ≥“2 h 25 min”表示 2 小時 25 分鐘。 VDR-D310: 電池型號 電壓/容量 充電時間 提供的電池/ 7.2 V/1150 mAh 2 h 25 min CGA-DU12 (可選件) 7.2 V/1360 mAh 2 h 45 min CGA-DU14 (可選件)...
Page 23
LSQT1158-T.CH.book 23 ページ 2006年12月26日 火曜日 午前10時18分 設定 ∫ 可拍攝時間 (使用 DVD-RAM 光碟時) ≥ 該時間是指使用取景器時的可拍攝時間。 括弧內的時間是指使用 LCD 顯示屏時的可拍攝時間。 ≥ 實際可拍攝時間是指,在重複開始/停止拍攝、開啟/關閉本機、移動變焦桿等時,光碟上的可拍攝 時間。 ≥“1 h 25 min”表示 1 小時 25 分鐘。 VDR-D310: 電池型號 電壓/容量 拍攝模式 最長可連續拍攝時間 實際可拍攝時間 1 h 25 min 35 min (1 h 20 min) (35 min) 提供的電池/...
Page 24
LSQT1158-T.CH.book 24 ページ 2006年12月26日 火曜日 午前10時18分 設定 電池型號 電壓/容量 拍攝模式 最長可連續拍攝時間 實際可拍攝時間 3 h 50 min 1 h 40 min (3 h 30 min) (1 h 35 min) CGA-DU21 7.2 V/ 4 h 30 min 2040 mAh (4 h 5 min) (1 h 50 min) (可選件)...
Page 31
LSQT1158-T.CH.book 31 ページ 2006年12月26日 火曜日 午前10時18分 設定 關於在每個模式中所顯示的操作圖示 關於自動模式和手動模式 (l 38) 影片拍攝模式 1/2 1/2 NEXT 1/2 NEXT NEXT 2/2 2/2 NEXT 2/2 NEXT NEXT 3/3 3/3 NEXT 3/3 NEXT NEXT 4/4 4/4 NEXT 4/4 NEXT NEXT 圖示 方向 功能 頁碼 背光補償 (1/2) 淡入淡出...
Page 32
LSQT1158-T.CH.book 32 ページ 2006年12月26日 火曜日 午前10時18分 設定 相片拍攝模式 1/2 1/2 NEXT 1/2 NEXT NEXT 2/2 2/2 NEXT 2/2 NEXT NEXT 3/3 3/3 NEXT 3/3 NEXT NEXT 4/4 4/4 NEXT 4/4 NEXT NEXT 圖示 方向 功能 頁碼 背光補償 Ø (1/2) 自拍計時器 幫助模式 柔化肌膚模式 (2/2) 遠攝微距...
LSQT1158-T.CH.book 34 ページ 2006年12月26日 火曜日 午前10時18分 設定 退出功能表螢幕 向右移動操縱桿或按下操縱桿。 按 MENU 按鈕。 MENU ≥ 拍攝或播放時,不會顯示功能表螢幕。 當顯示 上下移動操縱桿,選擇子功能表選 功能表螢幕時,不能開始其他操作。 項。 用遙控器操作 (VDR-D310) 功能表螢幕的變化與使用主機上的按鈕時是一樣 的。 按 MENU 按鈕。 MENU 向右移動操縱桿或按下操縱桿。 ENTER 選擇一個功能表項。 上下移動操縱桿,選擇需要的選項。 MENU ENTER ≥ 使用方向按鈕 (3,4,2,1) 和 ENTER 按鈕來代 替主機上的操縱桿。 按下操縱桿確認選擇。 按 MENU 按鈕退出功能表螢幕。 MENU ENTER 返回到上一螢幕...
LSQT1158-T.CH.book 49 ページ 2006年12月26日 火曜日 午前10時18分 拍攝 本機可以在約 50 cm 的距離上對目標進行對焦。 按下操縱桿。 然後,向下移動操縱 桿顯示圖例中顯示的圖示。 ¬ 轉動模式轉盤選擇 或 。 按下操縱桿。 然後,向下移動操縱 桿顯示圖例中顯示的圖示。 2/2 2/2 NEXT 2/2 NEXT NEXT 向上移動操縱桿,選擇 [ 2/2 2/2 NEXT 2/2 NEXT NEXT ]。 向右移動操縱桿,選擇 [ ]。 2/2 2/2 NEXT 2/2 NEXT NEXT ≥...
LSQT1158-T.CH.book 52 ページ 2006年12月26日 火曜日 午前10時18分 拍攝 ] 水上及雪地 向下移動開關,將其設定到 FOCUS 用於在亮處拍攝影像,如滑雪場及海灘 位置。 取消場景模式功能 按 MENU 按鈕後,選擇 [ 基本功能 ] # [ 場景模式 ] # [ 關 ],然後按下操縱桿。 ≥ 也可以通過將 AUTO/MANUAL/FOCUS 開關設 定為 AUTO 取消場景模式功能。 4/4 4/4 NEXT 4/4 NEXT NEXT 出現圖例中顯示的手動對焦指示 [MF] 和圖示。 運動模式...
Page 53
LSQT1158-T.CH.book 53 ページ 2006年12月26日 火曜日 午前10時18分 拍攝 將 AUTO/MANUAL/FOCUS 開關設 定為 MANUAL。 手動設定白平衡 選擇 [ ],用白色物體填滿螢幕。 3/3 3/3 NEXT 3/3 NEXT NEXT 自動顯示圖例中顯示的圖示。 BACK BACK BACK BACK 向上移動操縱桿,選擇 [ ]。 向上移動操縱桿,選擇 [ ]。 3/3 3/3 NEXT 3/3 NEXT NEXT BACK BACK BACK 當...
LSQT1158_EN.book 100 ページ 2006年12月26日 火曜日 午前10時30分 Information for Your Safety The socket outlet shall be installed near the equipment and easily accessible. WARNING: The mains plug of the power supply cord shall TO REDUCE THE RISK OF FIRE, remain readily operable. ELECTRIC SHOCK OR PRODUCT To completely disconnect this apparatus from DAMAGE, the AC Mains, disconnect the power supply...
Page 101
LSQT1158_EN.book 101 ページ 2006年12月26日 火曜日 午前10時30分 ENGLISH -If you see this symbol- ∫ How to replace the Fuse Information on Disposal in other Countries The location of the fuse differ according to the outside the European Union type of AC mains plug (figures A and B). Confirm the AC mains plug fitted and follow This symbol is only valid in the the instructions below.
Page 102
LSQT1158_EN.book 102 ページ 2006年12月26日 火曜日 午前10時30分 ∫ Indemnity concerning recording ≥ Depending on the model, some functions are not available. content ≥ Features may vary, so please read carefully. The manufacturer shall in no event be liable for the loss of recordings due to malfunction or defect of this unit, its accessories or recordable media.
Page 103
LSQT1158_EN.book 103 ページ 2006年12月26日 火曜日 午前10時30分 Soft skin mode ........148 Contents Tele macro function (VDR-D310) ... 148 Colour night view function...... 149 Self-timer recording........ 149 Information for Your Safety....100 Recording guideline function....150 Before using Wide mode..........150 Image stabilizer function ......150 Wind noise reduction function....
Page 104
LSQT1158_EN.book 104 ページ 2006年12月26日 火曜日 午前10時30分 With other products With a TV..........176 Playback on TV ........176 With a DVD recorder/player....177 Playback on DVD recorder, DVD player, computer etc......177 Dubbing recordings onto a DVD recorder’s hard disk ....178 With a VCR.......... 179 Dubbing images onto other video devices ......179 With a printer (PictBridge)....
LSQT1158_EN.book 105 ページ 2006年12月26日 火曜日 午前10時30分 Before using Before using Features ∫ Easy recording! (l 138) No need to search for the recording start position. The new recording will not overwrite any previously recorded scene. ∫ Easy playback! (l 156) Recorded scenes are displayed as thumbnails. You can easily search for the scenes you want to watch.
Page 106
LSQT1158_EN.book 106 ページ 2006年12月26日 火曜日 午前10時30分 Before using If you insert a DVD-RW or a DVD-R disc recorded in this unit (that has not been finalized) into another device such as DVD recorder, computer, etc., the disc may become unusable. Be sure to finalize the disc on this unit before inserting it in other devices. (l 172) ∫...
LSQT1158_EN.book 107 ページ 2006年12月26日 火曜日 午前10時30分 Before using Accessories Optional accessories Check the accessories before using this unit. Some optional accessories may not be available Battery pack in some countries. (VDR-D310) AC adaptor (VW-AD11E/EB) Battery pack (VDR-D220) Battery pack (lithium/CGR-DU06/640 mAh) (VDR-D220) AC adaptor Battery pack (lithium/CGA-DU12/1150 mAh) Battery pack (lithium/CGA-DU14/1360 mAh)
LSQT1158_EN.book 109 ページ 2006年12月26日 火曜日 午前10時30分 Before using 34 Disc compartment (l 125) 35 Grip belt (l 109) 23 LCD monitor (l 111) Using grip belt Due to limitations in LCD production technology, there may be some tiny bright Adjust the belt length so it fits your hand. or dark spots on the LCD monitor screen.
LSQT1158_EN.book 110 ページ 2006年12月26日 火曜日 午前10時30分 Before using Pass the end of the lens cap cord through the belt. Lens hood ∫ VDR-D310 Rotate the lens hood counter- clockwise A to remove it. In order to attach it, place into slot B, and then rotate it clockwise C. Pass the lens cap through the loop.
LSQT1158_EN.book 111 ページ 2006年12月26日 火曜日 午前10時30分 Before using ≥ When 2 lens accessories, such as the ND filter (Please carefully read the operating instructions and tele conversion lens, are attached and the for how to attach the unit to the tripod.) W/T lever is pressed toward the W side, the 4 corners of an image will be darkened.
LSQT1158_EN.book 112 ページ 2006年12月26日 火曜日 午前10時30分 Before using ≥ The brightness and colour level of the LCD Using the remote control monitor can be adjusted from the menu. (VDR-D310) (l 135) ≥ The unit may be damaged or fail if the LCD monitor is forcibly opened or rotated.
LSQT1158_EN.book 113 ページ 2006年12月26日 火曜日 午前10時30分 Before using While pressing the stopper A, ∫ Remote control usable range pull out the battery holder. The distance between the remote control and the unit’s remote control sensor A: Within approx. Angle: Approx. 10o up and 15o down, left, and right Set the button-type battery with its (r) mark facing upward and...
LSQT1158_EN.book 114 ページ 2006年12月26日 火曜日 午前10時30分 Before using Discs and cards Discs that can be used on this unit Disc type DVD-RAM DVD-RW 8 cm 8 cm Single sided/ Single sided/double sided double sided (DVD-RAM [DVD-RW Ver. 1.1/2X-SPEED (2X/1X)] Ver. 2.1) Recording format DVD Video DVD Video DVD-Video format...
Page 115
LSQT1158_EN.book 115 ページ 2006年12月26日 火曜日 午前10時30分 Before using Disc type DVD-R DVD-R DL 8 cm 8 cm Single sided/double sided Dual layer on single side (DVD-R for General Ver. 2.0) (DVD-R for DL Ver. 3.0) Recording format DVD-Video format DVD-Video format (Video format) (Video format) Characteristic One time recording disc...
Page 116
≥ Discs inserted in a holder, cartridge, or caddy case cannot be used. Always remove bare discs from these containers prior to use. ≥ It is recommended that you use Panasonic discs. Usually discs compatible with the DVD standard can be used for recording and playback with no problems. However, some commercially available discs do not meet the DVD standard for quality and performance.
Page 117
LSQT1158_EN.book 117 ページ 2006年12月26日 火曜日 午前10時30分 Before using When using brand-new DVD-RW When using DVD-RW, select whether to record in DVD Video Recording format (VR format) or DVD- Video format (Video format) and then format the disc. (l 116, About format types) When a brand-new DVD-RW is inserted in this unit, the screen on the right appears.
SD card. (l 174) ≥ We recommend that you use a Panasonic brand SD card. ≥ When the write-protect switch A on SD card is locked, no recording, deletion or editing will be possible on the card.
LSQT1158_EN.book 119 ページ 2006年12月26日 火曜日 午前10時30分 Before using Disc and card handling ∫ How to hold a disc or card Do not touch the recording/playback surface or the terminal surface. ∫ When inserting/removing a disc Do not allow the recording/playback side of the disc to get fingerprints or dirty. ≥...
Dispose of used batteries normal. according to the manufacturer’s instructions. ≥ Battery charging time (l 121) ≥ We recommend using Panasonic batteries. (l 107) ≥ If you use other batteries, we cannot guarantee the quality of this product. LSQT1158...
LSQT1158_EN.book 121 ページ 2006年12月26日 火曜日 午前10時30分 Setup Charging time and recordable time The times shown in the tables below are for when the temperature is 25 oC and the humidity is 60%. If the temperature is higher or lower than 25 oC, the charging time will become longer. ∫...
Page 122
LSQT1158_EN.book 122 ページ 2006年12月26日 火曜日 午前10時30分 Setup ∫ Recordable time (When using a DVD-RAM disc) ≥ The times indicate the recordable time when the viewfinder is used. The times in parentheses indicate the recordable time when the LCD monitor is used. ≥ The actual recordable time refers to the recordable time on a disc when repeatedly starting/stopping recording, turning the unit on/off, moving the zoom lever, etc.
Page 123
LSQT1158_EN.book 123 ページ 2006年12月26日 火曜日 午前10時30分 Setup Maximum Battery model Voltage/ Recording Actual recordable continuously number capacity mode time recordable time 2 h 35 min 1 h 5 min (2 h 20 min) (1 h) CGA-DU14 7.2 V/ 1 h 20 min (optional) 1360 mAh (2 h 40 min)
LSQT1158_EN.book 124 ページ 2006年12月26日 火曜日 午前10時30分 Setup Connecting to the AC outlet How to turn on the power While pressing the button A, set the The unit is in the standby condition when the AC adaptor is connected. The primary circuit is OFF/ON switch to ON.
LSQT1158_EN.book 125 ページ 2006年12月26日 火曜日 午前10時30分 Setup ∫ To turn off the power Close the LCD monitor and retract When the power is turned on for the first time after changing the disc or battery, the unit the viewfinder. carries out a recognition procedure to check that there are no problems with the disc.
Page 126
LSQT1158_EN.book 126 ページ 2006年12月26日 火曜日 午前10時30分 Setup A few moments after the ACCESS/PC lamp ∫ Removing disc blinks, the cover of the disc compartment will While pressing down on the spindle, grasp the open slightly. edge of the disc and gently lift it out. Open the cover of the disc compartment by hand and insert/ remove the disc.
LSQT1158_EN.book 127 ページ 2006年12月26日 火曜日 午前10時30分 Setup “SIDE B” recording/playback side is the side with touch the area around the pickup lens for it the “SIDE A” mark. becomes extremely hot. After inserting a disc/After recording finishes While the ACCESS/PC lamp is lit, the disc is rotating and disc information is being recorded.
LSQT1158_EN.book 128 ページ 2006年12月26日 火曜日 午前10時30分 Setup Insert/remove the SD card into/ Selecting a mode from the card slot. The mode dial is used to switch between recording and playback modes. Rotate the mode dial slowly but surely. Rotate the mode dial, and set the desired mode pictograph to the position shown in the illustration.
Page 129
LSQT1158_EN.book 129 ページ 2006年12月26日 火曜日 午前10時30分 Setup Move the joystick up, down, left, or Move the joystick up, down, left right to select an item or scene, and or right to select the scene to be then press the joystick to set it. played back and press the joystick.
Page 130
LSQT1158_EN.book 130 ページ 2006年12月26日 火曜日 午前10時30分 Setup About the operation icons displayed in each mode About auto mode and manual mode (l 137) Video recording mode 1/2 1/2 NEXT 1/2 NEXT NEXT 2/2 2/2 NEXT 2/2 NEXT NEXT 3/3 3/3 NEXT 3/3 NEXT NEXT 4/4 4/4 NEXT 4/4 NEXT...
Page 131
LSQT1158_EN.book 131 ページ 2006年12月26日 火曜日 午前10時30分 Setup Picture recording mode 1/2 1/2 NEXT 1/2 NEXT NEXT 2/2 2/2 NEXT 2/2 NEXT NEXT 3/3 3/3 NEXT 3/3 NEXT NEXT 4/4 4/4 NEXT 4/4 NEXT NEXT Icon Direction Function Page Backlight compensation Ø Self timer (1/2) Help mode Soft skin mode...
LSQT1158_EN.book 132 ページ 2006年12月26日 火曜日 午前10時30分 Setup ∫ Help mode ≥ When the help mode is used, functions cannot The help mode explains the operation icons that be set. are displayed when the AUTO/MANUAL/FOCUS ≥ When the help mode is used, motion pictures switch is set to AUTO in video/picture recording and still pictures cannot be recorded.
Page 133
LSQT1158_EN.book 133 ページ 2006年12月26日 火曜日 午前10時30分 Setup Move the joystick up or down in Press the joystick to enter the order to select the desired top selection. menu. To get back to the previous screen Move the joystick left. Move the joystick right or press the joystick.
LSQT1158_EN.book 134 ページ 2006年12月26日 火曜日 午前10時30分 Setup move the joystick up or down to ≥ Use the direction buttons (3,4,2,1) and ENTER button in place of the joystick on the set the desired value. main unit. Press the MENU button to exit the menu screen.
LSQT1158_EN.book 135 ページ 2006年12月26日 火曜日 午前10時30分 Setup Then, move the joystick left or ≥ The date and time function are driven by a right to make the adjustment. built-in lithium battery. ≥ Make sure to check the time before recording. ≥ If the time display becomes [- -], the built-in lithium battery has run down.
LSQT1158_EN.book 136 ページ 2006年12月26日 火曜日 午前10時30分 Recording Recording Before recording Basic camera positioning 1 Hold the camera with both hands. 2 Put your hand through the grip belt. 3 Do not cover the microphones or sensors with your hands. 4 Keep your arms near your body. 5 Slightly open your legs.
Page 137
LSQT1158_EN.book 137 ページ 2006年12月26日 火曜日 午前10時30分 Recording ∫ About auto mode Set the AUTO/MANUAL/FOCUS switch to AUTO, and colour balance (white balance) and focusing will be adjusted automatically. jAuto white balance (l 198) jAuto focusing (l 199) Depending on the brightness of the subject etc., the aperture and shutter speed are automatically adjusted for an optimum brightness.
LSQT1158_EN.book 138 ページ 2006年12月26日 火曜日 午前10時30分 Recording Recording motion pictures (RAM) (-RW‹VR›) (-RW‹V›) (-R) Record motion pictures onto a disc. ≥ When the unit is purchased, the aspect ratio is set to [16:9] for recording images compatible with a wide-screen TV. To watch images on a regular TV (4:3), change the aspect ratio setting (l 150) before recording the images or when watching them on the connected TV (l 176).
LSQT1158_EN.book 139 ページ 2006年12月26日 火曜日 午前10時30分 Recording ≥ When about 5 minutes have passed without any operation in recording pause, the unit automatically turns off to prevent the battery from running down. When you want to use the unit, turn it on again. This setting can also be set to [OFF].
Page 140
LSQT1158_EN.book 140 ページ 2006年12月26日 火曜日 午前10時30分 Recording ∫ Approximate recordable time for 1 disc (single sided) Recording mode Disc type (High quality) (Normal) (Long play) DVD-RAM Approx. 18 min Approx. 37 min Approx. 75 min DVD-R DL Approx. 35 min Approx. 69 min Approx.
LSQT1158_EN.book 141 ページ 2006年12月26日 火曜日 午前10時30分 Recording Recording still pictures (JPEG still pictures) (SD) Record the still picture on an SD card. ≥ When this unit is purchased, [PICTURE SIZE] is set to [ ] (VDR-D310)/[ ] (VDR-D220) for recording pictures compatible with a wide-screen TV (16:9). To record pictures with a 4:3 aspect ratio, change the [PICTURE SIZE] setting before recording (l 144).
Page 142
LSQT1158_EN.book 142 ページ 2006年12月26日 火曜日 午前10時30分 Recording A Shutter chance mark ± (The white lamp flashes.): Focusing ¥ (The green lamp lights up.): When in focus No mark: When focusing is unsuccessful. ≥ The shutter chance mark is indicated as follows when the button is not pressed halfway.
Page 143
LSQT1158_EN.book 143 ページ 2006年12月26日 火曜日 午前10時30分 Recording ≥ When recording still pictures, hold the unit firmly with your hands and keep your arms stationary at your side so as not to shake the unit. ≥ You can record stable pictures without shaking by using a tripod and the remote control. Screen indications in picture recording mode A Remaining number of still pictures (Flashes in red when [R 0] appears.)
LSQT1158_EN.book 144 ページ 2006年12月26日 火曜日 午前10時30分 Recording Number of pixels and picture quality for still picture recording ∫ [PICTURE SIZE] Changing the recording size. Press the MENU button, then select [BASIC] # [PICTURE SIZE] # desired item and press the joystick. MENU VDR-D310: Icon Aspect...
LSQT1158_EN.book 145 ページ 2006年12月26日 火曜日 午前10時30分 Recording Various recording ≥ The zoom speed varies depending on the range over which the zoom lever is moved. functions (The zoom speed does not vary when operating with the remote control.) ≥ When the zoom speed is high, the subject may Zoom in/out function not be focused easily.
LSQT1158_EN.book 146 ページ 2006年12月26日 火曜日 午前10時30分 Recording ≥ This function cannot be used in picture The image is horizontally flipped as if you see a recording mode. mirror image. (However the image recorded is the same as a normal recording.) ≥ Extend the viewfinder to see the picture while To use the zoom microphone recording.
LSQT1158_EN.book 147 ページ 2006年12月26日 火曜日 午前10時30分 Recording Move the joystick up to select Press the recording start/stop [ª]. button. Start recording. (Fade in) 1/2 1/2 NEXT 1/2 NEXT NEXT The image on the screen will become brighter. To return to normal recording Select [ª] again.
LSQT1158_EN.book 148 ページ 2006年12月26日 火曜日 午前10時30分 Recording Soft skin mode Tele macro function (VDR-D310) This makes skin colours appear softer for a more attractive appearance. This is for bringing only what you want to record into focus to take (RAM) (-RW‹VR›) (-RW‹V›) (-R) (SD) close-ups.
LSQT1158_EN.book 149 ページ 2006年12月26日 火曜日 午前10時30分 Recording ≥ In the following cases, the tele macro function is cancelled. ≥ The colour night view function makes the jThe zoom magnification becomes lower than signal charging time of CCD up to 10k. approximately 25k longer than usual, so that jThe power is turned off or the mode dial is dark scenes can be recorded brightly.
LSQT1158_EN.book 150 ページ 2006年12月26日 火曜日 午前10時30分 Recording ≥ If you press the button halfway and then fully, the subject is focused when the button is Wide mode pressed halfway. (VDR-D310) This is for selecting the screen’s ≥ When you press the button fully in auto aspect ratio when recording motion focus mode, the subject is focused just before pictures.
LSQT1158_EN.book 151 ページ 2006年12月26日 火曜日 午前10時30分 Recording Press the MENU button, then select Press the MENU button, then select [ADVANCED] # [O.I.S.] # [ON] and [ADVANCED] # [WIND CUT] # [ON] press the joystick. and press the joystick. MENU MENU To cancel the image stabilizer function To cancel the wind noise reduction Press the MENU button, then select function...
LSQT1158_EN.book 152 ページ 2006年12月26日 火曜日 午前10時30分 Recording Set the AUTO/MANUAL/FOCUS ≥ Avoid recording under fluorescent light, mercury light or sodium light because the switch to MANUAL. colour and brightness of the playback image may change. ≥ If you record a subject illuminated with strong light or a highly reflective subject, vertical lines of light may appear.
LSQT1158_EN.book 153 ページ 2006年12月26日 火曜日 午前10時30分 Recording Move the switch down and set it Set the AUTO/MANUAL/FOCUS to FOCUS position. switch to MANUAL. 4/4 4/4 NEXT 4/4 NEXT NEXT 3/3 3/3 NEXT 3/3 NEXT NEXT The manual focus indication [MF] and the icon The icon shown in the illustration is displayed shown in the illustration appear.
LSQT1158_EN.book 154 ページ 2006年12月26日 火曜日 午前10時30分 Recording will temporarily be black. (The black balance cannot be adjusted manually.) To set the white balance manually Select [ ], fill the screen with a white subject. 1 Black balance adjustment in progress. (Flashes.) 2 White balance adjustment in progress. (Flashes.) BACK BACK...
Page 155
LSQT1158_EN.book 155 ページ 2006年12月26日 火曜日 午前10時30分 Recording Move the joystick left or right to ≥ You may see vertical lines of light in the playback image of a brightly shining subject or select [ ] (aperture) or [ highly reflective subject, but this is not a (shutter speed).
LSQT1158_EN.book 156 ページ 2006年12月26日 火曜日 午前10時30分 Playback Playback Motion picture playback (RAM) (-RW‹VR›) (-RW‹V›) (-R) Play back the motion pictures recorded on the disc. Rotate the mode dial to select The motion pictures recorded on the disc are displayed as thumbnails. Select the scene to be played back. A Scene number B Scroll bar display The selected scene will be encircled by a yellow frame.
Page 157
LSQT1158_EN.book 157 ページ 2006年12月26日 火曜日 午前10時30分 Playback ≥ No sound will be heard except during normal playback. ≥ If pause play is continued for 5 minutes, the screen returns to the thumbnails. ≥ When the amount of time recorded on the scene is short, playback may not be possible. ≥...
Page 158
LSQT1158_EN.book 158 ページ 2006年12月26日 火曜日 午前10時30分 Playback ∫ Operating with the remote control (VDR-D310) Press the E or D button. SEARCH PLAY SEARCH STILL ADV PAUSE STILL ADV SKIP STOP SKIP Frame-by-frame playback The motion picture is advanced one frame at a time. Move the joystick up during playback to pause the playback.
LSQT1158_EN.book 159 ページ 2006年12月26日 火曜日 午前10時30分 Playback Playing back motion pictures by date Recorded scenes are grouped by date on this unit. Scenes recorded on the same day can be played back in succession. Press the MENU button, then select [PLAY SETUP] # [PLAY MODE] # [BY DATE] and press the joystick.
LSQT1158_EN.book 160 ページ 2006年12月26日 火曜日 午前10時30分 Playback Still picture playback (JPEG still pictures) (SD) Play back the still pictures recorded on the card. Rotate the mode dial to select The still pictures recorded on the SD card are displayed as thumbnails. Select the file to be played back. A File number B Scroll bar display The selected file will be encircled by a yellow frame.
Page 161
LSQT1158_EN.book 161 ページ 2006年12月26日 火曜日 午前10時30分 Playback ≥ It takes time to display the file depending on the number of pixels of the file. ≥ When a file is displayed as [ ] on the thumbnail display, playback is not possible. ≥ If you attempt to play back file recorded in a different format or file data is defective, an error message may appear.
LSQT1158_EN.book 162 ページ 2006年12月26日 火曜日 午前10時30分 Editing Select [SELECT] or [ALL] and Editing Editing scenes press the joystick. ≥ When [ALL] is selected, the following scenes will be deleted. Proceed to step 5. Deleting scenes jWhen [PLAY MODE] is set to [VIEW ALL]: This is for deleting scenes recorded All the scenes on the disc on discs.
LSQT1158_EN.book 163 ページ 2006年12月26日 火曜日 午前10時30分 Editing move the joystick down to set the ≥ Do not turn off this unit while deleting. ≥ When you delete scenes, use a battery with dividing point. sufficient battery power or use the AC adaptor. ≥...
LSQT1158_EN.book 164 ページ 2006年12月26日 火曜日 午前10時30分 Editing Select the scene to be combined, ≥ If you create or delete playlists, the original scenes will not be modified. Editing scenes on then press the joystick. a playlist will not affect the original scenes. ≥...
LSQT1158_EN.book 165 ページ 2006年12月26日 火曜日 午前10時30分 Editing Select the scene to be added to [PLAYLIST] # [VIEW LIST] and the playlist, then press the press the joystick. joystick. MENU The selected scene is encircled by a red frame. Select the playlist to be played ≥...
Page 166
LSQT1158_EN.book 166 ページ 2006年12月26日 火曜日 午前10時30分 Editing (Only when [SELECT] is selected in step 2) Select the scene to be deleted, Deleting scenes then press the joystick. ≥ Deleting scenes on a playlist will not affect the original scenes. ∫ Deleting scenes one at a time ¬...
Page 167
LSQT1158_EN.book 167 ページ 2006年12月26日 火曜日 午前10時30分 Editing Press the MENU button, then Press the MENU button, then select [EDIT] # [ADD] # [YES] select [EDIT] # [MOVE] # [YES] and press the joystick. and press the joystick. MENU MENU Select the scene to be added, Select the scene to be moved, then press the joystick.
Page 168
LSQT1158_EN.book 168 ページ 2006年12月26日 火曜日 午前10時30分 Editing Press the MENU button, then select [EDIT] # [DIVIDE] # [YES] Combining scenes and press the joystick. Two consecutive scenes can be combined into one. ≥ Combining scenes on a playlist will not affect the original scenes. MENU ¬...
LSQT1158_EN.book 169 ページ 2006年12月26日 火曜日 午前10時30分 Editing ≥ When [ALL] is selected, all files on the SD card Editing still pictures except the locked files will be erased. Proceed to step 5. Deleting still pictures (Only when [SELECT] is selected in step 2) This is for deleting still picture files Select the file to be deleted, then recorded on SD cards.
LSQT1158_EN.book 170 ページ 2006年12月26日 火曜日 午前10時30分 Editing ≥ If files conforming to DCF standard are deleted, all the data related to the files will be DPOF setting deleted. This is for writing the printing data on an SD card. Locking still pictures This is for preventing still picture files (SD) from being deleted by mistake.
Page 171
LSQT1158_EN.book 171 ページ 2006年12月26日 火曜日 午前10時30分 Editing To cancel all DPOF settings Press the MENU button, then select [PHOTO SETUP] # [DPOF SET] # [CANCEL ALL] and press the joystick. ≥ When the confirmation message appears, select [YES], then press the joystick. ∫...
LSQT1158_EN.book 172 ページ 2006年12月26日 火曜日 午前10時30分 Disc and card management [FINALIZE] # [YES] and press Disc and card management Disc management the joystick. Finalizing a disc It allows the discs to be played on MENU other devices. (-RW‹VR›) (-RW‹V›) (-R) If you insert a DVD-RW or a DVD-R disc recorded in this unit (that has not been finalized) into another device such as DVD When the confirmation message...
LSQT1158_EN.book 173 ページ 2006年12月26日 火曜日 午前10時30分 Disc and card management [DISC PROTECT] and press the joystick. Un-finalizing a DVD-RW This is for un-finalizing a DVD-RW (Video format) so that it can be used for recording. MENU (-RW‹V›) ¬ Rotate the mode dial to select Press the MENU button, then select [DISC SETUP] # When the confirmation message...
LSQT1158_EN.book 174 ページ 2006年12月26日 火曜日 午前10時30分 Disc and card management [FORMAT DISC] # [YES] and press the joystick. Displaying disc information (RAM) (-RW‹VR›) (-RW‹V›) (-R) Information such as the number of recorded MENU scenes, the remaining space and whether or not the disc is finalized or protected is displayed. ¬...
Page 175
LSQT1158_EN.book 175 ページ 2006年12月26日 火曜日 午前10時30分 Disc and card management [FORMAT CARD] # [YES] and press the joystick. MENU When the confirmation message appears, select [YES], then press the joystick. ≥ When formatting is complete, press the MENU button to exit the message screen. ≥...
LSQT1158_EN.book 176 ページ 2006年12月26日 火曜日 午前10時30分 With other products ∫ If the image or audio from this unit is not With other products With a TV output on the TV ≥ Check that the plugs are inserted as far as they Playback on TV ≥...
LSQT1158_EN.book 177 ページ 2006年12月26日 火曜日 午前10時30分 With other products ∫ To display the on-screen information on the TV Playing back a DVD-RAM or a (VDR-D310) DVD-RW (VR format) The information displayed on the screen (RAM) (-RW‹VR›) (operation icon and time code, etc.) can be displayed on the TV.
LSQT1158_EN.book 178 ページ 2006年12月26日 火曜日 午前10時30分 With other products the operating instructions of the playback ≥ If you dub images recorded on a DVD-RW device. (Video format) or a DVD-R disc, the title name ≥ The recording time is not displayed. of the images after dubbing becomes the date they were dubbed.
LSQT1158_EN.book 179 ページ 2006年12月26日 火曜日 午前10時30分 With other products Start playback on this unit. With a VCR Then start recording on the connected device. Dubbing images onto other ≥ See the operating instructions of the video device for details. video devices To stop dubbing (RAM) (-RW‹VR›) (-RW‹V›) (-R) Stop recording on the connected device.
Page 180
LSQT1158_EN.book 180 ページ 2006年12月26日 火曜日 午前10時30分 With other products Select the paper size setting on The USB function selection screen will appear. [PAPER SIZE]. Select [PictBridge] and press the joystick. The [ ] indication appears on this unit’s screen. Select a file to be printed, then press the joystick.
Page 181
LSQT1158_EN.book 181 ページ 2006年12月26日 火曜日 午前10時30分 With other products ≥ Avoid the following operations during printing. These operations disable proper printing. jDisconnecting the USB cable jRemoving the SD card jSwitching the mode dial jTurning off the power ≥ Check the settings for the paper size, quality of print, etc.
LSQT1158_EN.book 184 ページ 2006年12月26日 火曜日 午前10時30分 Others Indications 1 Beep When you start recording When you turn on the power Indications When this unit is recognized by the computer or the printer, etc. ∫ Recording indications 2 Beeps When you pause recording Motion picture recording When you turn off the power 0h00m00s...
Page 186
LSQT1158_EN.book 186 ページ 2006年12月26日 火曜日 午前10時30分 Others Locked still pictures Number of recording pixels for VDR-D310: still pictures 2048k1512 1920k1080 1280k960 640k480 VDR-D220: 640k480 640k360 The picture size is not displayed for still pictures recorded with other products that have different picture sizes from the sizes shown above.
Refer PERFORMANCE to the following support site for information about discs that have PANASONIC DISC IS been confirmed as compatible by Panasonic. RECOMMENDED. http://panasonic.co.jp/pavc/global/cs/e_cam (This website is in English only.) CANNOT RECORD IN AGS The AGS function is activated.
LSQT1158_EN.book 188 ページ 2006年12月26日 火曜日 午前10時30分 Others The SD card is full so no further data can be recorded. Delete CARD FULL. unnecessary files (l 169) or insert a new SD card. PUSH THE RESET SWITCH. An irregularity in the unit has been detected. Press the RESET CHECK THE DISC AFTER button to restart the unit.
LSQT1158_EN.book 189 ページ 2006年12月26日 火曜日 午前10時30分 Others Functions that cannot be used simultaneously Some functions in this unit are disabled or cannot be selected due to the unit’s specifications. The table below shows examples of functions restricted by various conditions. Conditions which Functions disable the functions Digital zoom...
LSQT1158_EN.book 190 ページ 2006年12月26日 火曜日 午前10時30分 Others Frequently asked questions What kind of discs can be used? DVD-RAM, DVD-RW, DVD-R and DVD-R DL can be used if they are 8 cm bare discs. (l 114) Can discs with a cartridge be used? They can be used if the cartridge is removed.
LSQT1158_EN.book 191 ページ 2006年12月26日 火曜日 午前10時30分 Others Troubleshooting Problem Check points ≥ Is the battery fully charged? # Charge the battery using the AC adaptor. (l 120) This unit cannot be ≥ The battery protection circuit may have operated. Attach the turned on. battery to the AC adaptor for 5 to 10 seconds.
Page 192
LSQT1158_EN.book 192 ページ 2006年12月26日 火曜日 午前10時30分 Others Problem Check points The remote control does ≥ Has the button-type battery of the remote control run out? not function. # Replace it with a new button-type battery. (l 112) ≥ The disc cover will not open unless the unit is powered. # Connect a charged battery or AC adaptor.
Page 193
LSQT1158_EN.book 193 ページ 2006年12月26日 火曜日 午前10時30分 Others Problem Check points ≥ Are you trying to record small or finely detailed objects with [PICT.QUALITY] set at [ Recorded still pictures # If you try to record small or finely detailed objects with are not clear. [PICT.QUALITY] set at [ ], the images may break up into a mosaic-like pattern.
Page 194
LSQT1158_EN.book 194 ページ 2006年12月26日 火曜日 午前10時30分 Others Problem Check points ≥ Is this unit connected to a computer? # No operation can be performed on this unit when it is connected The indication to a computer. (VDR-D310) (Refer to the operating instructions disappears.
LSQT1158_EN.book 195 ページ 2006年12月26日 火曜日 午前10時30分 Others Cautions for use ≥ Do not leave rubber or plastic products in contact with the unit for a long time. When you use the unit in a sandy or dusty About this unit place such as a beach, do not let sand or fine dust get into the body and terminals of the ≥...
LSQT1158_EN.book 196 ページ 2006年12月26日 火曜日 午前10時30分 Others ≥ This unit is not intended for business use. in. In cold places such as a ski resort, the period during which you can record pictures is When you are not going to use the unit for an shortened.
LSQT1158_EN.book 197 ページ 2006年12月26日 火曜日 午前10時30分 Others is lit), do not remove the SD card, operate the mode dial, turn off the power or shake or About the disc impact the unit. ≥ If there is dust, a scratch, or dirt on disc or ∫...
LSQT1158_EN.book 198 ページ 2006年12月26日 火曜日 午前10時30分 Others Explanation of terms About condensation Automatic white balance White balance adjustment recognizes the colour When condensation forms on the unit, the lens of light and adjusts so the white colour will will cloud up and the unit may not work properly. become a purer white.
LSQT1158_EN.book 199 ページ 2006年12月26日 火曜日 午前10時30分 Others source. For light outside the functional automatic Similarly, when recording something on the white balance adjustment range, use the manual opposite side of a road with heavy traffic, a white balance adjustment mode. vehicle that happens to pass by may be brought into focus.
LSQT1158_EN.book 200 ページ 2006年12月26日 火曜日 午前10時30分 Others Specifications DVD Video Camera Information for your safety Power source: DC 7.9 V/7.2 V Power consumption: VDR-D310: Recording 7.0 W VDR-D220: Recording 6.0 W Signal system CCIR: 625 lines, 50 fields PAL colour signal DVD Video Recording format (DVD-RAM, DVD-RW) Recording format DVD-Video format (DVD-RW, DVD-R, DVD-R DL) VDR-D310:...
Page 201
LSQT1158_EN.book 201 ページ 2006年12月26日 火曜日 午前10時30分 Others Standard illumination 1,400 lx 12 lx (Low light mode: 1/50) Minimum required [approx. 1 lx (VDR-D310)/approx. 2 lx (VDR-D220) with the colour illumination night view function] Video output level 1.0 Vp-p, 75 ™ Y: 1.0 Vp-p, 75 ™ S Video output level C: 0.3 Vp-p, 75 ™...
LSQT1158_EN.book 202 ページ 2006年12月26日 火曜日 午前10時30分 Others JPEG (Design rule for Camera File system, based on Exif 2.2 Compression standard), DPOF corresponding VDR-D310: 2048k1512, 1920k1080 (16:9), 1280k960, 640k480 Picture size VDR-D220: 640k480, 640k360 (16:9) AC adaptor: VSK0651 Information for your safety Power source: AC 110 V to 240 V, 50/60 Hz Power consumption: 19 W...
